6. STORAGE
1) To ensure that the battery is fully charged, avoid setting SS3S in extremely hot or cold environ-
ments.
2) If the equipment will not be used for a long time, please remove the battery before storage.
3) The batteries and chargers must be placed in the instrument box to prevent heat, dust and mois-
ture from entering, check if the switch is off.
4) Check the switch if close or not.
5) The battery should be stored in a dry environment under:
6) Short term less than 1 month storage temperature -20T-4-60X.
7) Short-term storage temperature less than 6 months -10 t ~+35" C.
8) Recommended storage temperature (TC ~3(rc) for longer storage time.
9) The distance between the battery and the combustible must be kept beyond 1.5 m.
• To ensure the service life of the equipment and prevent its degradation, store it in a fully charged
state. When not in use, charge and discharge the battery at least once a month.
Do not turn on the power switch when storing.

7. TECHNICAL SPECIFICATIONS

Power: 18 V
No load speed: 3000 rpm
Linear speed: 5 m/s
Cutting capacity: 80-90 mm
Bar length: 4"/102 mm
Chain pitch: 1/4"
Teeth: 28
Weight: 1 kg
*Battery and charger are not included.

8. EXPLODED VIEW

1 Lock Nut
2 Screw ST4.8x25
3 Sprocket Cover
4 Cover
5 Torsion Spring
6 Liner sleeve
7 Chain
8 Guide plate
9 Adjust the pin
10 Screw ST4x22
11 Left housing 1
12 Screw M6
13 LED
14 Screw ST3x6
15 Screw ST2.9x6
16 Pinion
17 Gear house
18 DC motor
19 Screw ST2.9x10
20 Right housing 1
21 Screw ST2.9x16
22 Bearing 608
23 Ring circlip
24 Bearing 6900Z
25 Main gear
26 Spindle
27 Switch
28 Battery pack pins
29 Left housing 2
30 Sprocket wheel
31 Screw M5x8
32 Right housing 2
