Sanyo VCC-HD2500 Specifications

1080p 4 megapixel day-night cs box camera with audio.
Hide thumbs


Advertisement

SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO
Sanyo Company
Security Products Division
21605 Plummer Street
Chatsworth, CA 91311
Phone: 888. 818. 2597
Fax: 818.717.2716 223 9180
http://us.sanyo.com/security

Specifier Notes: This product guide specification is written according to the Construction Specifications

Institute (CSI) 3‐Part Format, based on Master Format 2004 and The Project Resource Manual—CSI Manual

of Practice. The Manufacturer is responsible for technical accuracy. By removing the references to specific

Sanyo product names or part numbers, the text may be used also in performance‐based specifications.



The section must be carefully reviewed and edited by the Architect or Engineer to meet the requirements of

the project and local building code. Words and sentences within brackets [ ] are choices to include or

exclude a particular item or statement. Coordinate this section with other specification sections and the

Drawings.


VIDEO SURVEILLANCE REMOTE DEVICES AND SENSORS
Sanyo VCC-HD2500 4 MEGAPIXEL DAY/NIGHT CS BOX CAMERA WITH AUDIO
PART 1 - GENERAL
1.1
SUMMARY
A.
Section Includes
1.
B.
Related Sections
1.
2.
3.
4.
1.2
REFERENCES
A.
Federal Communications Commission (FCC) (www.fcc.gov)
1.
B.
International Electrotechnical Commission (IEC)
1.
C.
Institute of Electrical and Electronics Engineers, Inc. (IEEE) (www.ieee.org)
Project Name/Project Number



Product Guide Specification
SECTION 28 23 29
Video Surveillance Remote Devices
Section 28 23 13 – Video Surveillance Control and Management
Systems
Section 28 23 16 – Video Surveillance Monitoring and Supervisory
Interfaces
Section 28 23 19 – Digital Video Recorders and Analog Recording
Devices
Section 28 23 23 – Video Surveillance Systems Infrastructure
FCC CFR 47 part 15 Class B – Telecommunications – Radio
Frequency Devices – Digital Emission
IEC 60529 Degrees of Protection provided by enclosures (IP Code)
28 23 29 - 12





Video Surveillance Remote Devices and Sensors

December, 2009

Advertisement

   Related Manuals for Sanyo VCC-HD2500

   Summary of Contents for Sanyo VCC-HD2500

  • Page 1

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  Sanyo Company       Security Products Division  21605 Plummer Street  Chatsworth, CA 91311  Phone: 888. 818. 2597  Fax: 818.717.2716 223 9180  http://us.sanyo.com/security    Specifier Notes: This product guide specification is written according to the Construction Specifications    Institute (CSI) 3‐Part Format, based on Master Format 2004 and The Project Resource Manual—CSI Manual    of Practice. The Manufacturer is responsible for technical accuracy. By removing the references to specific    Sanyo product names or part numbers, the text may be used also in performance‐based specifications.        The section must be carefully reviewed and edited by the Architect or Engineer to meet the requirements of    the project and local building code. Words and sentences within brackets [ ] are choices to include or    exclude a particular item or statement. Coordinate this section with other specification sections and the    Drawings.     ...

  • Page 2

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  IEEE 802.3af Power Over Ethernet International Organization of Standardization (ISO) 9001 – Quality System Underwriters Laboratories, Inc. (UL) (www.ul.com) UL 2044 Commercial Closed-Circuit Television Equipment SYSTEM DESCRIPTION Video Surveillance Remote Devices 4 Megapixel 1080p Full High Definition Day/Night Network CMOS Camera with Audio.

  • Page 3

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  trained by the manufacturer in the installation and service of the equipment provided. DELIVERY, STORAGE AND HANDLING Comply with requirements of Section [01 60 00] Deliver materials in manufacturer’s original, unopened, undamaged containers;...

  • Page 4

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  Provide selection of languages from English, French, German, Japanese and Spanish. Progressive Scan CMOS technology for image clarity. Four (4) Megapixels maximum resolution Five levels of operator privileges shall be available.

  • Page 5

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  14. When image data is output on a conventional SD output the camera shall eliminate “smearing” associated caused by vertical noise associated with bright spots (such as headlights). Video Requirements and Adjustments: Minimum Adjustments and Requirements Imager: Progressive Scan 1/3”...

  • Page 6

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  Graphics Chip: ATI Radeon HD2600 series or higher; nVidia GeForce 8600 series or higher; nVidia Quadro FX550 series or higher. Web Browser: Internet Explorer Ver 6.0 SP2 or higher, or Ver 7.0...

  • Page 7

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  H.264 1920 x 1080 1280 x 720 640 x 360 1920 x 1080 1280 x 720 640 x 360 MJPEG 1920 x 1080 1280 x 720 1024 x 576...

  • Page 8

    SANYO VCC-HD2500 1080p 4 MEGAPIXEL DAY-NIGHT CS BOX CAMERA WITH AUDIO  Power Consumption: 6.8 W. Mechanical: Weight: 8.82 oz. (250g). Dimensions: 72.4 W x 44.8 H x 75.2 D mm (2.85” W x 1.76” H x 2.96” D) Environmental: Operating Temperature: 14°F to 122°F (-10° to +50°C) within 90% relative humidity.
