Steelcraft 40-15020 Installation Instructions

PARTS LIST:

1 Driver/Left PNC Sidebar
1 Passenger/Right PNC Sidebar
2 Front Mounting Brackets
4 Center/Rear Mounting Brackets
Passenger/Right
PNC Sidebar

PROCEDURE:

1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS
CAREFULLY BEFORE STARTING INSTALLATION.
2. Starting from underneath the Passenger/Right body panel, locate the front mounting location and the
threaded holes in the body panel, (Figure 1). Remove the plastic plugs covering the holes.
3. Select the Passenger/Right Front Mounting Bracket. Attach the Mounting Bracket to the front location
with (2) 10mm Hex Bolts, (2) 10mm Lock Washers and (2) 10mm Flat Washers, (Figure 2). Do not
tighten hardware.
4. Repeat Steps 2 & 4 to attach (2) Center/Rear Mounting Brackets to the center and rear locations,
(Figures 3—5). Do not tighten hardware.
5. Select the Passenger/Right PNC Sidebar. Place the Sidebar onto the cradles of the Mounting Brackets.
IMPORTANT: Do not rotate or slide the Sidebar front to back or damage to the finish may result. Attach
the Sidebar to the Mounting Brackets with (6) 8mm Combo Bolts, (Figure 6). Do not tighten hardware.
6. Level and adjust the PNC Sidebar and tighten all hardware.
7. Repeat Steps 1—7 to attach the Driver/Left PNC Sidebar.
8. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, Do not use any type of polish or wax that may contain abrasives that could damage the
finish. Mild soap may be used to clean the Sidebars.
12 10mm x 30mm Hex Bolts
12 10mm Lock Washers
12 10mm x 27mm OD x 3mm Flat Washers
12 8mm x 25mm Combo Bolts
(4) Center/Rear
Mounting Brackets
(2) Front Mounting
Brackets
Page 1 of 3
4X SIDEBARS
2021-22 FORD BRONCO 4DR
Front
8/23/21 (AL)40-
