ESA609
Electrical Safety Analyzer
Users Manual
FBC-0060
February 2014, Rev. 1
© 2014 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESA609 and is the answer not in the manual?

Questions and answers

Related Manuals for Fluke ESA609

Summary of Contents for Fluke ESA609

  • Page 1 ESA609 Electrical Safety Analyzer Users Manual FBC-0060 February 2014, Rev. 1 © 2014 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 Fluke Biomedical warrants this instrument against defects in materials and workmanship for one year from the date of original purchase OR two years if at the end of your first year you send the instrument to a Fluke Biomedical service center for calibration. You will be charged our customary fee for such calibration.
  • Page 3 Copyright Release Fluke Biomedical agrees to a limited copyright release that allows you to reproduce manuals and other printed materials for use in service training programs and other technical publications. If you would like other reproductions or distributions, submit a written request to Fluke Biomedical.
  • Page 4 To ensure the accuracy of the Product is maintained at a high level, Fluke Biomedical recommends the product be calibrated at least once every 12 months. Calibration must be done by qualified personnel. Contact your local Fluke Biomedical representative for calibration.
  • Page 5 Information in this document is subject to change and does not represent a commitment by Fluke Biomedical. Changes made to the information in this document will be incorporated in new editions of the publication. No responsibility is assumed by Fluke Biomedical for the use or reliability of software or equipment that is not supplied by Fluke Biomedical, or by its affiliated dealers.

  • Page 7: Table Of Contents

    Table of Contents Title Page Introduction ........................1 Intended Use ......................... 1 Safety Information ......................2 Unpacking the Analyzer ....................4 Instrument Familiarization ....................5 Front Panel ....................... 5 Side Panels ....................... 6 Product Handstrap ....................8 Connect the Analyzer to Line Power ................8 Connect the DUT to the Analyzer ..................
  • Page 8 ESA609 Users Manual Performing a Chassis (Enclosure) Leakage Test ..........19 Performing a Direct-Equipment Leakage Test ............. 21 Making Point-To-Point Measurements ................23 Measuring Resistance ....................23 Measuring Leakage Current ..................23 Maintenance ........................24 Testing and Replacing the Fuses ................24 Cleaning the Analyzer ....................
  • Page 9 List of Tables Table Title Page Symbols ..........................2 Front Panel Controls and Connections ................. 5 Side Panel Connections ......................7 Schematic Abbreviations ...................... 14 Test Names Based on Selected Standard ................16 Replaceable Parts ........................ 26 Accessories .......................... 28...
  • Page 10 ESA609 Users Manual...
  • Page 11 List of Figures Figure Title Page Front-Panel Controls and Connections ................. 5 Side-Panel Connections ....................... 6 Product Handstrap ........................ 8 DUT Connections to the Analyzer ..................10 Start screen .......................... 11 Mains Voltage Test ....................... 12 Ground-Wire Resistence Test ....................13 Ground-Wire (Protective-Earth) Resistance Measurement Schematic .........
  • Page 12 ESA609 Users Manual...

  • Page 13: Introduction

    Electrical Safety Analyzer Introduction Intended Use The Fluke Biomedical ESA609 Electrical Safety Analyzer The Product is an electronic signal source and (the Analyzer) is a full-featured, compact, portable measurement device for verifying the electrical safety of analyzer that verifies the electrical safety of medical medical devices.

  • Page 14: Safety Information

    9 "Monitoring and Hazardous voltage. Risk of electric Control Instrumentation" product. Do not  shock. dispose of this product as unsorted municipal waste. Go to Fluke’s website  Fuse for recycling information. Conforms to relevant North American ...
  • Page 15 Electrical Safety Analyzer Safety Information • Use the correct terminals, function, and  Warning range for measurements. To prevent possible electrical shock, fire, or • Do not touch voltages > 30 V ac rms, 42 V personal injury, follow these guidelines: ac peak, or 60 V dc.

  • Page 16: Unpacking The Analyzer

    ESA609 Users Manual • Use only the mains power cord and Unpacking the Analyzer connector approved for the voltage and Carefully unpack all items from the box and check that you plug configuration in your country and have the following items: rated for the Product.

