Page 1: Graphic Display
® ® DSM250 NMEA 2000 Multi-function Color ® Graphic Display User’s Manual Revision 1.4.2 Copyright © 2009 Maretron, LLP All Rights Reserved Maretron, LLP 9014 N. 23 Ave #10 Phoenix, AZ 85021-7850 http://www.maretron.com Maretron Manual Part #: M001301 1.4.2 Revision Page i www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 2 DSM250 User’s Manual Revision History Rev. Description Original document. 1.4.2 Added sections on Alert and Anchor Watch and configuration of more devices. Page ii Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 3: Table Of Contents
Choosing a Mounting Location ................... 2 Mounting the DSM250......................2 2.3.1 Surface Mounting the DSM250 ..................2 2.3.2 Flush Mounting the DSM250 ..................3 2.3.3 Gimbal Mounting the DSM250 ..................4 ...
Page 4 Maretron DSM200 Configuration ..................61 6.5.1 Remote Device Selection .................... 61 Maretron DSM250 Configuration ..................63 6.6.1 Remote Device Selection .................... 63 6.6.2 Copy alarms settings from local display ..............64 ...
Page 5 ® ® 6.6.8 Label ........................... 67 6.6.9 Remote Device Selection .................... 68 Maretron DST100 Configuration ..................69 6.7.1 Advanced Configuration ....................69 6.7.2 Clear Speed Calibration ....................70 6.7.3 Speed Calibration ....................... 70 ...
Page 6 DSM250 User’s Manual 6.12.3 Instance ........................102 6.12.4 Channel Configuration ....................102 6.13 Maretron SIM100 Configuration ..................103 6.13.1 Advanced Configuration .................... 103 6.13.2 Device Label ......................104 6.13.3 Instance ........................105 ...
Page 7 ® ® 6.21.5 Barometric Pressure ....................147 6.21.6 Outside Humidity....................... 147 6.21.7 Outside Temperature ....................148 Data Display Types ........................149 Anchor Watch Display ....................149 Compass Rose Display ....................149 ...
Page 8 DSM250 User’s Manual Technical Specifications ......................187 Technical Support ........................191 Installation Template ........................193 Maretron (2 Year) Limited Warranty ..................196 Page viii Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 9 Figure 7 – Keypad and Key Names ...................... 7 Figure 8 – Entering a Textual Value ...................... 9 Figure 9 – DSM250 Running in Favorite Screens Mode ..............24 Figure 10 – Main Menu ........................25 ...
Page 10 Figure 57 – DST100 Configuration Screen ..................69 Figure 58 – DST100 Advanced Configuration Screen ................ 69 Figure 59 – Calibrating the DSM250 for DST100 Speed through Water ..........70 Figure 60 – Setting the Transducer Depth Offset in a DST100 ............71 ...
Page 11 ® ® Figure 95 – RIM100 Channel Configuration Screen ................. 102 Figure 96 – SIM100 Configuration Screen ..................103 Figure 97 – SIM100 Advanced Configuration Screen ............... 103 ® Figure 98 –SIM100 NMEA 2000 PGN Enable/Disable Screen ............104 ...
Page 12 DSM250 User’s Manual Figure 143 – Intermediate Level Calibration ..................132 Figure 144 – Full Level Calibration ....................133 Figure 145 – Custom Tank Level Calibration Confirmation Screen ..........133 Figure 146 – Rectangular Tank Selection ..................134 ...
Page 13 ® ® Figure 192 – Trigger Configuration Editor - Tripped Alert ..............170 Figure 193 – Outside Alert Parameters ..................... 171 Figure 194 - Trigger Configuration – Outside Radius Alert ............... 172 Figure 195 – Trigger Configuration - Inside Radius Alert ..............173 ...
Page 14 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 15: General
® Congratulations on your purchase of the Maretron DSM250 NMEA 2000 Multi-function Color Graphic Display. Maretron has designed and built your display to the highest standards for years of dependable and accurate service. ® Maretron’s DSM250 is a high-resolution color display that allows easy interpretation of NMEA 2000 instrument and navigation data through custom display configurations, with an easy-to-use five-key illuminated keypad.
Page 16: Installation
2.3.1 Surface Mounting the DSM250 The DSM250 can be directly mounted to any suitable surface as shown in Figure 1. The steps for this type of mounting are as follows: 1.
Page 17: Flush Mounting The Dsm250
Figure 1 – Surface Mounting the DSM250 2.3.2 Flush Mounting the DSM250 The DSM250 can be flush mounted to any suitable surface as shown in Figure 2. The steps for this type of mounting are as follows: 1. Attach the Flush Mount Template (see Section 13) to the surface where the DSM250 is to be located.
Page 18: Gimbal Mounting The Dsm250
Figure 2 – Flush Mounting the DSM250 2.3.3 Gimbal Mounting the DSM250 The DSM250 can be gimbal mounted to any horizontal surface such a counter or ceiling as shown in Figure 3. The optional gimbal mounting assembly (part number DSMMNTASSBLY) includes a bracket and screws for attaching the bracket to the DSM250, a stand, and 2 knobs for fastening the DSM250/bracket to the stand.
Page 19: Connecting The Dsm250
Maretron NMEA 2000 cable (or compatible cable) by connecting the female end of the cable to the DSM250 (note the key on the male connector and keyway on the female connector). Be sure the cable is connected securely and that the collar on the cable connector is tightened firmly.
Page 20: Operating The Dsm250
To turn the DSM250 off, press and hold the power key. The DSM250 will display a countdown screen, which can be seen in Figure 6. If you continue to hold the power key, the DSM250 will power down in approximately three seconds. If you release the power key before these three seconds have elapsed, the DSM250 will return to its current operational state.
Page 21: Keypad Essentials
Down Enter Figure 7 – Keypad and Key Names In the normal viewing mode where your favorite screens are displayed, the keys on the DSM250 keypad have the following functions: Power Key ( ) – turns the DSM250 off (see section 3.1 on page 6 for details). A momentary press of this key can also be used to accept or cancel an Alert (see section 8.2.1 on page 160...
Page 22: Choosing A Value From A List
3.3.2 Choosing a Value from a List When editing a value chosen from a list, the keys on the DSM250 keypad have the following functions: Power Key ( ) –...
Page 23: Figure 8 - Entering A Textual Value
® ® Figure 8 – Entering a Textual Value The top line contains the textual string that has already been entered. New characters are appended one at a time to the end of the line, at the position marked by the underscore. To append an uppercase character, use the Scroll Up and Scroll Down buttons to select Uppercase and then press Enter to go across to the characters.
Page 24 DSM250 User’s Manual To abort the entire textual edit, and return to the original field without changing the contents of the field, use the Scroll Up and Scroll Down buttons to select Exit without Saving and then press Enter. To enter the text string in the original field, use the Scroll Up and Scroll Down buttons to select Save and Exit and then press Enter.
Page 25: Important Concepts
DSM250 supports up to 16 different favorite screens. Categories and Data Types The DSM250 is capable of displaying many types of information. In order to make it easier to locate a specific type of information to display, the different types of information are organized into general...
Page 26: Ac Utility
Phase C L-L Voltage – displays phase C Line-to-phase A Line RMS voltage of the Utility 4.2.4 Anchor Watch The DSM250 provides a graphical display of the Anchor Alert (section 8.3.7.9) parameters. When the vessel is anchored, the position of vessel at the point of dropping the anchor is entered in to the Anchor Alert plus the maximum distance that the boat can drift from that position (normally a little more than the amount of Anchor Chain that you have let out).
Page 27: Depth
Anchor Drop position and the radius of the alert (see section 7.1 for more details on the display). 4.2.5 DC The DSM250 supports the display of information for up to 64 DC sources including alternators, batteries, solar cells, wind generators, etc., with special parameters for batteries (i.e., State of Charge, Time Remaining, etc.).
