Installation Instructions
Preparation & Installation
16
1
Bottom Panel Screws
2
Locking Tabs
4. Remove bottom panel by: 1)
Removing (2) screws from left and
right sides of bottom panel. 2)
Pulling bottom panel toward front
of liner to release from locking
tabs.
5. Secure 10" round ducting collar
to top of insert by (4) M4 x 6mm
screws.
6. Vertical ducting preparation is
complete. Refer to page 14, step
4 to complete installation.
