48" ROUND ROCK GRILL, ROTISSERIE & FIRE PIT
FOR SAFE OPERATION, PLEASE READ ALL ASSEMBLY
!
AND OPERATING INSTRUCTIONS BEFORE USE.
READ FIRST!
!
RULES FOR SAFE OPERATION
• THE ROUND ROCK IS FOR OUTDOOR USE ONLY!
• USE THE ROUND ROCK ONLY ON BRICK,
CONCRETE, STONE OR OTHER MASONRY
SURFACES!
• DO NOT USE ON LAWNS, WOODEN DECKS OR
ASPHALT!
• KEEP THE ROUND ROCK AWAY FROM BUILDINGS,
FLAMMABLE ITEMS AND VEHICLES.
• DO NOT USE THE ROUND ROCK UNDER A COVER
OR AWNING.
• THE ROUND ROCK IS FOR ADULT USE ONLY.
• KEEP CHILDREN AND PETS AWAY WHILE IT IS
BEING USED.
• DO NOT MOVE THE ROUND ROCK WHILE IN USE.
• DO NOT LEAVE UNATTENDED AT ANY TIME WHILE
IN USE.
• DO NOT USE IN WINDY CONDITIONS.
• NEVER USE KEROSENE, GASOLINE OR ANY OTHER
FUELS AS A STARTING AGENT.
• BEFORE EACH USE, MAKE SURE THE ROUND
ROCK IS IN GOOD WORKING CONDITION.
• USE CAUTION AFTER THE FIRE HAS BEEN
EXTINGUISHED- SURFACES WILL REMAIN HOT
FOR SOME TIME.
• BE SURE ALL COALS ARE COLD BEFORE
EMPTYING. IF NECESSARY POUR WATER ON
COALS BEFORE MOVING GRILL.
!
FOOD SAFETY
• RAW POULTRY AND MEAT SHOULD BE KEPT
SEPARATE FROM READY TO EAT FOOD.
• USE CLEAN PLATTERS AND UTENSILS FOR
HANDLING COOKED FOODS.
• COOK POULTRY AND MEATS THOROUGHLY TO
KILL BACTERIA.
• USE INSTANT-READ THERMOMETER TO ENSURE
PROPER INTERNAL FOOD TEMPERATURES.
• KEEP PREPARED FOOD AND LEFTOVERS
REFRIGERATED.
• WASH HANDS, UTENSILS AND SURFACES WITH
SOAP AND HOT WATER PRIOR TO AND AFTER
HANDLING RAW POULTRY AND MEATS.
• FOR MORE INFORMATION CALL USDA MEAT AND
POULTRY HOTLINE: 1-800-535-4555 IN
WASHINGTON, DC.
MODEL 590503
ASSEMBLY AND OPERATING INSTRUCTIONS
HOOK
ROTISSERIE
POT
completely assembled with rotisserie, main cooking grill,
accessory grill and pot hook in use
Congratulations on your purchase of the Round Rock Fire Pit and
Grill! At Landmann USA, our goal is to provide products that are
easy to assemble and fun to use. Should you have questions,
issues, a defective part or if you have any questions concerning its
use, please contact us at: grills@landmann-usa.com
-OR-
1-877-3GRILLS (1-877-347-4557) M-F 8-5 Eastern Time
Proof of purchase may be required.
Landmann USA
Cartersville, GA 30120
www.landmann-usa.com
Made in China
© 2008 Landmann USA
®
ACCESSORY GRILL
FIRE PIT
MODEL 590503
Page 1
VER. 1, 9/25/08
MAIN
COOKING
GRILL