Page 28 DSM250 User’s Manual Heat Index – displays the current heat index based on air temperature and humidity Humidity Inside – displays the relative humidity from an indoor humidity sensor Humidity Outside – displays the relative humidity for an outdoor humidity sensor Moon Phase –...
Page 29: Fuel Management
Time to empty is only applicable if the conditions remain the same. Total Fuel Capacity – displays the total capacity of all fuel tanks. The DSM250 can only compute total fuel capacity assuming all totalized tanks are transmitting their capacity.
Page 30: Heading
4.2.13 Navigation The DSM250 is not a primary navigation device; that is, it does not provide means for entering and storing waypoint and route data. The DSM250 can receive information on the current leg of the voyage from a primary navigation device (such as a chart plotter or PC with navigation software and ®...
Page 31: Speed
4.2.17 Tank The DSM250 supports the display of information for up to sixteen tanks types (16 fuel plus 16 water, etc.). Capacity – displays the fluid capacity of the tank Level – displays the level of fluid in the tank as a percentage of its capacity Remaining –...
Page 32: Temperature
4.2.20 Transmission The DSM250 supports the display of information for up to four transmissions. Gear – displays the current gear of the transmission (forward, neutral, or reverse) Oil Pressure – displays the pressure of the oil in the transmission Oil Temp.
Page 33: Wind
® ® Trim Tabs – displays the position of the vessel’s trim tabs 4.2.22 Wind Dir. Apparent – displays the angle of the wind relative to the vessel center line as it appears to an observer on the deck of a moving or stationary vessel (does not subtract out the speed of the vessel) Dir.
Page 34: Alerts
Alerts. Optionally, an Annunciator message is sent to devices capable of sounding an audio alarm (e.g. the ALM100). Currently, the DSM250 and the N2KView™ Vessel Monitoring Software are capable of generating and receiving Alert Messages.
Page 35 ® ® • Disabled – All alerts are disabled. This mode should be used when the vessel is in storage, dry- dock, or otherwise out of operation. • Moored - This mode is used when the vessel is secured to a structure that is permanently attached to the ground like a pier, wharf, dock, or mooring buoy.
Page 36: Alert States
Screen in the “What Happened” column. 4.3.6 Available Alert Classes The DSM250 has several classes of alerts, depending on the parameter for which an alert is being configured. • Low Alert – The alert will become active if the monitored value drops below the value in this alert for longer than the time specified in the Set Delay field.
Page 37 ® ® • Off Alert – The alert will become active if the monitored switch or flag becomes “OFF” for longer than the time specified in the Set Delay field. • Tripped Alert – The alert will become active if the monitored circuit breaker becomes “Tripped” for longer than the time specified in the Set Delay field.
Page 38: Operating Modes
Auto mode - the DSM250 automatically cycles between “favorite” screens, at time intervals which are individually programmable for each “favorite” screen. An example screen of the DSM250 running in favorite screens mode can be seen in Figure 9 below. Figure 9 – DSM250 Running in Favorite Screens Mode...
Page 39: Figure 10 - Main Menu
® ® In menu mode, the DSM250 may be configured by scrolling up and down the menu and selecting one of the submenus found there. The DSM250 Main Menu can be seen in Figure 10 below. Figure 10 – Main Menu The menu has the following structure Alert Setup…(5.2.1)
Page 40: Alert Setup Menu
5.2.1 Alert Setup Menu Selecting Alert Setup… from the Main Menu allows you to create, delete, and edit the Alerts stored in the DSM250, and to change the operating mode of the vessel. See section 8 for details on the Alerts.
Page 41: Display Settings Menu
) to accept the setting. The DSM250 will retain information on devices that have been removed from the bus or powered down (“Offline”) so that when they are placed back on the bus, they will assume their prior “Display” setting.
Page 42: Figure 13 - Dsm250 Display Settings Screen
See section 3.3.4 for details on how to enter a textual value. 5.2.4.1.2 Primary Device Selection Not all the data displayed by the DSM250 can be taken directly off the NMEA 2000 bus. Some require calculations with other parameters before the desired value can be displayed. An example Page 28 Revision 1.4.2...
Page 43: Figure 15 - Dsm250 Primary Device Selection
The instance number of the weather station is specified for each control. This table provides the instance numbers of the other parameters used in the calculations. Figure 15 – DSM250 Primary Device Selection 5.2.4.1.3 Refresh Network Information The Device Configuration (5.2.3.1) and Device Selection (5.2.3.2) menus display a list of devices that have been detected on the NMEA2000 bus.
Page 44: Figure 16 - Dsm250 Advanced Information Screen
Baud Rate: the speed capability of the connected network given in bits per second (bps), Voltage: the network voltage as measured by the DSM250 in Volts, Traffic: the percent usage of the total available bandwidth measured by the DSM250, Receive Rate: the DSM250 measured received rate in frames per second (fps),...
Page 45: Figure 18 - Backlight Menu
The DSM250 has three user-programmable lighting levels which may be cycled through using the Lights key ( ) on the keypad while the DSM250 is operating in favorite screens mode. Each time you quick press the Lights key ( ) in favorite screens mode, the DSM250 backlight will transition between the “Low”...
Page 46: Figure 19 - Color Palette Selection Screen
Set #1 while changing between color palettes when using a long press of the Lights key ( ) when the DSM250 is operating in favorite screens mode. Change the “Color Set:” back to “On” to enable this color palette. Notice that Color Set #1 has a white background (100% Red, 100% Green, and 100% Blue equals white) and that the foreground color is black.
Page 47: Figure 21 - Setting The Demo Mode
DSM250 to return to using data from the NMEA 2000 bus. In order to be able to demonstrate all of the DSM250’s capabilities, the unit allows the user to setup and configure different screens while in demo mode. However, in a show room environment and five minutes after the last button push (i.e., the customer has walked away the demo unit), the DSM250...
Page 48: Figure 22 - Setting The Keyboard Beep Option
Figure 22 – Setting the Keyboard Beep Option 5.2.4.7 Label Each DSM250 can be given a software label. Normally this label will indicate the position of the DSM250 and is used by the Alert System to identify one DSM250 from another.
Page 49: Favorite Screens Mode
® ® 5.2.5 Favorite Screens Mode The DSM250 supports two methods of operation in favorites mode: “Auto”, in which the DSM250 automatically cycles through all favorite screens that have been enabled for Auto mode, and “Manual”, in which the DSM250 continues to display the currently displayed favorite screen until you...
Page 50: Figure 26 -Favorite Screen Parameters
Auto/Manual – this favorite screen is displayed in both Auto and Manual modes 5.2.6.2 Format The DSM250 offers many methods and formats of displaying multiple data items at a given time. This parameter is used to program how many data items will appear on this particular favorite screen and in what sizes these items will appear.
Page 51: Figure 27 - Setting The Favorite Screen Format
In Auto mode, this parameter determines the amount of time this favorite screen is displayed before the DSM250 automatically cycles to the next higher numbered favorite screen in the auto mode. This parameter is programmable to anywhere between 1 second and 180 seconds.
Page 52: Figure 29 - Selecting The Data Category
DSM250 User’s Manual 5.2.6.4 Window Data The Window Data section of the menu allows you to select a particular type of data to be displayed in each part of the screen. Selecting the data to be displayed is a two-step process. First, press the Enter key ( ) and select the category of data to be displayed.
Page 53 You use the instance field to tell the DSM250 which GPS to use for displaying data. Most of the time, the DSM250 simply displays a single parameter from a device on the network so you will only see one “Instance” entry. There are other parameters that the DSM250 displays that are a combination of information from multiple products on the network.
Page 54: Units Menu
NMEA 2000 bus. If the DSM250 is not showing heading or COG (i.e., no needle on compass rose or dashes for digital displays), it’s probably a good indication that variation isn’t available on the network. The DSM250 can’t calculate true heading given magnetic heading from a compass if variation isn’t available.
