RDK-B (Raspberry Pi 3 B+) Build and Setup Manual -
Router Profile
Introduction
Build Instructions and Flashing Procedure
Hardware and Setup Information
RDK-B Bootup Sequence
Router Profile Test Bed using RPI
Router Functionality Use Case - Internet connectivity for Wired and Wireless Client(s)
Lists of Supported Features
Supported Features User manual
Additional Links
Yocto Modification for RDK B+ Support
Introduction
The Raspberry Pi 3 Model B+ featuring a 64-bit quad core
802.11.b/g/n/ac wireless LAN which provides an high edge for the broadband developer community to test the RDK-B stack with Router, WiFi
functionalities.
Build Instructions and Flashing Procedure
RDK-B Raspberrypi - Host SetUp and Build Instructions
Hardware and Setup Information
RDKB RPI Setup Information
Note : RPI-3 B and B+ have same Build instructions and testing procedure
RDK-B Bootup Sequence
GwProvApp-Ethwan is the entry point for RDK-B stack middleware. It does all gateway initialization as above
Responsible to initiate the registration of all services on boot -up. Responsible for all provisioning of LAN,FIREWALL(iptables),BRIDGE,etc
GwProvApp-EthWan is specifically designed for Ethernet only Input feed for WAN Network Connection(i,e erouter0)
Router Profile Test Bed using RPI
processor
running at 1.4 Ghz. R-Pi3 B+ supports the dual band
2.4GHz and 5GHz IEEE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Raspberry Pi 3 B+
Summary of Contents for Raspberry Pi 3 B+
- Page 1 Supported Features User manual Additional Links Yocto Modification for RDK B+ Support Introduction The Raspberry Pi 3 Model B+ featuring a 64-bit quad core processor running at 1.4 Ghz. R-Pi3 B+ supports the dual band 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN which provides an high edge for the broadband developer community to test the RDK-B stack with Router, WiFi functionalities.
- Page 2 Router Functionality Use Case - Internet connectivity for Wired and Wireless Client(s) Ethernet Port of RPI should be connected to WAN Network Connect WiFi Dongle to RPI ( Please refer to supported dongle here RDKB RPI Setup Information#DonglesInformationLinks Client PC(s) should be connected to RPI through Usb2Ethernet Adaptor which should be supported by RPI ( Please refer to https://elinux.org /RPi_USB_Ethernet_adapters for supported usb to ethernet adapter by RPI ).
- Page 3 Parental Control(Managed Devices,Managed Sites,Managed Services) Port Forwarding Remote Management ( Available only with http support ) Factory-Reset Captive Portal Password-Reset Test and Diagnostics Bridge Mode Webpa Bootchart MAC Filtering Firewall Settings Log level control through CcspLogAgent Firmware Upgrade using Dual bank Log Rotation Support SNMP Band Steering using RSSI...
