Everbloom T333615K2 Installation Manual

Trellis assembly kit
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank You!
You're only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Trellis Assembly Kit
Installation Guide
Before You Start
Please Read the instructions carefully to familiarize yourself with every
detail and step involved. Keep this manual for future reference. Find a
suitable space to assemble the Trellis Kit.
Important Notes
Small parts are included; we advise you to keep them away from children
and pets. We also suggest having another person help you assemble.
Subscribe at www.everbloom-garden.com for extra
savings and upgrading information!
Model# T333615K2
Everbloom-Garden.com
Questions or Comments?
Email us at service@everbloom-garden.com
Copyright © 2022 Dynaforge Trading LLC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the T333615K2 and is the answer not in the manual?

Questions and answers

Related Manuals for Everbloom T333615K2

Summary of Contents for Everbloom T333615K2

  • Page 1 Trellis Kit. Important Notes Small parts are included; we advise you to keep them away from children and pets. We also suggest having another person help you assemble. Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Everbloom-Garden.com Questions or Comments? Email us at service@everbloom-garden.com...

  • Page 2: Installation

    Installation Guide space of 33” height on EverBloom E143612 Trough Planter Box / Everbloom Trellis Assembly Kit can be firmly attached to Raised or E213612 Deep Trough Planter Box / Elevated Garden Bed to expand your growing space vertically for your E283612 Elevated Trough Planter Box climbing vines and veggies.
  • Page 3 Model# T333615K2 3. Install another corner connector following the steps above, as shown in Pic.3 and Pic.3a. view from back 2. Tighten bolts and nuts with hex key and nut driver, as shown in Pic.2. view from front 4. Insert the top back long board, as shown in Pic.4.
  • Page 4 Model# T333615K2 6. Insert bolts from inside of the extention pole to the corner connector, as shown 5. Attach the extention pole to the corner connector, as shown in Pic.5. Be in Pic.6 and Pic. 6a. Tighten the nylon lock nut by hand, as shown in Pic.6b.
  • Page 5 Model# T333617K2 7. Tighten the bolts and nuts with hex key and nut driver, as shown in Pic.7. 9. Slide the steel wire panel from above, as shown in Pic.9. top view view from back 8. Install another extention pole following step 4-6 above, as shown in Pic.8. 10.
  • Page 6 Model# T333615K2 Model# T333615K2 Note: You can choose different heights as you wish when installing steel wire panels on the extension poles. 11. Slide another steel wire panel and fix it with long bolts and nuts, as One Trellis Kit bulit on S333618W One Trellis Kit bulit on E213612 shown in Pic.11.
  • Page 7 Model# T333615K2 Installation 2 Create an additional solid growing space of 66” height on EverBloom R143638 Deep Root Raised Garden Bed / E213612 Deep Trough Planter Box with T333615K2 This installation need 2 Trellis Assembly Kits. Before installation, please be sure that the top back long board hasn’t been installed,...
  • Page 8 Model# T333615K2 11. Attach the extention pole to the corner connector, as shown in Pic.14. Be 13. Tighten all eight sure the slot of the pole is facing to the other corner connector, as shown in bolts and nuts with Pic.14a.
  • Page 9 Model# T333615K2 17. Slide the second steel wire panel from above and fix it with long bolts and 16. Fix the steel wire panel with long bolt and nut, as shown in Pic.19 and Pic.19a. nuts , as shown in Pic.20. Please pay attention to the bolts position.
  • Page 10 66” height, as shown in Pic.23. Also you can adjust the positions of these steel wire panels slightly as you like. Style in Pic.24 just is a sample. Create a 36”x15” bottom tray on EverBloom S333618W Self-Watering Mobile Elevated Garden 1.
  • Page 11 Model# T333615K2 3. Close all the connector washers, as shown in Pic.27. 4. Align the steel wire panel to four post brackets, as shown in Pic.28. Then, 5. fasten the other three connector washers on the steel wire panel to post fasten a connector washer on the steel wire panel to post bracket with brackets with bolts and nuts, as shown in Pic.29.
  • Page 12 Model# T333615K2 Installation 4 Create a pergola of 36” height on EverBloom S333618W Self-Watering Mobile Elevated Garden with T333615K2 This installation need 2 Trellis Assembly Kits. Before installation, please be sure that the top long boards haven’t been installed, or have been taken off.
  • Page 13 Model# T333615K2 2. Tighten bolts and nuts with hex key and nut driver, as shown in Pic.31. Note: Please lift the corner connector when you tighten the bolts and nuts. Be sure the screw hole centers of connector and post align. If the corner connector is installed lower, it may cause difficulty in fixing the extension poles.
  • Page 14 Model# T333615K2 4. Insert the top long boards, as shown in Pic.36. 6. Insert bolt from inside of the extention pole to the corner connector, as shown in Pic.38 and Pic. 38a. Turn on the nylon lock nut by hand, as shown in Pic.38b.
  • Page 15 Model# T333615K2 7. Tighten the bolts and nuts with hex key and nut driver, as shown in Pic.39. 9. Open all the steel connector washers, as shown in Pic.42. view from back 10. Clamp the connector washers onto the steel wire panel, as shown in Pic.43 and Pic.43a.
  • Page 16 Model# T333615K2 11. Close all the connector washers, as shown in Pic.44. 12. Align the steel wire panel to two extention poles, as shown in Pic.45 and Pic.45a. 2nd hole view from back view from front 3rd hole from bottom 13.
  • Page 17 Model# T333615K2 14. Fasten the other three connector washers on the steel wire panel to exten- 17. Align the steel wire panel to those two installed panels, as shown in Pic.50. tion poles with bolts and nuts, as shown in Pic.47.
  • Page 18 Model# T333615K2 19. Tighten the bolt and nut, as shown in Pic.52. 21. Put the roof panel between the two straight panels, as shown in Pic.54. 20. Fasten the other two connector washers, as shown in Pic.53 and Pic.53a. 22. Fasten the roof panel with side panels with cable ties at four corners, as...
  • Page 19 Model# T333615K2 24. Use post caps from garden bed to cover 4 ends of post brackets and trim by scissor, as shown in Pic.57. 25. Then you can get a pergola of 36” height on EverBloom Self-Watering Mobile Elevated Garden, as shown in Pic.
  • Page 20 2. Then, take off just the nut of outer pole of post bracket, as shown in Pic.60 and Pic.60a. Note: Do not take off the bolt. Fix garden beds on firm grounds to provide more stability on EverBloom E143612 Trough Planter Box /...
  • Page 21 Model# T333615K2 6. Assemble the other three corner brackets following steps 1-5, as shown in For E283612 Elevated Trough Planter Box, please follow steps below. Pic.65. 1. Put the garden bed to the selected place. Attach the corner brackets to the posts as shown in Pic.67 and 67a.
  • Page 22 Model# T333615K2 4. Choose suitable screws (not included), and fix the garden bed to the ground, as shown in Pic.71 and Pic.71a. 3. Tighten the bolts and nuts with hex key and nut driver, as shown in Pic.70. The safety corner bracket may also be assembled on higher position of the post bracket of the planter box or trellis, and secure the whole products on wall or other solid objects surrounding by.
  • Page 23 Bloom On. Everbloom-Garden.com US Patent Pending Subscribe at www.everbloom-garden.com for extra savings and upgrading information! Distributed by: Dynaforge Trading LLC St. Paul, MN55101 Email: service@everbloom-garden.com...