Page 55 ® ® • Statute Miles 5.2.7.4 Boat Speed This menu item allows you to select the units to be used for the display of all boat speed-related information. Units that may be selected are the following: • Knots • Miles/Hour •...
Page 56 DSM250 User’s Manual • Millimeters Mercury (mm Hg) • kPa 5.2.7.9 Fluid Pressure This menu item allows you to select the units to be used for the display of fluid pressure. Units that may be selected are the following: • Pounds/Square Inch (PSI) •...
Page 57: Device Configuration
Maretron Rudder Angle Adapter (RAA100) – Set rudder number, operating mode, and calibrate rudder position. Maretron Run Indicator Monitor (RIM100) – Set Data Instance for the device, and labels for the device and each channel. Maretron Switch Indicator Monitor (SIM100) – Set Data Instance for the device, and labels for the device and each channel.
Page 58: Figure 32 - Device Configuration Screen
DSM250 User’s Manual Maretron Ultrasonic Wind and Weather Station (WSO100) – set installation offset, set wind ® damping rates, and enable/disable individual NMEA 2000 PGN transmissions. More device types will be included in future firmware releases. In each case, the contents of the Device Configuration menus may vary depending on the version of the firmware within the device.
Page 59: Bennett Ep-30 (Nmea1) Trim Tabs Configuration
® ® Bennett EP-30 (NMEA1) Trim Tabs Configuration This describes the configuration of the Bennett EP-30 trim tabs firmware version 1.0.7 (“NMEA1” NMEA 2000 Trim Tab Indicator Kit). The EP-30 configuration menu is shown below in Figure 33 below, and currently has the single entry “Trim Tabs Calibration…”. Figure 33 –EP-30 Trim Tabs Configuration Screen 6.1.1 Trim Tabs Calibration The Bennett EP-30 (NMEA1) trim tabs calibration opening screen is shown in Figure 34 below.
Page 60: Figure 35 -Ep-30 Intermediate Calibration Screen
DSM250 User’s Manual Figure 35 –EP-30 Intermediate Calibration Screen After you have lowered both trim tabs to their full down position and a few seconds have elapsed, the screen shown in Figure 36 below should appear, indicating that the calibration of the trim tab sensors has completed successfully.
Page 61: Maretron Acm100 Configuration
® ® Maretron ACM100 Configuration This describes the configuration of the Maretron ACM100 firmware version 1.0.6. Figure 37 – ACM100 Configuration Screen 6.2.1 Advanced Configuration Advanced Configuration changes some complex parameters within the device, and should only be performed by an advanced user. Typically advanced configuration is only done at installation and should not need to be done while at sea.
Page 62 DSM250 User’s Manual • Inverse Install • Normal Install Use the Scroll Up and Scroll Down buttons to select the correct option, and then press Enter to save the value. 6.2.1.2 Current Transformer B If you notice that the power measurements of phase B are negative when they should be positive, or vice-versa, then the current transformer has been installed backwards.
Page 63: Ac Circuit Type
The ACM100 Alternating Current transmits a number of the NMEA2000 PGNs which can be turned on or turned off by the DSM250 display. For reasons of compatibility with older NMEA2000 devices, some of these PGNs are redundant; disabling these PGNs will reduce the amount of traffic on the ®...
Page 64: Ac Device Type
DSM250 User’s Manual • Single-Phase (Phase A, B) – use this value when power is connected via two hot wires (180° out of phase with each other) and single neutral wire from a single phase of a transformer (a typical 220VAC connection in the US).
Page 65: Figure 40 - Reset Total Energy Recorded Confirmation Screen
® ® Figure 40 – Reset Total Energy Recorded Confirmation Screen Press Accept to reset the value, or Cancel to return to the previous screen. Revision 1.4.2 Page 51 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 66: Maretron Alm100 Configuration
DSM250 User’s Manual Maretron ALM100 Configuration This describes the configuration of the Maretron ACM100 firmware version 1.0.5. Figure 41 – ALM100 Configuration Screen 6.3.1 Advanced Configuration Advanced Configuration changes some complex parameters within the device, and should only be performed by an advanced user. Typically advanced configuration is only done at installation and should not need to be done while at sea.
Page 67: Instance
® ® installed, for later reference. Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value. 6.3.1.3 NMEA2000 PGN Enable/Disable The ALM100 Annunciator Module transmits the NMEA2000 PGN #130824 which can be turned on or turned off by the DSM250 display.
Page 68: Test Annunciator
DSM250 User’s Manual 6.3.4 Test Annunciator The Annunciator may be tested by scrolling the cursor to highlight this entry and then pressing the Enter button. The ALM100 will emit a single beep. Page 54 Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 69: Maretron Dcm100 Configuration
® ® Maretron DCM100 Configuration This describes the configuration of the Maretron ACM100 firmware version 1.0.4. Figure 44 – DCM100 Configuration Screen 6.4.1 Advanced Configuration Advanced Configuration changes some complex parameters within the device, and should only be performed by an advanced user. Typically advanced configuration is only done at installation and should not need to be done while at sea.
Page 70: Figure 46 -Dcm100 Nmea 2000 Pgn Enable/Disable Screen
The DCM100 Annunciator Module transmits the NMEA2000 PGNs #127506 and 127508 which can be turned on or turned off by the DSM250 display. Pressing the Enter key with “NMEA2000 PGN Enable/Disable…” menu item selected causes the DSM250 to display the following screen.
Page 71: Current Sensor Zero Offset Calibration
® ® 6.4.1.5 Restore Factory Defaults This option restores all settings on the device to their factory default state. 6.4.2 Current Sensor Zero Offset Calibration The DCM100 is shipped with a Hall-effect current sensor. In order to match the DCM100 unit and the sensor to one another and ensure maximum accuracy, you should perform this calibration step while there is no current flowing through the current sensor.
Page 72: Dc Type
DSM250 User’s Manual 6.4.3 DC Type You can configure the DCM100 as to what type of DC power source it is monitoring. With the exception of the “Battery” type, the value of this parameter is used only for reporting the power source type over the NMEA 2000 network.
Page 73 ® ® 6.4.3.6 Charge Efficiency Factor The Charge Efficiency Factor for the battery can be set to a value between 5% and 100%. Please refer to Section 4.6.1 on page 11 for details. 6.4.3.7 Fully Charged Voltage In order for the DCM100 to determine when a battery is fully charged, it uses three parameters. The “Fully Charged Voltage”...
Page 74: Instance
DSM250 User’s Manual 6.4.4 Instance This entry allows you to program the NMEA 2000 device instance for the unit. You usually will not need to modify the default value of “0” unless you have multiple units on the network. 6.4.5 Label A label may be assigned to the DCM100 as an aid to identifying the device over the network.
Page 75: Maretron Dsm200 Configuration
6.5.1 Remote Device Selection ® A DSM250 unit can be used to configure a remote DSM200 to set which NMEA 2000 devices are selected for display on the remote DSM200 unit. In this manner, multiple devices of the same type ®...
Page 76 DSM250 User’s Manual The “NA” column of the menu displays the node address the device is using. The “Manuf.” column of the menu displays the manufacturer of the device. The “Model” column displays the model number of the device. The “SN#” column displays the serial number of the device, so that any of two or more devices of the same manufacturer and model number may be distinguished from one another.
Page 77: Maretron Dsm250 Configuration
A DSM250 unit can be used to configure a remote DSM250 to set which NMEA 2000 devices are selected for display on the remote DSM250 unit. In this manner, multiple devices of the same type ® may be used on a NMEA 2000 network in a fail-safe configuration.
