Section A - Mounting the product
Step 3:
Open the dead front
Before removing the dead front, ensure the IQ System Controller 2
is completely de-energized.
Risk of equipment damage. Do not wire the IQ System
Controller 2 when it is energized.
• Risk of equipment damage. Do not remove the pre-installed
solar shield attached to the enclosure door.
• Risk of electric shock. Do not modify the dead front other than
to remove or replace filler plates, as needed. The product
warranty can be affected in case of modification.
2
IQ System Controller 2 Quick Install Guide
Philips screw #2
1
3
The ground connection to the dead front needs to
be carefully disconnected before the dead front can
be dismantled from the IQ System Controller 2.
12
