Sanyo VCC-HD5400P Service Manual

Hide thumbs

Advertisement

SERVICE MANUAL
Megapixel Camera
CONTENTS
SPECIFICATIONS .............................................3
1. DISASSEMBLY ..............................................5
2. ADJUSTMENT ...............................................11
3. PARTS LIST ................................................18
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
RoHS
This product does not contain any hazardous substances prohibited by the RoHS Directive.
WARNING
You are requested to use RoHS compliant parts for maintenance or repair.
You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when carrying
out repair work.)
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
L5DG2/XE, XE-C1F, XE-C8F, US-Z, US-C1F, US-C8F, C-Z, C-C1F (R)
PRODUCT SAFETY NOTICE
FILE NO.
VCC-HD5400P
(Product Code : 117 409 00)
(Product Code : 117 459 00)
(Product Code : 117 459 10)
(Europe, U.K., Southeast Asia)
VCC-HD5400
(Product Code : 117 409 01)
(Product Code : 117 459 01)
(Product Code : 117 459 11)
(U.S.A., Canada, Taiwan, Brazil)
VCC-HD5400PC
(Product Code : 117 409 04)
(Product Code : 117 459 04)
(China)
REFERENCE No.SM5310813

Advertisement

Chapters

loading

  Also See for Sanyo VCC-HD5400P

  Related Manuals for Sanyo VCC-HD5400P

  Summary of Contents for Sanyo VCC-HD5400P

  • Page 1: Table Of Contents

    FILE NO. SERVICE MANUAL VCC-HD5400P Megapixel Camera (Product Code : 117 409 00) (Product Code : 117 459 00) (Product Code : 117 459 10) (Europe, U.K., Southeast Asia) VCC-HD5400 (Product Code : 117 409 01) (Product Code : 117 459 01) (Product Code : 117 459 11) (U.S.A., Canada, Taiwan, Brazil)
  • Page 2 WARNING Do not use solder containing lead. This product has been manufactured using lead-free solder in order to help preserve the environment. Because of this, be sure to use lead-free solder when carrying out repair work, and never use solder containing lead.
  • Page 3: Specifications

    Backlight compensation : Multi-spot evaluative metering, center-weighted evaluative metering, masking, face detection Electronic sensitivity boosting : Auto (32 x max) or Off Electronic shutter : 1/25, 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VCC-HD5400P, VCC-HD5400PC) Electronic shutter : 1/30, 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 (VCC-HD5400)
  • Page 4 Operating ambient temperature/humidity : Humidity: less than 90 % RH (no condensation) Power source : 24 V AC ± 10 %, 50 Hz/ 12 V -15 V DC/ PoE (VCC-HD5400P, VCC-HD5400PC) Power source : 24 V AC ± 10 %, 60 Hz/ 12 V -15 V DC/ PoE (VCC-HD5400) Power consumption : 21 W (PoE: 12.3 W)
  • Page 5: Disassembly

    1. DISASSEMBLY 1-1. REMOVAL OF COVER STAMP 1. Cover, SD 2. Cover, harness 3. Cover, pan lock 4. Two screws 2 x 3 5. Two screws 2 x 3 6. Cover, pan 7. Shield tape 8. Two special screws 3 x 4 When assembling, tighten the screws order.
  • Page 6 1-2. REMOVAL OF CP-3 BOARD, CP-2 BOARD, PW-1 BOARD AND TB-4 BOARD 1. Three screws 2 x 3 2. Cover, bottom 3. Three screws 2 x 4 4. Connector (x 3) 5. Connector (CN242) 6. CP-3 board 7. Three screws 2 x 4 8.
  • Page 7: 21 11. Sy-1 Board

    1-3. REMOVAL OF SY-1 BOARD AND COVER TILT 14 13 1. Two screws 3 x 6 2. Holder chassis side 3. Two screws 2 x 4 4. Shield connector 5. Connector (CN403) 6. Connector (CN404) 7. Connector (CN405) 8. Connector (CN401) 9.
  • Page 8: 8. Assy Motor Tilt