Page 78: Copy Alarms Settings From Local Display
6.6.2 Copy alarms settings from local display It is possible to copy the alarm settings from a DSM250 unit to a remotely located DSM250. This should be done with care because if more than one Alert Source is monitoring the same parameter, then multiple alerts will be generated when the parameter goes out of bounds, and each one will need to be independently accepted or cancelled.
Page 79: Copy Device Selection From Local Display
6.6.3 Copy device selection from local display Since it is normally desirable for all DSM250 units on a network to display the same sensors, it is possible to copy the device selection settings from a DSM250 unit to a remotely located DSM250. In...
Page 80: Copy Dst100 Calibrations From Local Display
DSM250 and that the remote DSM250 must be restarted to complete the operation. Press Enter to restart the remote DSM250 unit, complete the favorite settings transfer operation, and return to the previous menu selection.
Page 81: Copy All Settings From Local Display
Also use this function to copy settings from an old DSM250 to a new DSM250 when replacing the device. 6.6.8 Label The Label of the DSM250 is used by the Alert System to identify the source of an alert. Here, the label can be changed using the method described in section 3.3.4. Revision 1.4.2 Page 67 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 82: Remote Device Selection
DSM250 User’s Manual 6.6.9 Remote Device Selection Page 68 Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 83: Maretron Dst100 Configuration
® ® Maretron DST100 Configuration The DSM250 is capable of configuring Maretron’s DST100 for several different parameters including trip log resetting, transducer depth offset, and speed calibration. This describes the configuration of the Maretron DST100 firmware version 1.0.1. Figure 57 – DST100 Configuration Screen 6.7.1 Advanced Configuration...
Page 84: Clear Speed Calibration
The DST100 speed through water (STW) initial accuracy is significantly affected by the location or placement of the DST100 within the hull. The DSM250 can correct for these inaccuracies using the speed calibration procedure. You calibrate the DSM250 for the DST100 STW by pressing the Enter key ( ) with the “Speed Calibration…”...
Page 85: Transducer Depth Offset
DST100. The DSM250 will then add the measured depth of the water (as seen by the DST100) to the programmed offset value to produce the total water depth. If you are interested in the depth of water beneath the keel, then you should program a negative value equal to the distance between the DST100 and the bottom of the keel.
Page 86: Figure 61 - Resetting The Dst100 Trip Distance Log
“Reset” menu item is selected will complete the operation. Resetting the trip log zeroes the DST100’s trip log such that all displays receive a zeroed value (i.e., you don’t have to perform the operation from other DSM200/DSM250 locations). Figure 61 – Resetting the DST100 Trip Distance Log Page 72 Revision 1.4.2...
Page 87: Maretron Ems100 Configuration
® ® Maretron EMS100 Configuration This describes the configuration of the Maretron EMS100 firmware version 1.2. The EMS100 is configured to match the engine to which it is connected. The EMS100 Configuration changes some complex parameters within the device, and should only be performed by an advanced user.
Page 88: Boost Pressure Sender Type
DSM250 User’s Manual • No Gauge – select this option if there is no boost pressure gauge present. • YANMAR Select the required option using the Scroll Up and Scroll Down keys followed by the Enter key. 6.8.3 Boost Pressure Sender Type The EMS100 comes from the factory preprogrammed with the characteristics of boost pressure senders for supported engines.
Page 89: Drive Trim Sender Offset
® ® 6.8.7 Drive Trim Sender Offset Often, the characteristics of individual drive trim senders vary from their specified values. This setting allows you to apply an offset to the resistance value of the drive trim sender in order to allow you to bring the digital value reported by the EMS100 into agreement with that displayed by the analog gauge.
Page 90: Water Temperature Sender Type
DSM250 User’s Manual you must select the correct type of gauge for this setting in order for the data to be displayed correctly. Valid options are: • No Gauge – select this option if there is no water temperature gauge present.
Page 91 ® ® with the number of flywheel teeth or alternator pulses per revolution for the engine to which the EMS100 is connected. Valid options are: • 0…400 – pulses per revolution Select the required option using the Increase and Decrease keys followed by the Enter key. Revision 1.4.2 Page 77 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 92: Maretron Gps100 Configuration
2.0.1 shown here. The GPS100 has several different programmable parameters that are configurable by the DSM250 display. Normally, it is not necessary to configure the GPS100 although there may be some circumstances where configuration is desirable.
Page 93: Figure 65 - Configuring Antenna Altitude On A Gps100
GPSs on the network, this should be left at zero. 6.9.1.2 GPS Antenna Altitude The DSM250 is capable of setting the antenna altitude on a Maretron GPS100. You can choose this setting by pressing the Enter key ( ) with the “Antenna Altitude:” menu item selected which causes the screen shown in Figure 65 to be displayed.
Page 94: Figure 66 - Configuring Satellite Elevation Mask On A Gps100
6.9.1.4 PDOP Mask The DSM250 is capable of setting the PDOP Mask on a Maretron GPS100. You can choose this setting by pressing the Enter key ( ) with the “PDOP Mask:” menu item selected which causes the screen shown in Figure 67 to be displayed.
Page 95: Figure 68 - Configuring Snr Mask On A Gps100
6.9.1.5 SNR Mask The DSM250 is capable of setting the SNR (Signal to Noise Ratio) Mask on a GPS100. You choose this setting by pressing the Enter key ( ) with the GPS SNR Mask menu item selected which results in the screen shown in Figure 68.
Page 96: Cold Start Gps
Figure 70 – Restoring Factory Defaults on the GPS100 6.9.2 Cold Start GPS The DSM250 is capable of restarting the GPS algorithm on a Maretron GPS100. You can choose this setting by pressing the Enter key ( ) with the “Cold start GPS Engine” menu item selected which Page 82 Revision 1.4.2...
Page 97: Gps Mode Setting
Figure 71 – Performing a Cold Start of the GPS100 6.9.3 GPS Mode Setting The DSM250 is capable of setting the minimum operating mode on a Maretron GPS100. You can choose this setting by pressing the Enter key ( ) with the “GPS Mode:” menu item selected which causes the screen shown in Figure 72 to be displayed.
Page 98: Device Label
See section 3.3.4 for details on how to enter a textual value. 6.9.5 SBAS (WAAS) Enable/Disable The DSM250 is capable of enabling or disabling the SBAS (WAAS) function on a Maretron GPS Antenna/Receiver (GPS100). You can change this setting by pressing the Enter key ( ) with the “SBAS: WAAS,EGNOS,MSAS:”...
Page 99: Maretron J2K100 Configuration
® ® 6.10 Maretron J2K100 Configuration This describes the configuration of the Maretron J2K100 firmware version 1.0.7. The DSM250 is capable of configuring settings for the J1939 to NMEA 2000® Gateway (J2K100). A screenshot of the J2K100 configuration menu is shown in Figure 74 below.
Page 100: Figure 76 - J1939 Diagnostic Messages Configuration
Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value.
Page 101: Device Label
® ® ® Figure 77 – J2K100 NMEA 2000 PGN Enable/Disable Screen You can enable or disable specific transmissions by scrolling through the different transmitted messages and pressing the Enter key ( ) on the message to be configured. Select whether you want the message to be transmitted (“On”) or disabled (“Off”) using the Scroll Up ( or Scroll Down ( ) keys followed by the Enter key (...
Page 102: J1939 Source Address Configuration
DSM250 User’s Manual Use the Scroll Up and Scroll Down keys to change the value to the desired value you wish to use as the engine instance identifier, and then press the Enter key to accept the value and store it within the J2K100.
Page 103: Refresh J1939 Source Address List
® ® 6.10.5 Refresh J1939 source address list The configuration screen for the J2K100 will examine the bus to determine to which devices it can connect. This is presented in a list at the bottom of the screen. To update the list after adding a device, highlight this entry, and press the Enter button.
Page 104 DSM250 User’s Manual Use the Scroll Up ( ) or Scroll Down ( ) keys to change the value to the desired value you wish to use as the engine instance identifier, and then press the Enter key ( ) to accept the value and store it within the J2K100.
