Creative Playthings Ridgefield Premium Pack 8 Quick Start Manual

Advertisement

CHILDHOOD STARTS HERE

Cartons for this Play Set:

1 63062-211
Ridgefield Gym 1 (Hardware)
1 63067-202
Ridgefield Gym 2 (Instructions)
1 63006-421
Williamsburg Gym 1 (Hardware)
1 63006-422
Williamsburg Gym 2
1 63006-423
Williamsburg Gym 3
1 63006-445
Williamsburg Roof (Hardware)
1 40456-402
End Panel Assembly
1 40457-402
Side Window Panel
1 40458-402
Door Panel (Hardware)
1 63008-221
Skybox 1 (Hdwre & Instr)
1 63008-222
Skybox 2
1 SC904-800Q Skybox Play Floor (Hdwre & Instr)
1 SC908-800Q Williamsburg Play Floor (Hdwre & Instr)
1 63066-101
Yorktown Skybox Panel (Hdwre & Instr)
1 SJ926-810
Skybox Wood Roof (Hdwre & Instr)
2 SM964-402
Gable End Fan (Hdwre & Instr)
2 SM963-402
Dormer (Hdwre & Instr)
1 63058-202
4 Position Swing Beam
1 63076-303
9ft Swing Beam Legs (Hdwre & Instr)
1 50546-777
3 Swings, 1 Trapeze
1 SC907-800Q Williamsburg Play Walls (Hdwre & Instr)
1 AH201-102Q Rock Climing Wall
1 63081-102
Ice Cream Stand (Hdwre & Instr)
1 8400-202
Spiral Slide (Hardware)
1 63033-102
Spiral Slide Skybox Mount (Hdwre & Instr)
1 SH946-102
Access Ladder
1 AG942-400
Access Ladder Handles (Hdwre & Instr)
1 15166-400
10 ft. Super Wave Slide
1 AG943-400
Slide Handle (Hdwre & Instr)
© Copyright 2018, Creative Playthings
Ridgefield Premium Pack 8
Dormer
The components of this gym can be combined with
others to create different play sets. This is the best
order of assembly to create this specific set.
Read this sheet and all instructions included with the
different parts before assembly.
See the Instructions and Owner's Manual included in
carton 63067-202 for important safety information.
• Start by assembling the Ridgefield tower. Instruc-
tions are in carton 63067-202. Other instructions
and hardware are in the cartons noted at left. Do
not use the Williamsburg instructions packed in
the wood roof carton.
• Ridgefield step 2. Omit the sandbox end on the
end where the Skybox is to mount. It will be re-
placed when installing the play floors.
• Ridgefield step 18. The 9ft Beam will be mounted
in the position pictured above.
• After Ridgefield step 22, before installing Panels:
Find the posts adjacent the Skybox. On the outer
face, drill 3/8" diameter holes through each post
at 4", 9-1/2", 30-7/8", and 34" below the top of the
post. Insert 5/16" weld nuts into the inner face of
each hole. The Panels will capture the weld nuts.
• Ridgefield step 24. Do not install the end wall
panel adjacent to the Skybox tower.
RIDG9WPP8
Dimensions of assembled package:
22' 4" wide x 21' 5" deep x 12' 9" tall
RIDGEFIELD PREMIUM PACK 8
RIDG9WPP8-100 Rev B (03-18)
0 "
4 "
"
9 - 1 / 2
8 "
3 0 - 7 /
3 4 "

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ridgefield Premium Pack 8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Creative Playthings Ridgefield Premium Pack 8

  • Page 1 RIDG9WPP8 Ridgefield Premium Pack 8 CHILDHOOD STARTS HERE Dormer Dimensions of assembled package: 22' 4" wide x 21' 5" deep x 12' 9" tall Cartons for this Play Set: The components of this gym can be combined with 1 63062-211 Ridgefield Gym 1 (Hardware) others to create different play sets. This is the best 1 63067-202 Ridgefield Gym 2 (Instructions) order of assembly to create this specific set. 1 63006-421 Williamsburg Gym 1 (Hardware) Read this sheet and all instructions included with the 1 63006-422 Williamsburg Gym 2 different parts before assembly. 1 63006-423 Williamsburg Gym 3 See the Instructions and Owner's Manual included in 1 63006-445 Williamsburg Roof (Hardware) carton 63067-202 for important safety information.
  • Page 2 1/4" flat washers. Drill 3/16" diameter pilot holes for positions shown on the first page. Ladder access may be the lag screws. obstructed by later installations. • Double-check all fasteners are secure and all recessed • Install the 9ft Swing Beam. Instructions are in 63076-303. hardware is covered by hole caps. RIDGEFIELD PREMIUM PACK 8 Page 2 © Copyright 2018, Creative Playthings RIDG9WPP8-100 Rev B (03-18)