    1-4. REMOVAL OF ASSY MOTOR 1. Two screws 3 x 6 2. Holder chassis side 3. Three screws 2 x 5 When assembling, tighten the screws order. A 4. Earth shaft 5. Housing bearing 6. Bearing 7. Two screws 3 x 6 8.
  • Page 9 1-5. REMOVAL OF MOTOR FAN DC 1. Three screws 2 x 4 2. Assy gear tilt 3. Three screws 2 x 4 4. Holder cable tilt 5. Fixer BK-1 6. Connector 7. Three screws 2 x 4 8. Four screws 2.6 x 12 9.
  • Page 10 1-7. BOARD LOCATION CA-2 board SY-1 board CA-4 board PW-1 board CP-2 board CA-3 board CP-3 board TB-4 board...
  • Page 11: Adjustment

    3. Double-click on the DscCalDi.exe. Calibration software 4. L5DG2 is selected with Model Code. Chroma meter VJ8-0192 5. EX (VCC-HD5400P), US (VCC-HD5400) or C (VCC- Spare lump (pattern box) VJ8-0191 HD5400PC) is selected with Factry Mode. 6. PAL (VCC-HD5400P, VCC-HD5400PC) or NTSC (VCC-...
  • Page 12 2-5. Adjustment Adjustment location: QrCode of computer screen, Infinity 1. Timer Quartz Adjustment Cal. of computer screen Adjustment location: CT351 (CA-5) Measuring location: Computer screen Measuring location: CL351 (CA-5) Measuring equipment: Collimator Measuring equipment: Frequency counter Preparation: Subject: No designation If using a ready-made collimator, set to infinity.
  • Page 13 3. Lens Adjustment (1m) Dsc Calibration Infinity calibration : Copy AF_I_WIDE: 24 AF_I_MID1: 23 AF_I_MID2: 23 AF_I_MID3: 23 AF_I_MID4: 14 AF_I_MID5: 5 AF_I_MID6: -4 AF_I_TELE: -15 QR_Z_WIDE: -86 QR_F_I_WIDE: 131 Siemens QR_F_I_TELE: -304 200 cm 100 ± 1.0 cm star chart QR_Z_AORI: -86 Camera QR_F_I_AORI: 131...
  • Page 14 Adjustment location: AWB of computer screen Adjustment value determination is effectuated using below val- Measuring location: Computer screen ues. The adjustment values fulfill the conditions below, they are Measuring equipment: Pattern box determined as within specifications. Preparation: Adjusting method: Adjustment value determination 1.
  • Page 15 5. CMOS (CCD) White Point Defect Detect Adjustment 7. Privacy Masking Adjustment Adjustment location: CCD Defect of computer screen Measuring location: Computer screen Measuring equipment: Note: If readjusting after it has already been adjusted, wait for 15 minutes or more for the unit to cool down first. Adjustment method: 1.
  • Page 16 8. Gyro Offset Adjustment Adjustment location: EIS Adj of computer screen Measuring location: Computer screen, Privacy mask Measuring equipment: Note: Do not shake the camera while gyro offset is being Tele Privacy Mode adjusted. There is no gyro gain adjustment. Adjustment method: 1.
  • Page 17 OK if partially overlapping horizontally and vertically If you make an error during adjustment, click ADJ “DEL” in the IE window and repeat the adjustment. 6. The camera will automatically start to pan and tilt. 2-6. Overwriting firmware from the calibration Check that ”A1”...
  • Page 18: Parts List