Page 105: Maretron Raa100 Configuration
6.11 Maretron RAA100 Configuration This describes the configuration of the Maretron RAA100 firmware version 1.4.9. Maretron RAA100 rudder angle adapters on the network may be configured using the DSM250. The RAA100 configuration menu is shown in Figure 80 below. Figure 80 – RAA100 Configuration Screen 6.11.1...
Page 106: Label
Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value.
Page 107: Rudder Angle Calibration
DSM250. The RAA100 will measure the sender resistance at each point and create a custom calibration map which relates the resistance of the sender with the rudder angle.
Page 108: Figure 83 - Custom Rudder Angle Calibration
Enter key ( ) to confirm your selection and begin the calibration process. Figure 83 shows the DSM250 with the Custom Rudder Calibration menu item highlighted. Figure 83 – Custom Rudder Angle Calibration The first step in the custom rudder angle sender calibration process is to turn the wheel hard over to starboard, and to measure the angle or the rudder (angle from center) with a protractor or other instrument.
Page 109: Figure 85 - Center Rudder Angle Calibration
® ® the RAA100. Figure 85 shows a screenshot of the center rudder calibration screen. You may also press the Abort Key ( ) to end the calibration process. Figure 85 – Center Rudder Angle Calibration The third step in the custom rudder angle sender calibration process is to turn the wheel hard over to port, and to measure the angle or the rudder (angle from center) with a protractor or other instrument.
Page 110: Rudder Number
DSM250 User’s Manual Figure 87 – Custom Rudder Calibration Confirmation Screen 6.11.3.2 Set to American Standard (240-33 ohm) Use the option for rudders using a rudder angle sender with the standard American resistance range (240 ohms at full port 45°, 33 ohms at full starboard 45°).
Page 111: Operating Mode
® ® Figure 88 – Setting the Rudder Number 6.11.5 Operating Mode The RAA100 can be operated in one of two operating modes, depending on the installation. • NMEA 2000 (the only thing that is connected to the resistive sender is the RAA100) •...
Page 112: Gauge Resistance, + To Sender
DSM250 User’s Manual 6.11.6 Gauge Resistance, + to Sender If the desired operating mode is “NMEA 2000 & Analog Gauge”, the two gauge resistances must be programmed (please refer to the RAA100 User’s Manual for details on how to perform these measurements).
Page 113: Figure 91 - Setting The - To Sender Gauge Resistance
® ® Figure 91 – Setting the – to Sender Gauge Resistance Revision 1.4.2 Page 99 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 114: Maretron Rim100 Configuration
This describes the configuration of the Maretron RIM100 firmware version 1.1.1. The DSM250 may be used to configure the channels on the Run Indicator Module (RIM100). After selecting the RIM100 from the list of devices on the network, the following screen will be displayed.
Page 115: Device Label
Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value.
Page 116: Instance
DSM250 User’s Manual 6.12.3 Instance From here the instance used in the data message may be set. 6.12.4 Channel Configuration To configure an individual channel, use the Scroll Up and Scroll Down buttons to highlight the channel, and then press Enter. The following screen will be displayed.
Page 117: Maretron Sim100 Configuration
This describes the configuration of the Maretron SIM100 firmware version 1.1.1. The DSM250 may be used to configure the channels on the Switch Indicator Module (SIM100). After selecting the SIM100 from the list of devices on the network, the following screen will be displayed.
Page 118: Device Label
Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value.
Page 119: Instance
® ® 6.13.3 Instance From here the instance used in the data message may be set. 6.13.4 Channel Configuration To configure an individual channel, use the Scroll Up and Scroll Down buttons to highlight the channel, and then press Enter. The following screen will be displayed. Figure 99 –...
Page 120: Maretron Ssc200 Configuration
This describes the configuration of the Maretron SSC200 firmware version 2.0.11. Nine configurable parameters for the Maretron SSC200 solid state compass may be configured using the Maretron DSM250 display. The Maretron SSC200 configuration menu can be seen in Figure 100 below. Figure 100 –SSC200 Configuration Screen 6.14.1...
Page 121: Figure 102 -Ssc200 Nmea 0183 Settings Screen
Several characteristics of the NMEA 0183 interface of the SSC200 may be programmed using the DSM250 display. This can be used for initial programming of a SSC200 compass even if only the NMEA 0183 interface is to be used after installation is complete. The figure below shows the possible programming options for the NMEA 0183 interface.
Page 122: Figure 103 - Ssc200 Nmea 0183 Sentence/Rate Selection Screen
DSM250 User’s Manual The last line in the menu enables you to program the lifetime of the variation data received by the SSC200. In Figure 103, you can see that the “Variation Time” has been programmed to 5.0 seconds. This means that if the compass has not received magnetic variation for five seconds, it will no longer transmit true heading data, as the variation data it has received is now expired.
Page 123: Installation Offset Calibration
The installation offset (i.e., misalignment of installed SSC200 with vessels center line) may be calibrated using the Maretron DSM250 display. While executing “Installation Offset Calibration”, the vessel must stay still with no pitch and roll because SSC200 will also calibrate pitch and roll at this time.Once the compass is installed, point the vessel at a known heading, and then select the...
Page 124: Inverted Installation Entry
SSC200 can be mounted to the aft side of a bulkhead). If either of these mounting options is used, the DSM250 can be used to inform the SSC200 of this fact so that it can adjust heading, rate or turn, pitch, and roll readings to be corrected accordingly.
Page 125: Label
6.14.5 Magnetic Deviation Calibration The DSM250 is capable of performing magnetic deviation calibration on a Maretron SSC200 solid state compass. The Rate of Turn Offset Calibration (section 6.14.8) should be done before the Deviation Calibration. The first screen (Figure 108) gives instructions for performing the procedure.
Page 126: Magnetic Deviation Status
The SSC200 is capable of transmitting the rate of turn of a vessel. Different applications may require different damping for the rate of turn measurement. The DSM250 may be used to set the damping period for the rate of turn measurement to anywhere between 0.1 seconds and 60 seconds. Figure 111 shows an example of the damping period set to 2 seconds.
Page 127: Rate Of Turn Zero Offset Calibration
Enter key ( ) with the “Rate of Turn Zero Offset Calibration…” menu item selected which causes the DSM250 to display the screen shown in Figure 112. The Rate of Turn Offset Calibration should be done before the Deviation Calibration (section 6.14.5).
Page 128: Figure 113 - Setting Variation Source To Nmea 0183 Or Nmea 2000
DSM250 User’s Manual information regarding the magnetic variation at the current location is required. Please see the SSC200 User’s Manual for more details on the use of magnetic variation by the SSC200 compass. By default, the SSC200 is capable of receiving variation information on either its NMEA 0183 or ®...
Page 129: Figure 115 - Setting Variation Source To Nmea 2000 ® Only
® ® ® Figure 115 below shows the NMEA 2000 source selected. ® Figure 115 – Setting Variation Source to NMEA 2000 Only ® If there is no magnetic variation source available on either the NMEA 2000 or the NMEA 0183 interface, and you wish to display true heading information, you may manually enter a magnetic variation.
Page 130 DSM250 User’s Manual WARNING: Magnetic variation changes as your location on the earth changes; therefore magnetic variation should be adjusted with changes in position. Neither the DSM250 nor the SSC200 will make these changes automatically; they are the responsibility of the user.
Page 131: Maretron Tla100 Configuration
® ® 6.15 Maretron TLA100 Configuration Maretron TLA100 tank level adapters on the network may be configured using the DSM250. This describes the configuration of the Maretron TLA100 firmware version 1.6.14. The TLA100 configuration menu is shown in Figure 117 below.
Page 132: Label
Tools such as Maretron N2KAnalyzer allow you to view these values later. See section 3.3.4 for details on how to enter a textual value.