  • Page 17: Instrument Familiarization

    Electrical Safety Analyzer Instrument Familiarization Instrument Familiarization Table 2. Front-Panel Controls and Connections Item Name Description Front Panel Figure 1 and Table 2 describe the front-panel controls and Display The LCD display.  connections of the Analyzer. Test lead connectors, these Input Jacks ...

  • Page 18: Side Panels

    ESA609 Users Manual Side Panels Figure 2 and Table 3 describe the side-panel connections of the Analyzer. hpf110.eps Figure 2. Side-Panel Connections...
  • Page 19 Electrical Safety Analyzer Instrument Familiarization Table 3. Side-Panel Connections Item Name Description Port for calibrating the instrument. (Located under the holster.) For use by Calibration Port  authorized service center only. A grounded male three-prong (IEC 60320 C19 or C13) connector that accepts Power Input Connector ...

  • Page 20: Product Handstrap

    ESA609 Users Manual Product Handstrap Connect the Analyzer to Line Power Use the handstrap to carry the Analyzer, see Figure 3. Warning To prevent possible electrical shock, fire, or personal injury, do not use an extension cord or adapter plug.

  • Page 21: Connect The Dut To The Analyzer

    Electrical Safety Analyzer Connect the DUT to the Analyzer Connect the DUT to the Analyzer A Device Under Test (DUT) can be connected in a number of different ways depending on the device and the number of connections needed for a full electrical safety test. Figure 4 shows a DUT connected to the test receptacle and a separate connection to the DUT’s enclosure or protective earth ground.
  • Page 22 ESA609 Users Manual Connect ESA609 To protective earth or any exposed to grounded conductive surface on the enclosure mains socket. Connect the DUT ac power cord to the equipment outlet on the Analyzer hpf112.eps Figure 4. DUT Connections to the Analyzer...

  • Page 23: Turn On The Analyzer

    Electrical Safety Analyzer Turn on the Analyzer Turn on the Analyzer Accessing the Analyzer’s Functions To turn on the Analyzer, connect the power cord and plug Use the test function buttons on the Analyzer to select the the cord into an outlet. The Analyzer will perform a series type of test.

  • Page 24: Performing Electrical Safety Tests

    ESA609 Users Manual Performing Electrical Safety Tests Performing Mains Voltage Testing The Mains Voltage test measures the voltage on the mains The Analyzer performs a number of different electrical and input through three separate measurements. To access performance tests on biomedical equipment. The following the Mains Voltage test, press .

  • Page 25: Performing A Ground-Wire (Protective-Earth) Resistance Test

    Electrical Safety Analyzer Performing Electrical Safety Tests 3. Press the softkey labeled Zero. The Analyzer zeroes Performing a Ground-Wire (Protective-Earth) out the measurement to cancel the test lead Resistance Test resistance. The Ground-Wire (Protective-Earth) Resistance test 4. Connect the test lead coming from the red jack to the measures the impedance between the Analyzer’s test DUT enclosure or protective earth connection.
  • Page 26 Abbreviation Meaning appropriate electrical safety standard for the specific limit value to be followed. Measuring Device (ESA609 Analyzer) Figure 8 shows the electrical connections between the Functional Earth Analyzer and the DUT. Table 4 lists the abbreviations used in the schematics and their descriptions.
  • Page 27 Electrical Safety Analyzer Performing Electrical Safety Tests Device Under Test DUT_L1 Applied Part DUT_L2 DUT_PE Conductive Part Test Lead hpf26.eps Figure 8. Ground-Wire (Protective-Earth) Resistance Measurement Schematic...

  • Page 28: Performing A Current Consumption Test

    ESA609 Users Manual Press to access the leakage current main test shown in Performing a Current Consumption Test Figure 9. To measure the current consumed by the DUT, press . The Analyzer displays the current flowing through the mains connections of the test receptacle.

  • Page 29: Measuring Ground-Wire (Earth) Leakage Current

    Press rocker switches to change polarity or to open or close the neutral connection. Note When changing polarity, Fluke strongly advises you to perform the action slowly. Allow about 3 seconds to switch from one position to the other. It is possible to damage the analyzer if you switch...
  • Page 30 ESA609 Users Manual Device Under Test DUT_L1 DUT_L2 DUT_PE Conductive Part hpf27.eps Figure 10. Earth-Leakage Current Test Schematic...