    645 102 5883 DISC,CD-ROM L5DB2PC PC SOFT WARE, VCC-HD5400 ONLY INSTRUCTION MANUAL,Chinese (Simplified), 6008 613 222 4208 LABEL,MARK-L5DG2/XE-C1F, VCC-HD5400PC ONLY VCC-HD5400P ONLY 9801 645 101 9110 DISC,CD-ROM L5DG2 PC PC SOFT WARE, 6016 613 221 1123 HOLDER CP3 HD-L5DG2 INSTRUCTION MANUAL,...
  • Page 19 5031 6040 6040 M0001 NJ626 6003 5033 6001 NJ500 NJ620 5001 NJ618 NJ620 5011 NJ626 NJ500 6003 6008 5035 NJ612 6042 6056 6058 NJ605 6060 W1009 5011 5023 6003 NJ522 NJ522 5037 W1004 5003 5003 6005 6044 NJ600 6005 6005 NJ600 NJ502 NJ600...
  • Page 20 LOCATION PARTS NO. DESCRIPTION CABINET & CHASSIS PARTS 2 5005 613 220 9922 COVER,TILT TOP-L5DG2 5007 613 220 9939 COVER,TILT BOTTOM-L5DG2 5009 613 220 9946 COVER,PAN BOTTOM-L5DG2 5021 613 220 9960 DEC LENS-L5DG2 5027 613 220 9977 HOLDER,CHASSIS-L5DG2 5029 613 220 9984 HOLDER,CHASSIS SIDE-L5DG2 8010 613 221 0355...
  • Page 21 NJ504 5005 NJ826 NJ508 NJ512 NJ827 NJ825 NJ828 5009 8150 5029 NJ817 NJ827 NJ825 8340 8330 8110 NJ829 8090 8030 8290 8170 NJ506 8320 5021 8160 8360 NJ819 NJ816 NJ821 5007 NJ818 NJ516 NJ510 8360 8050 8020 8060 NJ819 NJ512 8300 5029 8040...
  • Page 22 LOCATION PARTS NO. DESCRIPTION 6010 613 220 5405 CHASSIS LENS-L5DF2 6012 613 222 3508 HOLDER LENS L-L5DD2 6014 613 222 3515 HOLDER LENS R-L5DD2 6015 613 222 4932 SPACER CA2-L5DF2 6025 613 221 4155 HOLDER,FAN-L5DG2 8000 613 221 0348 ASSY,HOLDER CAM UNIT-L5DG 8100 613 221 0447 HOLDER CABLE TILT-L5DG...
  • Page 23 NJ610 NJ608 W1010 NJ608 NJ813 NJ609 W1008 6014 NJ606 6015 6010 NJ823 W1007 NJ824 9000 NJ606 8390 8400 6012 NJ823 8310 8100 8000 NJ822 8370 6025 NJ823 M0002 NJ823 NJ622 L5DG2/XE_CAB3...
  • Page 24 ELECTRICAL PARTS Note: 1. Materials of Capacitors and Resistors are abbreviated as follows ; Resistors Capacitors MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor AL-SOLID Aluminum Solid Capacitor NP-ELECT...
  • Page 25 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C1066 303 338 0309 CERAMIC 0.1U K 10V R1054 301 226 1506 MT-GLAZE 0.000 ZA 1/16W C1067 303 338 0309 CERAMIC 0.1U K 10V R1056 301 224 9108 MT-GLAZE 150 JA 1/16W C1068 303 338 0309 CERAMIC...
  • Page 26 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION L8301 645 066 1969 INDUCTOR,2.0U M R9512 301 226 1506 MT-GLAZE 0.000 ZA 1/16W L8501 645 098 4594 INDUCTOR,4.7U N R9513 301 226 1506 MT-GLAZE 0.000 ZA 1/16W L8521 645 098 4594 INDUCTOR,4.7U N R9514 301 226 1506...
  • Page 27 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R7010 301 224 9009 MT-GLAZE 10K JA 1/16W C1409 303 317 1709 CERAMIC 6800P K 25V R7011 301 224 9009 MT-GLAZE 10K JA 1/16W C1410 303 317 1709 CERAMIC 6800P K 25V R7012 301 224 9009 MT-GLAZE...
  • Page 28 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION D7510 307 239 5005 DIODE RF071M2S PMDU C2316 303 384 6508 CERAMIC 10U K 6.3V 407 256 1001 DIODE DG1N15A C3501 303 338 0309 CERAMIC 0.1U K 10V 407 269 1203 DIODE SS160 C3503 303 276 1307 CERAMIC...
  • Page 29 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C6076 303 381 8109 CERAMIC 1U K 6.3V R2249 301 226 1506 MT-GLAZE 0.000 ZA 1/16W C6077 303 381 8109 CERAMIC 1U K 6.3V R2250 301 226 1506 MT-GLAZE 0.000 ZA 1/16W C6078 303 381 8109 CERAMIC...
  • Page 30 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R6151 301 224 9009 MT-GLAZE 10K JA 1/16W R6060 301 226 5405 MT-GLAZE 56 JA 1/16W R6061 301 226 5405 MT-GLAZE 56 JA 1/16W R6153 301 224 9009 MT-GLAZE 10K JA 1/16W R6154 301 224 9009 MT-GLAZE...
  • Page 31 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION Q2004 305 168 4502 TR 2SA2029-R C1712 303 381 8109 CERAMIC 1U K 6.3V 305 168 4601 TR 2SA2029-S C1713 303 384 6409 CERAMIC 4.7U K 6.3V Q2007 305 131 4508 TR 2SD1767Q C1714 303 433 1102 CERAMIC...
  • Page 32 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R1709 301 226 1506 MT-GLAZE 0.000 ZA 1/16W R2054 301 224 9009 MT-GLAZE 10K JA 1/16W R1710 301 290 1402 MT-GLAZE 300 DC 1/16W R2057 301 224 9009 MT-GLAZE 10K JA 1/16W R1711 301 226 1506 MT-GLAZE 0.000 ZA 1/16W...
  • Page 33 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION CN204 645 045 9092 PLUG,PWB-PWB 40P (N.S.P) C4005 303 445 5204 ELECT 1800U M 50V CN241 645 077 0760 PLUG,3P (N.S.P) C4006 303 445 5204 ELECT 1800U M 50V CN242 645 074 0336 PLUG,SIDE-ZR-SM4 (N.S.P) C4008 303 445 5204...
  • Page 34 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION R4123 301 037 6707 MT-GLAZE 1.2K JA 1/10W COMPL PWB,SY-1 F/W R4124 301 037 6707 MT-GLAZE 1.2K JA 1/10W 613 221 0867 R4125 301 037 6707 MT-GLAZE 1.2K JA 1/10W R4127 301 224 9405 MT-GLAZE 1.0M JA 1/16W (SEMICONDUCTORS) R4129...
  • Page 35 LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION C4405 303 306 6609 CERAMIC 560P K 50V R4410 301 037 1108 MT-GLAZE 6.8 JA 1/8W C4406 303 322 1008 CERAMIC 0.1U Z 16V R4411 301 037 1108 MT-GLAZE 6.8 JA 1/8W C4408 403 458 1405 ELECT...
  • Page 36: Circuit Diagrams & Printed Wiring Boards

    CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS TABLE OF CONTENTS OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS Page OVERALL WIRING (CA-1, CA-2, CA-3, CA-4) OVERALL WIRING (CP-2, CP-3, SY-1, PW-1, TB-4) OVERALL CIRCUIT BLOCK DIAGRAM CA-1 BOARD CMOS IMAGE SENSOR CA-2 BOARD (DM-A) SYSTEM ASIC CA-2 BOARD (DM-B) LENS DRIVER CA-2 BOARD (SY-A) SYSTEM CONTROL CA-3 BOARD (DM-C) DESERIALIZER &...
  • Page 37 NOTES: 1. All resistance values in "OHMS" unless otherwise noted. (K=1,000 ; M=1,000,000) 2. All capacitance values in "µF" unless otherwise noted. p=pico farad ; n=nano farad ; µ ,u or U=micro farad 3. All inductance values in "µH" unless otherwise noted. µ...
  • Page 38 OVERALL WIRING, BLOCK DIAGRAM & CIRCUIT DIAGRAMS OVERALL WIRING (CA-1, CA-2, CA-3, CA-4) CA-1 CA-3 CA-4 (DM-C) DM-A (PW-A) CN101 CN701 CN704 RESET RESET RESET CN105 3.3V(AL) 3.3V(AL) Y(S)_OUT CN102 HSCON HSCON HSENSE HSENSE DM-A USB_VBUS C(S)_OUT VSENSE VSENSE USB_D- CA-2 USB_D+ DM-A...
  • Page 39: Overall Wiring (Cp-2, Cp-3, Sy-1, Pw-1, Tb-4) C4

    OVERALL WIRING (CP-2, CP-3, SY-1, PW-1, TB-4) CP-2 CP-3 CN607 CN172 ENC_CLK ENC_CLK CN191 ENC_Y7 ENC_Y7 (DM-D) ENC_Y6 ENC_Y6 TMDS SHLD2 (VD-A) ENC_Y5 ENC_Y5 TMDS DATA2+ ENC_Y4 ENC_Y4 TMDS DATA2- ENC_Y3 ENC_Y3 TMDS SHLD1 (PW-B) ENC_Y2 ENC_Y2 (DM-E) TMDS DATA1+ ENC_Y1 ENC_Y1 TMDS DATA1-...
  • Page 40: Overall Circuit Block Diagram C5

    OVERALL CIRCUIT BLOCK DIAGRAM CA-2 CN102 TO USB TO ALARM IN/OUT TO I/F TO TILT TO PAN CA-4 CN703 CN704 CN403 CN404 IC142 Y,Pb,Pr,SCL,SDA GYRO SENSOR IC431 IC441 5.0V MOTOR DRIVER MOTOR DRIVER 3.0V (TILT) (PAN) (DM-A) 1.8V 1.2V 3.3V IC710 Y,Pb,Pr VIDEO AMP...
  • Page 41: Board Cmos Image Sensor