Page 133: Tank Levels Calibration
® ® To program the tank capacity, use the Scroll Up ( ) or Scroll Down ( ) keys to move the highlighted cursor over the “Tank Capacity:” menu item. Then, press the Enter key ( ) to move the highlight over the numerical tank capacity value.
Page 134: Figure 122 - Performing Custom Calibration Of The Tank Level Adapter
Figure 122 below shows a screenshot of the DSM250 with the Custom Calibration option highlighted. Custom calibration is necessary for non-rectangular tanks and for non-standard values of resistances for tank level senders.
Page 135: Figure 123 - Tank Levels Calibration Capacity Estimation
® ® Figure 123 – Tank Levels Calibration Capacity Estimation The next step in the calibration process is to fill the tank and indicate the volume of fluid in the tank at various points while filling the tank. This process should be started with an empty tank. You only need to indicate two calibration points for a rectangular tank, and can use up to 16 calibration points for a tank with a more complex shape.
Page 136: Figure 125 - Intermediate Level Calibration
DSM250 User’s Manual Figure 125 – Intermediate Level Calibration Once the tank is completely full, instead of pressing the Accept key to store the current calibration point, press the Complete key. This will complete the calibration process and will also adjust the tank capacity to the currently indicated level.
Page 137: Figure 127 - Custom Tank Level Calibration Confirmation Screen
® ® Figure 127 – Custom Tank Level Calibration Confirmation Screen 6.15.4.2 American Standard Sender Calibration If you have a rectangular tank, and a sender with the standard American resistance range (240 ohms full, 33 ohms empty), and you know the capacity of the tank, you can easily calibrate the sender by using the “Set to American Standard (240-33 ohm)”...
Page 138: Tank Number
DSM250 User’s Manual Figure 129 – European Standard Sender Calibration 6.15.5 Tank Number Next, the tank number must be configured. A tank number can have a value between 0 and 15. Each tank of a particular type must have a tank number that is different from all other tanks of the same type.
Page 139: Operating Mode
® ® keys to position the highlighted cursor over “Tank Type:”, then press the Enter key ( ) to move the highlight to the tank type data itself. Now, use the Scroll Up ( ) or Scroll Down ( ) keys to change the tank type data to the type desired.
Page 140: Gauge Resistance, + To Sender
DSM250 User’s Manual Figure 132 – Configuring the Operating Mode 6.15.8 Gauge Resistance, + to Sender If the desired operating mode is “NMEA 2000 & Analog Gauge”, the two gauge resistances must be programmed (please refer to the TLA100 User’s Manual for details on how to perform these measurements).
Page 141: Figure 134 - Configuring The - To Sender Gauge Resistance
® ® To program the - to sender gauge resistance, use the Scroll Up ( ) or Scroll Down ( ) keys to move the highlighted cursor over the “Gauge Resistance, - to Sender:” menu item. Then, press the Enter key ( ) to move the highlight over the numerical resistance value.
Page 142: Maretron Tlm100 Configuration
DSM250 User’s Manual 6.16 Maretron TLM100 Configuration The DSM250 may be used to configure and calibrate the Tank Level Monitor (TLM100 / TLM150 / TLM200). This describes the configuration of firmware version 1.1.4. After selecting the TLM100 from the list of devices on the network, the following screen will be displayed.
Page 143: Label
® ® installed, for later reference. Tools such as Maretron N2KAnalyzer allow you to view these values later. 6.16.1.3 NMEA2000 PGN Enable/Disable The TLM100 Tank Level Module transmits the NMEA2000 PGN #127505 which can be turned on or turned off by the DSM250 display. Pressing the Enter key with “NMEA2000 PGN Enable/Disable…”...
Page 144: Tank Levels Calibration
DSM250 User’s Manual change the value to the desired tank capacity value, and finally, press the Accept key to confirm your selection. Figure 138 – Configuring the Tank Capacity After you have pressed the Accept key, a confirmation screen will appear that warns you that the fluid remaining measurement will change as a result of this change.
Page 145: Figure 140 - Performing Custom Calibration Of The Tank Level Monitor
Figure 122 below shows a screenshot of the DSM250 with the Custom Calibration option highlighted. Custom calibration is necessary for non-rectangular tanks. To perform custom calibration...
Page 146: Figure 142 - Empty Level Calibration
DSM250 User’s Manual The next step in the calibration process is to fill the tank and indicate the volume of fluid in the tank at various points while filling the tank. This process should be started with an empty tank. You only need to indicate two calibration points for a rectangular tank, and can use up to 16 calibration points for a tank with a more complex shape.
Page 147: Figure 144 - Full Level Calibration
® ® Once the tank is completely full, instead of pressing the Accept key to store the current calibration point, press the Complete key. This will complete the calibration process and will also adjust the tank capacity to the currently indicated level. Figure 144 below shows the calibration screen at the last point with the full tank level (and thus the tank capacity) set to 101 gallons.
Page 148: Tank Number
DSM250 User’s Manual Figure 146 – Rectangular Tank Selection The following screen will be displayed. Figure 147- Rectangular Tank Calibration Enter the distance from the face of the TLM100 sensor to the bottom of the tank for the Empty Tank Depth, and the distance from the face of the TLM100 sensor to the top of the liquid when the tank is full for the Full Tank Depth.
Page 149: Maretron Tlm150 Configuration
Reserved-1..Reserved-7 – These values may be used when the contents of the tank does not fit into one of the categories above. 6.17 Maretron TLM150 Configuration The TLM150 is the gasoline version of the TLM100. The configuration of the two devices is the same;...
Page 150: Maretron Tmp100 Configuration
DSM250 User’s Manual 6.19 Maretron TMP100 Configuration Maretron Temperature Modules (TMP100) may be configured using the DSM250. This describes the configuration of the Maretron TMP100 firmware version 1.1.1. The top level of the TMP100 configuration menu is shown below. Figure 148 – TMP100 Configuration Screen 6.19.1...
Page 151: Channel Configuration
The TMP100 Temperature Module transmits a number of the NMEA2000 PGNs which can be turned on or turned off by the DSM250 display. For reasons of compatibility with older NMEA2000 devices, some of these PGNs are redundant; disabling these PGNs will reduce the amount of traffic ®...
Page 152: Device Label
DSM250 User’s Manual Figure 151 – TMP100 Channel Configuration Screen 6.19.2.1 Instance The Data Instance of the Temperature (as sent in PGNs 130311, 130312, and 130823) is set in this field. Use the Increase and Decrease buttons to select the correct instance number, and the press the Enter button to store it.
Page 153: Maretron Usb100 Configuration
® ® 6.20 Maretron USB100 Configuration Maretron USB100 gateways on the network may be configured using the DSM250. This describes the configuration of the Maretron USB100 firmware version 1.8.2. The USB100 configuration menu is shown in Figure 152 below. There is one configurable item for the USB100 and that is “Remote Device Selection…”.
Page 154: Remote Device Selection
This entry allows you to modify the NMEA 2000 installation description text strings. You can enter any information you like here, such as the date the unit was installed, or the location in which it was installed, for later reference. Tools such as Maretron N2KAnalyzer allow you to view these values later.
Page 155 ® ® are satisfied with the state of the “Display” setting, press the Enter key ( ) to accept the setting. The USB100 will retain information on devices that have been removed from the bus or powered down (“Offline”) so that when they are placed back on the bus, they will assume their prior “Display”...
Page 156: Maretron Wso100 Configuration
DSM250 User’s Manual 6.21 Maretron WSO100 Configuration The DSM250 is capable of performing configuration of the WSO100 Wind/Weather Sensor. This describes the configuration of the Maretron WSO100 firmware version 2.0.12. Figure 155 below shows a screenshot of the WSO100 configuration menu.
