THANK YOU We appreciate the trust and con dence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
The following responsible party designated in FCC §2.909 is turned off at the circuit breaker or fuse box before beginning. responsible for this declaration: Model Number: AK407-MBK, AK407-MWH All wiring must be in accordance with the National Electrical Company Name: TAL INTERNATIONAL CORPORATION Code “ANSI/NFPA 70”...
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material present at time of shipment from the factory for a period of ve years after the date of purchase by the original purchaser.
Page 4
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut 1.5V AAA battery 2-pin extension cord 3-pin extension cord 7 watt LED bulb...
Page 5
Pre-Installation (continued) PACKAGE CONTENTS ON / OFF ON / OFF 6 SPEED BRIGHTNESS BREEZE TIMER SUMMER WINTER FAN DIRECTION HOLD 3 SEC. Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Fan motor assembly Canopy Light kit mounting plate Canopy bottom cover (preassembled) Light kit Hanger ball/downrod assembly Receiver...
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of re, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°...
Assembly Preparing the canopy Preparing the motor Remove the cotter pin (GG) and clevis pin (HH), and loosen Remove the canopy bottom cover (C) from the canopy (B) by the two collar set screws (II) from the motor collar. turning the canopy bottom cover (C) counterclockwise. Take out the set screw (JJ) located in the hanger ball (KK), Remove the mounting bracket (A) from the canopy (B) by lower the hanger ball (KK) and remove the cross pin (LL).
Page 8
Assembly — Hanging the Fan Attaching the mounting bracket to the Hanging the fan on the mounting electrical box bracket WARNING: To reduce the risk of re, electric shock or other WARNING: The tab in the ring must rest in the groove of personal injury, mount the fan only to an outlet box or supporting the hanger ball/downrod assembly (D).
Page 9
Assembly — Hanging the Fan (continued) Making the electrical connections Ground White Black conductor WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts (except for the ground wire). Outlet Box CAUTION: To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
Page 10
Assembly — Hanging the Fan (continued) Attaching the canopy Attaching the canopy bottom cover NOTE: Adjust the canopy mounting screws (FF) as necessary WARNING: Make sure the tab on the mounting bracket (A) until the canopy (B) and canopy bottom cover (C) are snug. properly sits in the groove in the hanger ball (KK) before attaching the canopy (B) to the mounting bracket (A) by turning the canopy housing until it drops into place.
Page 11
Assembly — Installing the Light Kit Attaching the light kit to the Attaching the light kit mounting plate mounting plate and the light bulbs CAUTION: Before starting the installation, disconnect the CAUTION: Before starting the installation, disconnect the power by turning off the circuit breaker or removing the fuse power by turning off the circuit breaker or removing the fuse at the fuse box.
Operation SETTING UP THE TRANSMITTER NOTE: The remote has been pre-paired in the factory for your convenience. NOTE: Batteries will weaken with age and should be replaced before leaking takes place as this will damage the remote control. Dispose of used batteries properly and keep them out of the reach of children.
Page 13
Operation (continued) OPERATING YOUR FAN AND REMOTE CONTROL NOTE: The fan will store the last used speed setting for the next time it is turned on. NOTE: On each start up of your ceiling fan, the fan blades will oscillate back and forth. This is a NORMAL OPERATION for DC motor ceiling fans as they go through a calibration cycle.
Page 14
Operation (continued) INSTALLING THE REMOTE CONTROL HOLDER To install the remote control bracket (TT), remove the two screws holding the switch cover plate (UU). Do not remove the cover plate (UU). Orient the bracket (TT) by lining up the two mounting holes with those on the cover plate (UU).
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically.
Page 16
- Consult the dealer or an experienced radio/TV technician for help. Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m.- 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