    CA-1 BOARD CMOS IMAGE SENSOR CA-1 C1-18203/L5DG2-XE CCDCK XCLR TGVD TGHD CCDSD L9001 FBMH1608HL601 1608 L9002 FBMH1608HL601 1608 CN901 L9003 FBMH1608HM601 D_GND 1608 AFEDN5 AFEDN5 AFEDP5 AFEDP5 AFECKN AFECKN A_GND AFECKP AFECKP D_GND ADCK D_GND CCDEN C9002 CCDCK CCDSD XCLR TGHD VLOADS TEST6...
  • Page 42: Board (Dm-A) System Asic

    CA-2 BOARD (DM-A) SYSTEM ASIC R1008 A_VDD1.8 0;1/16Z 1.8V(VDD) TO DM-B A_VDD1.2 L1004 FBMH1608HL600 VDD1.2 1608 A_VDD3 3.3V(AL) TO DM-B, SY-A Q1010 L1003 UPA650TT-A FBMH1608HL600 1608 AD25 AC25 AL26 AJ17 AE25 AE24 AE14 AA21 AA18 AA17 AA14 AA13 DQS19 DQS20 DQS20 DQS21 DQS21...
  • Page 43 CA-2 BOARD (DM-A) SYSTEM ASIC [UPPER-LEFT] R1008 A_VDD1.8 0;1/16Z 1.8V(VDD) TO DM-B A_VDD1.2 L1004 FBMH1608HL600 VDD1.2 1608 A_VDD3 3.3V(AL) TO DM-B, SY-A L1003 Q1010 FBMH1608HL600 UPA650TT-A 1608 AD25 AC25 AL26 AJ17 AE25 AE24 AE14 AA21 AA18 AA17 AA14 AA13 R1093 33K;1/16J Q1011 2SC4081-R...
  • Page 44 CA-2 BOARD (DM-A) SYSTEM ASIC [UPPER-RIGHT] DQS19 DQS20 DQS20 DQS21 DQS21 DQS22 DQS22 DQS23 DQS23 DQS24 DQS24 DQS25 DQS25 DQS26 DQS26 DQS27 DQS27 DQS28 DQS28 DQS29 DQS29 DQS30 DQS30 DQS31 DQS31 DAS0 R1032 DAS0 DDR SDRAM 0;1/16Z DAS1 DAS1 1.8V(VDD) DAS2 IC102 DAS2...
  • Page 45 IC101 AFEDN5 1.2V(AS)_ON AFEDP5 SDIP5 RESET TO SY-A AFECKN SCKIN0 AFECKP SCKIP0 EV3HB DGND FPI_AD ADCK ADCK LENS_TEMP DGND CA-2 BOARD (DM-A) SYSTEM ASIC [LOWER-LEFT] ZPI_AD CCDEN CCDEN HALL_OUT QEV3HB------N CCDCK CCDCK CLK24M CCDSD CCDSD STATE1 XCLR XCLR STATE2 TGHD TGHD LENS_RESETN 16.0X16.0...
  • Page 46 IC101 DQP25 RESET R1033 DQP26 DDR SDRAM ZFWR DQP26 0;1/16Z 1.8V(VDD) DQP27 DQP27 IC103 DQ12 DQP28 K4X51323PG-8GC8 EV3HB DQP28 QXXAGB058---N DQP29 DQP29 DQ13 DQP30 DQP30 VDDQ CA-2 BOARD (DM-A) SYSTEM ASIC [LOWER-RIGHT] DQP31 DQS31 DQS16 DQP31 DQ31 DQ16 DQ14 C1038 DAP0 DAP0 0.1;B...
  • Page 47: Board (Dm-B) Lens Driver

    CA-2 BOARD (DM-B) LENS DRIVER DM-B D2-18203/L5DG2-XE VOLTAGE: POWER ON 5.0V(AL) 3.3V(AL) CN951 TO SY-A, DM-A 3.3V(AL) HALL_IN+ HALL_IN+ HALL_OUT+ HALL_OUT+ HALL_IN- HALL_IN- HALL_OUT- HALL_OUT- 1.8V(VDD) TO DM-A N.C.(GND) DRIVE+ R9501 4.3;1/10F DRIVE+ DRIVE+ R9502 DRIVE- DRIVE- 4.3;1/10F DRIVE- LENS_SCLK C4 MCLK DVSS STATE2...
  • Page 48: Board (Sy-A) System Control