Page 157: Figure 157 - Wso100 Nmea 2000 Pgn Enable/Disable Screen
The WSO100 Ultrasonic Wind and Weather Station transmits a number of NMEA2000 PGNs which can be turned on or turned off by the DSM250 display. For the vast majority of installations, the factory setting is appropriate, but if it becomes necessary to disable one of the transmitted messages from the WSO100, for instance, if you have a separate thermometer / humidity sensor / barometer on the network, it is possible to do so with the DSM250.Pressing the Enter key with “NMEA2000 PGN...
Page 158: Device Label
DSM250 User’s Manual Disable – The message will not be transmitted Default – The message will be transmitted at its default NMEA2000 rate. 0.5s…5.0s – The message will be transmitted at the interval specified. Select the required option using the Scroll Up and Scroll Down keys followed by the Enter key.
Page 159: Figure 158 - Wso100 Installation Offset Screen
® ® Figure 158 – WSO100 Installation Offset Screen Turn the vessel directly into the wind and motor forward. When you are satisfied that the apparent wind is directly on the bow of the vessel, press the Accept key to set this angle to read 0° apparent wind on the WSO100.
Page 160: Wind Data Damping Period
The WSO100 comes from the factory preset with a damping period of 1.5 seconds, which should be appropriate for most applications. However, you may use the DSM250 to tune the damping period to anywhere between 0.1 seconds and 5.0 seconds if you desire. To do this, use the Scroll Up (...
Page 161: Barometric Pressure
® ® Figure 162 – Setting the Wind Data Damping Period 6.21.5 Barometric Pressure The WSO100 has an internal barometer, which is pre-calibrated before leaving the factory. If the unit requires re-calibrating, then this field allows the entry of the actual pressure. This may be necessary if the vessel is on a lake with an altitude other than sea level, and the user wishes to normalize the barometric pressure to sea level.
Page 162: Outside Temperature
DSM250 User’s Manual Figure 164 – Setting the Outside Humidity Use the Increase and Decrease buttons to select the correct humidity, and the press the Enter button to store it. 6.21.7 Outside Temperature The Temperature sensor is pre-calibrated before leaving the factory, and should not require adjustment.
Page 163: Data Display Types
® ® 7 Data Display Types Anchor Watch Display The Anchor Watch Display is a graphical representation of an Anchor Alert. See section 8.3.7.9 for details on how to set up the Anchor Alert. Figure 166 – Anchor Watch Display Example The display is centered on the position at which the anchor is dropped;...
Page 164: Gauge Display
DSM250 User’s Manual Figure 167 – Compass Rose Display (Course Up) Example Figure 168 – Compass Rose (North Up) Display Gauge Display The gauge display shows the selected data in a graphical format resembling an analog gauge. There is a general gauge format for most types of display, and a specialized rudder gauge display. A full- screen example of a tachometer display can be seen in Figure 169 below.
Page 165: Figure 169 - Gauge Display Example
® ® Figure 169 – Gauge Display Example A full-screen example of the rudder gauge display can be seen in Figure 170 below. Figure 170 – Rudder Angle Gauge Display Example Revision 1.4.2 Page 151 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 166: Gps Status Display
DSM250 User’s Manual GPS Status Display The GPS Status display shows the following data about the selected GPS receiver: • GPS operating mode (2D, 3D, DGPS) • Satellite signal strength (up to 12 satellites) • Satellite azimuth and elevation (up to 12 satellites) •...
Page 167: Rolling Road
The bottom right hand corner shows the units. Rolling Road The DSM250 supports a “Rolling Road”, or navigation highway display. This display repeats transmitted navigation data from a primary navigator, such as a chart plotter or a personal computer running navigation software.
Page 168: Line Graph
DSM250 User’s Manual • SOG (Speed Over Ground) • BTW (Bearing to Waypoint) • DTW (Distance to Waypoint) • VMG (Velocity Made Good) • ETA (Estimated Time of Arrival) • TTG (Time to Go) • XTE (Cross Track Error) • Set •...
Page 169: Weather Display
Figure 175 – Line Graph Display Weather Display The DSM250 supports a single-screen weather display that shows a wide variety of weather-related information. A screen shot of the weather display appears in Figure 176 below. Figure 176 – Weather Display The weather display shows the following information •...
Page 170: Wind Rose
Figure 177 – Wind Rose Display 7.10 Moon Phase Display The DSM250 supports a moon phase display which shows the current phase of the moon at the current location. An example screenshot of the moon phase display appears in Figure 178 below.
Page 171: Trim Tab Display
7.11 Trim Tab Display The DSM250 supports a trim tab display in which the relative positions of the port and starboard trim tabs are displayed on a dual bar graph. A screenshot of the trim tab display appears in Figure 179 below.
Page 172: Tank Gauge Display
7.13 Tank Gauge Display The DSM250 supports a tank level gauge display type which shows percentage of fluid remaining in a tank on an analog gauge with 180° of travel. A screenshot of a tank gauge display showing a fuel tank’s level appears in Figure 181 below.
Page 173: Alerts
An Alert Monitor, the DSM250 monitors the bus for Alert messages from Alert Sources, and displays the remote Alert information on the DSM250’s screen. Operators may accept or cancel the remote Alerts from the buttons on the front of the DSM250, in which case an Alert Command Message is sent back to the Alert Source.
Page 174: Accepting Or Cancelling An Alert
DSM250 User’s Manual Accepting or Cancelling an Alert Active Alerts may be accepted (4.3.2) by the operator to indicate that the operator has taken responsibility for the Alert. Alerts that have been triggered and the cause removed without being accepted by a user must be cleared.
Page 175: Adding An Alert
® ® Pressing the Enter button at this point will Accept or Cancel the Alert. Adding an Alert Alerts are created by selecting the parameter to be monitored (e.g. Depth), and then selecting the type of Alert (e.g. High Alert). Start by going to the Add New Alert entry in the Alert Setup Menu. Figure 183 –...
Page 176: Enable/Disable Control
DSM250 User’s Manual Figure 184 – Part of the Alert Edit Screen This allows the entry of all the alert parameters, which can vary depending on the type of alert chosen. These parameters are: 8.3.1 Enable/Disable Control This allows individual alerts to be enabled or disabled. The decision to disable an Alert must be made very carefully, as it nullifies the purpose for having alerts.
Page 177: Trigger Source
The desired option is selected using the Scroll Up and Scroll Down buttons. 8.3.5 Description This is a textual field that will be displayed on the DSM250 and transmitted to Alert Slave devices. It is intended to describe the alert (e.g. Fire).
Page 178: Figure 185 - High Alert Parameters
DSM250 User’s Manual Figure 185 – High Alert Parameters A high alert is triggered (i.e. becomes an active alert) once an input signal has risen above the High Alert Set Point and the Set Delay time has elapsed. If the Set Delay is set to zero, then the alert is immediately triggered once the input signal rises above the High Alert Set Point.
Page 179: Figure 186 - Trigger Configuration - High Alert
® ® Figure 186 – Trigger Configuration – High Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 180: Figure 187 - Low Alert Parameters
DSM250 User’s Manual Figure 187 – Low Alert Parameters A low alert is triggered (i.e. becomes an active alert) once an input signal has dropped below the Low Alert Set Point and the Set Delay time has elapsed. If the Set Delay is set to zero, then the alert is immediately triggered once the input signal drops below the Low Alert Set Point.
Page 181: Figure 188 - Trigger Configuration - Low Alert
® ® 8.3.7.2.2 Trigger Configuration Figure 188 - Trigger Configuration – Low Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 182: Figure 189 - Trigger Configuration - Data Unavailable Alert
DSM250 User’s Manual Water Temperature parameter, you would then get an alert every time the ignition was switched off and the engine’s ECU stopped transmitting data. 8.3.7.3.1 Trigger Configuration Figure 189 – Trigger Configuration – Data Unavailable Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding.
