Summary of Contents for Fluke ESA700 Series
- Page 1 ESA710/ESA712/ESA715 Electrical Safety Analyzer Quick Guide...
-
Page 2: Getting Started
Introduction Getting started The Fluke Biomedical ESA710, ESA712 and ESA715 Electrical Safety There are two ways of working with the analyzer: Analyzers are designed to verify the electrical safety of medical devices. They allow users to test equipment against various domestic •... -
Page 3: Intended Use
Intended use The ESA710/ESA712/ESA715 (the product) is intended for use by trained service technicians to perform periodic preventative maintenance on a wide range of equipment. The testing procedures are menu-driven, and simple to operate. The product is an electronic signal source and measurement device for verifying compliance with electrical safety standards. -
Page 4: Safety Information
Safety information Read the safety information and all instructions before you use the • Use only the mains power cord and connector approved for the ESA710/ESA712/ESA715 (the product). voltage and plug configuration in your country and rated for the product. A Warning identifies hazardous conditions and actions that could cause bodily harm or death. - Page 5 • Do not exceed the Measurement Category (CAT) rating of the • Remove the null post adapter from the Ø/Null terminal after a test lowest-rated individual component of a product, probe, or lead zero is performed. The Ø/Null terminal becomes potentially accessory.
-
Page 6: General Specifications
General specifications Power (region dependent) ........90–132 V ac, 20 A MAX, 47–63 Hz 90–132 V ac & 180–264 V ac, 15 A MAX, 47–63 Hz 90–132 V ac & 180–264 V ac, 10 A MAX, 47–63 Hz 90–132 V ac & 180–264 V ac, 16 A MAX, 47–63 Hz Safety standard compliance ........ - Page 7 Symbols Symbols applicable to the product and user manual. For a full list of applicable product symbols, please visit: www.flukebiomedical.com/resource/certification-sheets. Symbol Description WARNING. RISK OF DANGER. WARING. HAZARDOUS VOLTAGE. Risk of electric shock. Consult user documentation. Power button ...
- Page 8 ©2025 Fluke Biomedical. FBC-141, March 2025, Rev. 1...