    CA-2 BOARD (SY-A) SYSTEM CONTROL R3034 SY-A 0;1/8Z 3.3V(AL) TO DM-A, DM-B ZSREQ Y2-18203/L5DG2-XE ZBOOT_COMREQ VOLTAGE: POWER ON TO DM-A R3043 47K;1/16J R3089 100K;1/16J R3038 47K;1/16J R3040 150K;1/16J C3023 3.3V(AL) COMREQ SCAN IN1 A10 BAT_OFF DC_IN2 R3056 3.3K;1/16J OPEN B9 SREQ SCAN IN2 OPEN R3057...
  • Page 49: Board (Dm-C) Deserializer & Video Amp

    CA-3 BOARD (DM-C) DESERIALIZER & VIDEO AMP DM-C R7024 R7102 0;1/10Z D3-18203/L5DG2-XE CN702 4.7K;1/16J R7027 0;1/10Z VOLTAGE: POWER ON R7103 IC710 R7104 R7021 4.7K;1/16J C7106 THS7303PWR 47;6.3-T 75;1/16D 4.7K;1/16J QTHS7303PW--P 3216 C7101 Q7001 C7107 2SD1767-Q 22;4-T 2125 CH.1-INPUTA CH.1-OUTPUT C7102 R7105 CH.2-INPUTA CH.1-SAG...
  • Page 50: Board (Pw-A) Power

    CA-3 BOARD (PW-A) POWER L8001 L8002 10;M BLM18PG121SN1 5.0V(AL) TO DM-C IC801 CN801 LM3100MHX QLM3100MHX--P FAN+B PGND DC_IN PGND TO DM-C C8008 0.033;B TO FAN C8007 0.01;B F8301 2A32V C8305 L8301 R8311 0;1/16Z VDD1.2 C8306 L8101 L8102 10;M BLM18PG121SN1 22;B 6.3 2125 C8301 0.1;B...
  • Page 51: Board Gyro Sensor

    CA-4 BOARD GYRO SENSOR TB-4 BOARD LED & SWITCH TB-4 IC141 CA-4 BU30TA2WNVX R1401 QBU30TA2WNVXG 2.2;1/16J VOUT T4-40900/L5DG2-XE STBY C4-18203/L5DG2-XE CN141 A_GND VOLTAGE: POWER ON A_GND A_GND VSENSE VSENSE DC/DC CONV. CN481 HSENSE HSENSE HSCON HSCON LED(A) 3.3V(AL) C1404 LED(K) 0.068;B C1407 4.7;B...
  • Page 52: Board System Control & Pan Tilt Motor Driver

    SY-1 BOARD SYSTEM CONTROL & PAN TILT MOTOR DRIVER IC401 XC6201P332MR QXC6201P332MP L4002 10;K VOUT 10;B DC/DC CONV. C4013 C4103 10;B C4104 0.01;B C4004 2125 2125 C4101 0.1;F 0.01;B IC405 IC412 TC74VHC14FT TC74VHC14FT QTC74VHC14FTP QTC74VHC14FTP IC413 R4101 TC4053BFT 0;1/16Z QTC4053BFT--P TO CP-2 (DM-D) CN401 CN601...
  • Page 53: Board Power

    PW-1 BOARD POWER CN441 PW-1 Q4401 1AV4L2WN100MG FAN5.0V SSM6J50TU L4402 FAN5.0V FAN5V 10;M 5.2X5.2 H=3.0 SENSOR L4401 P2-40900/L5DG2-XE BLM18PG121SN1 VOLTAGE: POWER ON TO FAN D4083 PS2701A-1-F3 IC401 XC61CN1502N F4001 L4001 L4003 DE5S6M FBMH3225HM601N D4001 3.5A125V FBMH3225HM601N CN401 D4002 SJPB-L6 VOUT AC24V/+ R4420 D4003...
  • Page 54: Board (Dm-D) Codec

