- Page 1 TSM800C / TSM1330C / MBB200C Update Instructions Revision 1.3 Copyright © 2014 Maretron, LLP All Rights Reserved Maretron Document #: 10295 Page...
- Page 2 TSM800C / TSM1330C / MBB200C Update Instructions Revision History Rev. Description Original document Update to use new installation program Changed to single update program Corrected bookmark in table of contents Page...
-
Page 3: Table Of Contents
Table of Contents Introduction..............................4 N2KView Application Update ........................4 N2KView Automatic Update ......................4 System Update ............................. 4 USB Flash Drive Creation........................ 5 Update Installation on System ......................9 Page... -
Page 4: Introduction
USB flash drive. 2.1 N2KView Automatic Update In a system where the TSM800C, TSM1330C, or MBB200C has internet access, if the Allow Automatic Updates check box in the Configuration Dialog is checked, the system will automatically check for updates to N2KView on startup, and prompt the user to the install the updates. -
Page 5: Usb Flash Drive Creation
In this case, please contact Maretron technical support for assistance. 3.1 USB Flash Drive Creation These are instructions to create a USB flash drive that will update the system image on a TSM800C, TSM1330C, or MBB200C. Perform the following steps on your Windows PC: Get a new USB flash drive, at least 4GB in size. - Page 6 Click on the Start button. The format will take a short time to complete. On the same PC, download and run the update program from the “Updates” link of the TSM800C, TSM1330C, or MBB200C product page on the Maretron website. This program will install the required update files to the USB flash drive.
- Page 7 Next, a screen will appear allowing you to choose the USB flash drive on which to install the update files. If you have only one USB flash drive plugged in, it will be already selected. The “Ready to Install” screen will appear next. Click Install to begin copying the file to the USB flash drive.
- Page 8 TSM800C / TSM1330C / MBB200C Update Instructions The setup program will now copy all of the required update files to the USB flash drive. Finally, the “Completing…” window will be shown. You can check the checkbox to display a copy of these instructions, and click the Finish button to complete the setup process.
-
Page 9: Update Installation On System
Maretron N2KView BlackBox a.b.c.yyyymmdd.air n2kview-update-descriptor-blackbox-2.5.xml sysfiles directory Eject the USB flash drive – the USB flash drive is now ready to install the update on the TSM800C, TSM1330C, or MBB200C. 3.2 Update Installation on System With the TSM800C, TSM1330C, or MBB200C powered off, plug the USB flash drive into an available USB port, and then power on the system. - Page 10 TSM800C / TSM1330C / MBB200C Update Instructions The system files will be updated next. A progress screen will appear until this is completed. Next, the N2KView application will be updated. This process can take some time. Page...
- Page 11 An Application Install window will appear. Please press the Replace button to continue. A second Application Install window will appear. Please click the I Agree button to continue. Page...
- Page 12 TSM800C / TSM1330C / MBB200C Update Instructions Next, the new version of N2KView will be installed. This process will take several minutes. Finally, a window will show telling you that the update process is complete, and the following window will appear. Please remove the USB flash drive and press OK to restart the system.
