INTRODUCTION

This guide details how to configure the LD8 receiver to simulate the following FMEA trial requirements:
1. Loss of Differential Corrections
2. Total Loss of GNSS satellites
All commands to the LD8 unit described within this guide are to be sent using the LD8 WebUI terminal which can be
accessed by navigating to Tools > Terminal as shown below. Further inf ormation on how to connect to the LD8
receiver using the WebUI can be found within the
LD8 FMEA TRIAL PROCEDURE – LOSS OF
CORRECTIONS
Bef ore starting the trial, make a note of the current L-band settings of the LD8 unit by entering the following
command into the WebUI terminal:
LOG LBANDTRACKSTAT
The terminal will display a response similar to the following:
LBANDTRACKSTAT WCOM1_30 0 50.5 FINESTEERING 2062 457753.000 0a000020 29e3 15441
3
"IOR" 1545865000 1200 974c 00c2 0 -91.416 43.052 3.6091 15658.910 298176 2330 746
38166528 290966 0.0000
"25E" 1545825000 1200 974c 00c2 0 -223.267 43.704 3.8057 78985.820 1504384 5 5 192561152
515 0.0000
"AORW" 1545845000 1200 974c 00c2 0 -280.645 40.858 2.8379 78986.523 1504448 607 571
192569344 68081 0.0015
LD8 FMEA TRIAL GUIDE
(WEBUI)
LD8 Operations
Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERIPOS LD8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hexagon VERIPOS LD8

Summary of Contents for Hexagon VERIPOS LD8

  • Page 1 LD8 FMEA TRIAL GUIDE (WEBUI) INTRODUCTION This guide details how to configure the LD8 receiver to simulate the following FMEA trial requirements: 1. Loss of Differential Corrections 2. Total Loss of GNSS satellites All commands to the LD8 unit described within this guide are to be sent using the LD8 WebUI terminal which can be accessed by navigating to Tools >...
  • Page 2 LD8 FMEA TRIAL GUIDE (WEBUI) The above example shows the LD8 in auto beam mode where multiple L-band beams are being tracked. If the L- band tracking was set to the Manual mode, then only one beam will be displayed on the terminal output. Make a note of the tracking mode and the selected beams.
