Mount to J-box
Important: Read all instructions prior to installation.
LED Wall Pack
Installation II: Mounting to Wall/Conduit
Mount to wall with
3 anchors and 3
screws
Dimensional Drawings
3.30in
83.82mm
Quick connect
2.34in
Terminal
59.38mm
FOAM GASKET
6.53in
165.81mm
Rev Date: V1 03/02/2018
User Manual
Part Number:
Mount to wall with
3 anchors and 3
WPFCD Series
screws
Quick connect
Terminal
INSIDE DRILL DIAGRAM
3.50in
88.90mm
2.75in
69.85mm
Conduit
14.02in
356.09mm
9.26in
235.33mm
10.87in
276.22mm
Conduit
9.25in
234.82mm
Rev Date: V1 03/02/2018
LED Wall Pack
User Manual
Part Number:
WPFCD Series
5yr