    CP-2 BOARD (DM-D) CODEC R7515 49.9;1/16F DM-D T7501 S558-5500-25-F R7516 R7502 49.9;1/16F 0;1/16Z JK751 L7505 DLP11SN900SL2 43860-0004 X7502 TXCT 25.000MHz R7518 D4-40900/L5DG2-XE 0;1/16Z R7522 VOLTAGE: POWER ON L7506 49.9;1/16F DLP11SN900SL2 R7520 0;1/16Z R7510 1M;1/16J R7514 TO LAN 49.9;1/16F RXCT R7523 0;1/16Z R7513 10;1/10D...
  • Page 55 CP-2 BOARD (DM-D) CODEC [UPPER-LEFT] DM-D D4-40900/L5DG2-XE VOLTAGE: POWER ON 3.3V(MOB) CN602 C6062 LED(A) LED(K) SD_LED_K IC604 EEPROM AT24C128B-TH-T(OLD) SD_EJECT_KEY QXXACAT128B-P 3.3V(MOB) I2C_CLK TO TB-4 R6107 0;1/16Z I2C_DAT CN481 R6108 0;1/16Z C6063 0.1;B CN607 ENC_CLK ENC_CLK R6034 0;1/16Z ENC_Y7 ENC_Y7 ENC_Y6 ENC_Y6 ENC_Y5...
  • Page 56 CP-2 BOARD (DM-D) CODEC [UPPER-RIGHT] R7515 49.9;1/16F T7501 S558-5500-25-F R7502 R7516 49.9;1/16F 0;1/16Z L7505 JK751 43860-0004 DLP11SN900SL2 X7502 TXCT 25.000MHz R7518 0;1/16Z R7522 L7506 49.9;1/16F DLP11SN900SL2 R7520 0;1/16Z R7510 1M;1/16J R7514 TO LAN 49.9;1/16F RXCT R7523 0;1/16Z R7513 10;1/10D VDDIO_3.3 VDDIO_3.3 ETH_RXDV ETH_RXC...
  • Page 57 VID0_D4 HOST_GND DDR_RASn Y3_MOB DDR_RASn VID0_D3 HOST_GND DDR_GND DDR_DQS0n C6027 DDR_DQS0n Y2_MOB 0.1;B VID0_D2 USB_DVDD HOST_GND DDR_GND CN609 DDR_DQS1n C6026 DDR_DQS1n Y1_MOB 0.1;B VID0_D1 USB_AVDD DDR_GND DDR_DQS2n DDR_DQS2n Y0_MOB VID0_D0 USB_AVDD DDR_GND 5.0V(AL) DDR_DQS3n 5.0V(AL) DDR_DQS3n VID0_FIELD USB_ACVDD DDR_GND DDR_DQS0 DDR_DQS0 CP-2 BOARD (DM-D) CODEC [LOWER-LEFT] VID0_HSYNC...
  • Page 58 HOST_GND C6085 DDR_RASn DDR_RASn HOST_GND DDR_GND 0.1;B DDR_DQS0n JTAG_TDI C6027 DDR_DQS0n 0.1;B USB_DVDD HOST_GND DDR_GND DDR_DQS1n C6026 DDR_DQS1n 0.1;B USB_AVDD DDR_GND DDR_DQS2n JTAG_TMS DDR_DQS2n USB_AVDD DDR_GND DDR_DQS3n uCOM_RST0 uCOM_REST0 R6007 R6008 L6001 DDR_DQS3n 0;1/16Z 1K;1/16D BLM18PG121SN1 USB_ACVDD DDR_GND DDR_DQS0 DDR_VREF(D) JTAG_TCK DDR_DQS0 CP-2 BOARD (DM-D) CODEC [LOWER-RIGHT]...
  • Page 59: Board (Pw-B) Power

    CP-2 BOARD (PW-B) POWER PW-B F2301 2A32V C2305 R2317 P3-40900/L5DG2-XE 0;1/16Z L2301 1.0V(MOB) VOLTAGE: POWER ON C2306 1AV4L2WN2R0MG 22;B 6.3 2125 C2301 0.1;B PVIN2 PGND2 R2302 PVIN1 PGND1 1K;1/16J 51K;1/16D ISET SYNC/EN C2302 R2314 1.0V(MOB)_ON AGND 0.047;B 10 IC231 SC4624MLTRT R2303 QSC4624MLT--P Q2303...
  • Page 60: Board (Dm-E) System Control

