  • Page 1 APB-P008 IW/OW Press Conference Audio Distribution Amplifier Owner’s manual...
  • Page 2 Do not open the device or attempt to disassemble the internal parts or modify them in any the outlet, and have the device inspected by qualified AudioPressBox service personnel. way. The device contains no user-serviceable parts. If it should appear to be malfunctioning, •...
  • Page 3 Company names and product names herein are trademarks or registered trademarks of their respective companies. Specifications and descriptions in this owner’s manual are for information purposes only. AudioPressBox reserves the right to change or modify products or specifications at any time without prior notice.
  • Page 4 Dear customer, Thank you for purchasing the AudioPressBox® APB-P008 OW/IW. APB-P008 OW/IW is a passive in wall/on wall design with 1 LINE Input, 8 MIC Outputs. A professional passive press box (Audio Splitter) expander featuring 8 MIC outputs designed for system integrators for fixed installation. Each Output is independet transformer balanced and isolated. It has 1 LINE input (3-pin phoenix connector).
  • Page 5 APB-P008 IW/OW - Front panel (Input section) APB-P008IW 1) MIC level Outputs 2) Line Input Individually transformer isolated outputs with 1 LINE input (3-pin phoenix connector). Mic Output level. 3-Pin XLR balanced output connector. 3) Input Link 1 Link output (3-pin phoenix connector) to...
  • Page 6: Specifications

    Specifications...
  • Page 7: Block Diagram

    Block diagram...
  • Page 8 | web: www.audiopressbox.com MediaTech Central Europe, a.s., Drienova 34, 821 02 Bratislava, Slovak Republic (EU) Tel: +421 2 20 999 700...
