LM12 Series LCD Monitor
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM12 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Partner LM12 Series

  • Page 1 LM12 Series LCD Monitor User Manual...
  • Page 2: Table Of Contents

    2.3 Mounting Options ________________________________________________________________ 5 2.4 Modular Magnetic Card Reader ____________________________________________________ 5 Contents of packing _____________________________________________________ 6 Installation of the LM12 Series Monitor ____________________________________ 6 4.1 Cable Installation ________________________________________________________________ 6 Using the On Screen Display (OSD)________________________________________ 7 5.1 Basic Settings Menu ______________________________________________________________ 8 5.1.1 BRIGHTNESS ______________________________________________________________ 8...
  • Page 3 Technical Data ________________________________________________________ 15 9.1 Mechanical Characteristics _______________________________________________________ 15 9.2 Electronics _____________________________________________________________________ 15 9.3 Display ________________________________________________________________________ 15 9.4 Touch _________________________________________________________________________ 15 9.5 Durability of mechanical bearing parts______________________________________________ 15 9.6 Environmental conditions: ________________________________________________________ 15 9.7 ESD and EMV behavior __________________________________________________________ 16 9.8 Resistance to jamming ___________________________________________________________ 16 10 Safety Instructions _____________________________________________________ 17 11 Further Notices________________________________________________________ 17...
  • Page 4: Lm12 Series Model Number Definition

    LM12 Series Model Number Definition LM12-X X X - X B : Charcoal Housing T : Touchscreen M: Magnetic Card Reader S : Single Back Light D : Double Back Light...
  • Page 5: General Overview

    General Overview Partner Tech is proud to offer the LM12 series LCD monitor. It offers a versatile solution for many types of applications. Options include a resistive touchscreen, magnetic card reader as well as many types of flexible mounting solutions.
  • Page 6: Contents Of Packing

    The following steps are necessary for the device to function properly: Switch the computer OFF. Connect the LM-12 series monitor to the computer. (For best results, set the computers screen resolution to 800x600). Switch your computer and the monitor back ON.
  • Page 7: Using The On Screen Display (Osd)

    Using the On Screen Display (OSD) To adjust the LCD display on the LM12, you will find four buttons centered on the bottom of the housing (figure 1). To initiate the On Screen Display (OSD), press the UP arrow button, you will then see the Basic Settings menu appear (figure 2).
  • Page 8: Basic Settings Menu

    5.1 Basic Settings Menu Figure 3: Basic Settings Menu The following parameters can be set in the Basic Settings menu. 5.1.1 BRIGHTNESS This selection adjusts the screen brightness. Use the + / - buttons to increase or decrease the brightness to a comfortable setting. 5.1.2 CONTRAST This selection adjusts the screen contrast.
  • Page 9: Display Adjust Menu

    5.2 Display Adjust Menu Figure 4: Display Adjust Menu The following parameters can be set in the Display Adjust menu. 5.2.1 H.POSITION This selection adjusts the Horizontal screen position using the + / - buttons. 5.2.2 V.POSTION This selection adjusts the Vertical screen position using the + / - buttons. 5.2.3 CLOCK This selection adjusts the Clock speed using the + / - buttons.
  • Page 10: Auto Tuning

    The factory setting of the monitor is set to produce the best results with a variety of industry standard video cards. To get the best picture quality, under Windows it would be best to use the Shutdown screen when activating the AUTO TUNING menu option.
  • Page 11: Color Control Menu

    5.3 Color Control Menu Figure 5: Color Control Menu The following parameters can be set in the Color Control menu. 5.3.1 USER COLOR MODE This selection allows each of the main color parts of the picture can be adjusted individually. By doing this, the color tone can be adjusted to a comfortable level.
  • Page 12: Others Menu

    5.4 Others Menu Figure 6: Others Menu The following parameters can be set in the Others menu. 5.4.1 OSD H.POSITION This selection adjusts the On Screen Display (OSD) Horizontal menu position using the + / - buttons. 5.4.2 OSD V.POSITION This selection adjusts the On Screen Display (OSD) Vertical menu position using the + / - buttons.
  • Page 13: Driver Installation

    6.1 Touchscreen Important Note: The LM-12 series monitor with touch capability contains an integrated AccuTouch serial controller (E271-2210) communicating at 9600 baud. Normally this is recognized by the setup utility. If not, the adjustment can be made manually by restarting the setup utility. Due to the different video card signals, it may be necessary to re-calibrate the touchscreen each time the LM-12 is moved to other systems.
  • Page 14: Troubleshooting

    Windows because the calibrate button is not active. 8.1 Additional help If you have problems with the connection or the installation of the LM12 series monitor, please contact your distributor or direct to the manufacturer: Partner Tech Corp. Tel: (8862) 2918-8500 Fax: (8862) 2915-3405 www.partner.com.tw...
  • Page 15: Technical Data

    Technical Data 9.1 Mechanical Characteristics Monitor Size: Machine Weight: 9.2 Electronics Vender #1: Power Input: Power Output: Vender #2: Power Input: Power Output: Operating Voltage: Ripple Voltage: Power Consumption: 9.3 Display Type: Size of screen: Brightness: Contrast: Resolution: Colors: Refresh rate (vertical): Durability of backlight: 9.4 Touch...
  • Page 16: Esd And Emv Behavior

    9.7 ESD and EMV behavior CE-sign (see also chapter Statement of confirmation) Perturbing radiation: 9.8 Resistance to jamming The LM12 Series has passed the following tests: 1. Electrostatic discharge according to EN 61000-4-2 (hardness air +,-8KV and contact +, - 4KV) 2.
  • Page 17: Safety Instructions

    This Operator's Manual is exclusively written for the LM12 series monitor. Warranty The manufacturer of the LM12 series monitor guarantees that all products supplied are free from production and material defects. The LM12 series monitor carries a 1 year warranty on all parts . Statement of Confirmation This is to certify that statements of confirmation are available for all different variations of the LM12 series monitor.
  • Page 18: Fcc Warning Statement

    FCC Warning Statement Note: This equipment has been tested and to comply with the limits for Class A or Class B (modular foot) digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