Page 183: Figure 190 - Trigger Configuration - On Alert
® ® Figure 190 – Trigger Configuration – On Alert Accept Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 184: Figure 191 - Trigger Configuration - Data Unavailable Alert
DSM250 User’s Manual Figure 191 – Trigger Configuration – Data Unavailable Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 185: Figure 193 - Outside Alert Parameters
® ® Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active” state, and annunciators will begin sounding again for that alert.
Page 186: Figure 194 - Trigger Configuration - Outside Radius Alert
DSM250 User’s Manual 8.3.7.7.2 Trigger Configuration – Outside Radius Alert Figure 194 - Trigger Configuration – Outside Radius Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 187: Figure 195 - Trigger Configuration - Inside Radius Alert
® ® 8.3.7.8.1 Trigger Configuration Figure 195 – Trigger Configuration - Inside Radius Alert Re-trigger Period – When you accept an alert, it will change to the “Accepted” state, and annunciators that are sounding for that alert will stop sounding. If the condition which caused the alert remains true after the amount of time in this field, the alert will return to the “Active”...
Page 188: Figure 196 - Trigger Configuration - Gps Quality Alert
DSM250 User’s Manual The Outside Radius Alert and the Anchor Alert are very similar. The Anchor Alert is designed to allow the input of relatively small radius values, and may be displayed graphically through the Anchor Watch Display (section 7.1). The radius of the Outside Radius Alert is specified in either Nautical Miles or Kilometers, while the radius of the Anchor Alert is specified in Feet or Meters.
Page 189: Figure 197 - Direction Alert Parameters
® ® Alert Clear Point – The Alert will be cleared when the quality of the GPS fix, as reported by the GPS becomes better than the value specified in this field. Possible values are the same as the Alert Set Point. Alert Clear Delay –...
Page 190: Figure 198 - Trigger Configuration - Direction Alert
8.3.7.12 Trigger Type is Time Alert The DSM250 can be configured with alerts that go active at a predetermined time, such as an alarm clock. These alerts can also be configured to become active periodically, making them useful for signaling watch changes (for example, every four hours) or as a personnel alarm (making sure a crew member is at the helm every 15 minutes).
Page 191: Local Audible
Alarm would become active again at 9:00, 10:00, and so on. 8.3.8 Local Audible If the Local Audible field is set to Enabled, the speaker internal to the DSM250 will be activated when this Alert is triggered. 8.3.9 Tone If Local Audible is enabled, the tone that is sounded on the DSM250 and the Remote Annunciators can be set here.
Page 192: Remote Annunciators
Note: the DSM250 is limited to working with annunciators with data instance numbers in the range 0- To enable a specific Annunciator, use the Scroll Up and Scroll Down buttons to position the cursor, and then press the Enter button to move to the Tone column.
Page 193: Operating Mode Anchored
8.3.14 Scope Alerts may be constrained to be displayed only on the DSM250 where they are detected. In this case the Alert message is not sent out on the NMEA2000 bus, and other devices will not display the alert, or allow Accepting of Cancelling. The Scope does not affect the generation of Annunciator messages.
Page 194: Editing An Alert
DSM250 User’s Manual Scroll up and down using the Scroll Up and Scroll Down buttons until the alert that must be deleted is highlighted, and press the Enter button. A confirmation message is displayed. Press the Accept button to delete the Alert or the Cancel button to return to the previous screen without deleting the Alert.
Page 195: Setting The Vessel Operating Mode
Setting the Vessel Operating Mode The Vessel Operating Mode must be set on each DSM250. This is a potentially risky operation, in that Alerts that are Active in the existing mode may be ignored in the new Operating Mode. The DSM250 will warn the operator about these Alerts to minimize the risk.
Page 196: Advanced Configuration
Alert Sources that are unmanned, then the warnings would be lost. For this reason, the Vessel Operating mode must be changed at each DSM250 or N2Kview, and those alerts, which would be disabled, noted by the user.
Page 197: Remote Alerts
8.7.1 Remote Alerts The DSM250 may be set up to not respond to Alerts generated by other devices on the bus. This is a global setting and will apply to all Remote Alerts from all other devices. The options here are •...
Page 198: Maintenance
DSM250 User’s Manual 9 Maintenance Regular maintenance is important to ensure continued proper operation of the Maretron DSM250. Perform the following tasks periodically: • Clean the unit with a soft cloth. Do not use chemical cleaners as they may remove paint or markings or may corrode the DSM250 enclosure or seals.
Page 199 ® ® Revision 1.4.2 Page 185 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 200: Troubleshooting
DSM250 will expose the sensitive electronic components to adverse environmental conditions that may render the unit inoperative. Please do not open the DSM250, as this will automatically void the warranty. If service is required, please return the unit to an authorized Maretron service location.
Page 201: Technical Specifications
® ® 11 Technical Specifications Specifications Parameter Value Comment ® NMEA 2000 Level A Highest Level of Certification Standard ® NMEA 2000 DeviceNet Micro-C Industry Standard Waterproof Connector Active Matrix TFT LCD Display Technology Sunlight Readable Display Resolution 320 x 240 Pixels QVGA Resolution Display Viewable Area 117mm W x88 mm H 5.7”...
Page 202 DSM250 User’s Manual Wind Apparent & True Wind Direction and Speed, Ground Referenced Speed and Direction ® NMEA 2000 Parameter Group Numbers (PGNs) Description PGN # PGN Name Default Rate Response to Requested 126464 PGN List (Transmit and Receive) PGNs...
Page 203 ® ® 130576 Small Craft Status Electrical Parameter Value Comment Operating Voltage 9 to 16 Volts DC Voltage Power Consumption <650mA Low Supply, Full Brightness (Maximum) <200mA Nominal Supply, Low Brightness ® Load Equivalence Number NMEA 2000 Spec. (1LEN = 50 mA) (LEN) Reverse Battery Protection Indefinitely...
Page 204 DSM250 User’s Manual Page 190 Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 205: Technical Support
® ® 12 Technical Support If you require technical support for Maretron products, you can reach us in any of the following ways: Telephone: 1-866-550-9100 Fax: 1-602-861-1777 E-mail: support@maretron.com World Wide Web: http://www.maretron.com Mail: Maretron, LLP Attn: Technical Support 9014 N. 23...
Page 206 DSM250 User’s Manual Page 192 Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 207: Installation Template
® ® 13 Installation Template Please check the dimensions before using the following diagram as a template for drilling the mounting holes because the printing process may have distorted the template. Figure 200 – Surface Mounting Template Revision 1.4.2 Page 193 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 208: Figure 201 - Flush Mounting Template
DSM250 User’s Manual Figure 201 – Flush Mounting Template Page 194 Revision 1.4.2 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 209 ® ® Revision 1.4.2 Page 195 www.busse-yachtshop.de | info@busse-yachtshop.de...
Page 210: Maretron (2 Year) Limited Warranty
DSM250 User’s Manual Maretron (2 Year) Limited Warranty Maretron warrants the DSM250 to be free from defects in materials and workmanship for two (2) years from the date of original purchase. If within the applicable period any such products shall be proved to Maretron’s satisfaction to fail to meet the above limited warranty, such products shall be...
Page 211: Revision 1.4.2
® ® To apply for warranty claims, contact Maretron or one of its dealers to describe the problem and determine the appropriate course of action. If a return is necessary, place the product in its original packaging together with proof of purchase and send to an Authorized Maretron Service Location. You are responsible for all shipping and insurance charges.

Maretron DSM250 User Manual

1 General

2 Installation

3 Operating the DSM250

4 Important Concepts

5 Operating Modes

6 Device Configuration

Quick Links

Graphic Display

Need help?

Questions and answers

Related Manuals for Maretron DSM250

Summary of Contents for Maretron DSM250