  • Page 31: Performing A Chassis (Enclosure) Leakage Test

    Electrical Safety Analyzer Performing Electrical Safety Tests The Chassis Leakage test can be performed with a Performing a Chassis (Enclosure) Leakage Test number of fault conditions on the test receptacle. Note • Press the polarity rocker switch to change the polarity. The Chassis (Enclosure) Leakage test is only available for the IEC 60601 or ANSI/AAMI ES1 •...
  • Page 32 ESA609 Users Manual Device Under Test DUT_L1 DUT_L2 Earth DUT_PE Conductive Part Test Lead hpf28.eps Figure 11. Enclosure-Leakage Current Test Schematic...

  • Page 33: Performing A Direct-Equipment Leakage Test

    Electrical Safety Analyzer Performing Electrical Safety Tests The following outlet conditions apply when performing this Performing a Direct-Equipment Leakage Test test: Note • Normal Polarity, Closed Earth The Direct-Equipment Leakage test is available when the EN62353 standard is selected. • Normal Polarity, Open Earth The Direct-Equipment Leakage Current test measures the •...
  • Page 34 ESA609 Users Manual Device Under Test DUT_L1 DUT_L2 DUT_PE Conductive Part Test Lead hpf24.eps Figure 12. Direct-Equipment Leakage Test Schematic...

  • Page 35: Making Point-To-Point Measurements

    Electrical Safety Analyzer Making Point-To-Point Measurements Making Point-To-Point Measurements The Analyzer can make resistance and low current measurements through its Point-to-Point function. To access the Point-to-Point menu press . Use the softkeys F1 through F3 to select the measurement function. Measuring Resistance To make a resistance measurement: 1.

  • Page 36: Maintenance

    Disconnect the mains power cord before the case bottom label of the Analyzer. Table 6 lists you remove the Product covers. available fuses with Fluke Biomedical part numbers. • Remove the input signals before you clean 5. Reinstall the fuse door and secure it with the screw.

  • Page 37: Cleaning The Analyzer

    Electrical Safety Analyzer Maintenance Cleaning the Analyzer  Warning To avoid electric shock, do not clean the Analyzer plugged into mains or attached to a DUT.  Caution Do not pour fluid onto the Analyzer surface; fluid seepage into the electrical circuitry may cause the Analyzer to fail.

  • Page 38: Replaceable Parts

    Users Manual Replaceable Parts Table 6 lists the replaceable parts for the Analyzer. Table 6. Replaceable Parts Item Fluke Biomedical Part Number ESA609 Safety Sheet 4370092 ESA609 Users Manual CD 4370089 2238680 2238596 Australia 2238603 Europe 2238615 Power Cord France/Belgium...
  • Page 39 Electrical Safety Analyzer Replaceable Parts Table 6. Replaceable Parts (cont.) Item Fluke Biomedical Part Number T20 A 250 V Fuse (Time Lag), 1¼ in x 2183691 ¼ in Australia, Switzerland T10 A 250 V Fuse (Time Lag), 1¼ in x...

  • Page 40: Accessories

    ESA609 Users Manual Accessories Table 7 lists the available accessories for the Analyzer. Table 7. Accessories Item Fluke Biomedical Part Number Test Leads with Retractable Sheath 1903307 Ground Pin Adapters 2392639 15 A – 20 A Adapter 2195732...

  • Page 41: Specifications

    Electrical Safety Analyzer Specifications Specifications Temperature Operating ............0 °C to 50 °C (32 °F to 122 °F) Storage ............... -20 °C to 60 °C (-4 °F to 140 °F) Humidity ..............10 % to 90 % non-condensing Altitude 120 V ac mains supply voltage ......5000 m 230 V ac mains supply voltage ......

  • Page 42: Detailed Specifications

    ESA609 Users Manual Detailed Specifications Test Standard Selections ........ANSI/AAMI ES-1/NFPA99, IEC 62353, and IEC 60601-1 Mains Voltage Measurement Range ..............90.0 V ac rms to 264.0 V ac rms Accuracy ............. ±(2 % of reading + 0.2 V) Earth Resistance Modes ..............
