PiCoolFAN4

Set up Procedure

What's in the Bag?

This package comes with everything you need to start using the PiCoolFAN4 right out of the box. It's
assembled, tested and contains all required accessories. Minor assembly is required by the user and no
soldering is necessary.
Each Package contains the following parts:
1. Assembled PiCoolFAN4 PCB
2. 2mm Header and Jumper
3. Necessary fan screws (4), bolts(4) and plastic spacers(4)
Note: The kit includes a 2mm header and jumper, but this is only required for the rare scenario where the
user needs to reset the bootloader and is otherwise not necessary to be soldered.
The PiCoolFAN4 assembly requires a pair of scissors and a cross-head screwdriver.
Designed by www.pimodules.com
Firmware Code 0x14
