DV-5A Red-E Cabinet
Integrated Preaction Fire Protection Package
General
Description
The TYCO DV-5 Red-E Cabinet is a
A
pre-assembled fire protection valve
package enclosed within a free-stand-
ing cabinet designed to occupy minimal
floor space and to provide an aestheti-
cally pleasing enclosure for a fire pro-
tection valve riser. The entire package
is pre-wired and the water inlet and
outlets to the valve riser are grooved
to provide minimal installation time.
The valve package includes a system
(manual) shut-off control valve, an auto-
matic water control valve, and water-
flow/supervisory switches. A built-in
air compressor with associated con-
trols provides an automatic air supply
for use as either supervision and pneu-
matic actuation of the automatic water
control valve.
Integral to the DV-5 Red-E Cabinet is a
A
control panel and back-up batteries for
providing electrical alarm, supervisory,
and trouble functions. All switches
within the cabinet are pre-wired to the
control panel, making the electrical
connections for power, detection cir-
cuits, and alarms the only remaining
connections to complete the system.
In addition to the control panel being
integral to the DV-5 Red-E Cabinet,
A
windows are provided in the door for
viewing the releasing panel functions
and essential system pressure gauges.
A lock for the control panel access door
is standard, and a lock for the cabinet
door is optional.
Features and benefits are as follows:
• Aesthetically pleasing appearance
• Professionally assembled
• Internally wired
• Custom manufactured
• All gauges and panel display are
externally visible
• Industrial grade rollers (4) are stan-
dard at bottom of cabinet
IMPORTANT
Refer to Technical Data Sheet
TFP2300 for warnings pertaining to
regulatory and health information.
Page 1 of 8
• Forklift compatible
• Two-door cabinet design for ease of
maintenance
• Internal, gauge panel, and control
panel lighting
• Optional Model QRS Electronic
Accelerator for the 6 in. and 8 in.
Double Interlock Electric/Electric
Actuation system types
• Optional seismic kit
The DV-5 Red-E Cabinet is designed
A
to readily incorporate 1-1/2 to 8 in.
(DN40 to DN200) valve risers for the
following types of preaction systems:
• Single Interlock Wet Pilot Actuation
• Single Interlock Dry Pilot Actuation
• Single Interlock Electric Actuation
• Double Interlock Electric/Pneumatic
• Double Interlock Electric/Electric
• Preaction Type A
NOTICE
The DV-5 Red-E Cabinets described
A
herein must be installed and main-
tained in compliance with this docu-
ment and with the applicable standards
of the NATIONAL FIRE PRO TECTION
ASSOCIATION (NFPA), in addition to
the standards of any authorities having
jurisdiction. Failure to do so may impair
the performance of these devices.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating con-
dition. Contact the installing contrac-
tor or product manufacturer with any
questions.
Technical
Data
Approvals
UL and C-UL Listed, FM Approved,
CSFM Listed System Types
• Single Interlock Wet Pilot Actuation
• Single Interlock Dry Pilot Actuation
• Single Interlock Electric Actuation
• Double Interlock Electric/
Pneumatic Actuation
• Double Interlock Electric/Electric
Actuation
DECEMBER 2020
Worldwide
www.tyco-fire.com
Contacts

System Types

The technical data sheets referenced in
Table A provide complete details for each
system type arrangement.

Working Pressure Range

DV-5 Valve: 20 to 300 psi (1,4 to 20,7 bar)
A
DV-5 Valve Trim: Refer to individual trim
A
technical data sheets for rated trim pres-
sures as shown in Table A.

Construction

The Red-E Cabinet is constructed of a
minimum thickness of 14 gauge steel
and is free standing. The standard paint
finish is bright red and black. The front
doors of the enclosure are fully hinged
(and removable) and open nearly to the
cabinet floor level allowing easy access
to the couplings when connecting the
water supply and drain. Pre-drilled
holes on tabs along the base of the
cabinet provide an anchor point for the
cabinet to be secured to the floor when
required. Industrial grade rollers at the
bottom of the cabinet are standard.
Internal controls that provide functions
to reset a system after operation - for
example, the alarm test valve or main
drain valve - are individually tagged for
easy identification. All prefabricated
piping is Schedule 40 steel.
A splash-resistant drain cup is pro-
vided that ensures water does not
splash into the cabinet during flow
testing. The discharging water can be
observed through a clear tube attached
to the drain cup. It is designed with a
fail-safe feature allowing water to over-
flow in the event the drain is blocked.
