Section A - Mounting the product
Step 1:
Minimum clearance
This product must be installed with clearance at the left, right, top,
bottom, and front of the product as shown in the figure.
Follow all local standards and regulations related to the mounting of
an IQ System Controller 2.
6 i n
6 i n
3 6
i n
6 i n
3 6 i
1 9 . 7
n
i n
i n
9 . 7
IQ System Controller 2 Quick Install Guide
10
