Assembly — Installing the Light Kit
10
Attaching the light kit assembly to
the light kit mounting plate
CAUTION: Before starting installation, disconnect the power
by turning off the circuit breaker or removing the fuse at the
fuse box. Turning power off using the fan switch is not suf cient
to prevent electric shock.
NOTE: If the light kit could be wobbled by hand, it means the
light kit is not twisted completely till the right position. Keep
twisting the light kit till it could not be wobbled by hand.
While holding the 20W LED light kit (I) under the fan motor
assembly (F), snap together the wire connection plugs (QQ):
White to white
Black to black
Position the notches (RR) in the inner edge of the 20W light
kit assembly (I) so they line up with the tabs (SS) on the outer
of the rim of the light kit mounting plate (TT). Secure it to the
fan by turning the 20W light kit assembly (I) clockwise until
snug.
SS
12
F
TT
QQ
RR
I