    CP-3 BOARD (DM-E) SYSTEM CONTROL L2002 BLM18PG121SN1 3.3V(AL) IC210 CAT24C256YI QXXACCAT256-P R2036 R2039 22K;1/16D 22K;1/16D R2037 R2040 22K;1/16D 22K;1/16D P120/INTP0/EXLVI EEPROM SSP_ADR2 P60/SCL0 P140/PCL/INTP6 R2038 R2041 SSP_ADR1 22K;1/16D 22K;1/16D P61/SDA0 P00/TI000 R2010 SSP_ADR0 P62/EXSCL0 P01/TI010/TO00 100;1/16J NET-OPTION P130 CN241 I/O-FARM-UP P33/TI51/TO51/INTP4 P20/ANI0 ANI1/P21...
  • Page 61: Board (Vd-A) Hdmi

    CP-3 BOARD (VD-A) HDMI VD-A V1-40900/L5DG2-XE VOLTAGE: POWER ON R1933 0;1/16Z 1.8V(MOB) CN191 TMDS SHLD2 CN172 TMDS DATA2+ TMDSDATA2+ TMDSDATA2- TMDS DATA2- ENC_CLK ENC_CLK TMDS SHLD1 ENC_Y7 TMDSDATA1+ TMDS DATA1+ ENC_Y6 TMDSDATA1- TMDS DATA1- ENC_Y5 TMDS SHLD0 C1907 ENC_Y4 R1903 TMDSDATA0+ TMDS DATA0+ ENC_Y3...
  • Page 62: Printed Wiring Boards (P.w.b.)

    PRINTED WIRING BOARDS (P.W.B.) CA-1 P.W.B. (SIDE A) CA-1 P.W.B. (SIDE B) C9013 PWB,CA1 CL901 1AC4B13B0010AA CL902 SIDE-B CL903 R9001 C9011 IC901 C9003 C9004 C9016 C9012 C9001 R9002 R9004 C9002 C9006 C9029 C9023 C9017 C9021 C9005 1AC4B13B0010AA PWB,CA1 SIDE-A R9005 CA-2 P.W.B.
  • Page 63 CA-3 P.W.B. (SIDE A) CA-3 P.W.B. (SIDE B) CN703 C7020 CN705 CN704 R7027 CN705 C8006 CN703 CN801 R7026 CN704 Q7001 R7025 C7019 R7023 C8014 CN801 R8106 R7022 R7104 C8114 R7008 CL8302 R8312 R7005 C7013 R7004 CL8301 C7014 CL709 R7003 IC801 R8311 R8310 L8301...
  • Page 64 SY-1 P.W.B. (SIDE A) SY-1 P.W.B. (SIDE B) D4003 PWB,SY-1 D4001 D4003 Q4003 1AC4B10H4300AA D4004 cam14 TILT SIDE-A Q4004 C4014 Q4001 IC404 X4001 IC413 IC404 cam10 IC402 R4013 C4010 C4009 C4008 CL4014 R4108 IC406 R4109 CL4023 CL4023 CL4025 IC411 IC407 C4103 IC412 IC408...
  • Page 65 PW-1 P.W.B. (SIDE A) PW-1 P.W.B. (SIDE B) cam12 cam2 PWB,PW-1 IC441 R4401 1AC4B10H4400AB R4402 R4403 C4308 SIDE-B D4401 R4405 C4403 L4302 C4611 D4311 C4307 D4301 C4402 CN441 R4318 C4318 IC432 R4319 R4317 D4313 D4312 R4315 IC432 IC431 R4314 R4313 C4305 C4306 R4316...
  • Page 66 CP-2 P.W.B. (SIDE A) CP-2 P.W.B. (SIDE B) R6034 R6035 R6022 R6023 R6024 R2243 R2246 CN602 CN602 R6128 C6074 D7511 IC605 L6018 R6028 D7510 CN605 D7504 X6003 IC605 CL601 C6078 C6079 CL601 R6127 L6019 C6081 R6037 IC603 CL607 IC606 C6009 CL608 C6010 CN604...
  • Page 67 CP-3 P.W.B. (SIDE A) CP-3 P.W.B. (SIDE B) F1901 Q1606 1A 32V Q1607 C1611 R1918 R1927 Q1605 C1612 IC162 Q1902 C1910 D1902 IC164 C1911 CN161 VA191 R1925 C1610 CN191 D1901 R1612 R1620 VA192 R1924 IC164 R1616 R1618 Q1604 Q1602 IC163 R1622 R1617 R1619...
  • Page 70 SANYO Electric Co., Ltd. Osaka, Japan Dec./’09...
