ASSEMBLY
PREPARE PISTON
1
INSTALL SMALL O-RING
A
into seal.
INSTALL SEAL
B
onto piston head. Apply food equipment
lubricant to outside of seal.
TIP: Flared end of seal should
face away from piston head.
SLIDE WASHER
C
SLIDE SPRING
D
PREPARE HEAD TUBE
2
OPTIONAL:
A
ADD GAGING COLLAR(S)
Slide collar(s) onto head tube
to reduce portion size.
See page 2 for PORTION CONTROL.
SLIDE LOCKING COLLAR
B
(threaded side down) towards flared
end of head tube.
SLIDE HEAD INSERT
C
(beveled edge first)
into head tube.
TIP: The end
with smaller hole
should go in first.
INSERT PISTON ASSEMBLY
3
into head tube assembly.
INSTALL KNOB
4
Press head tube down to compress
spring and expose piston threads.
Rotate knob clockwise to secure.
Page 6
WASH ALL PARTS PROPERLY
BEFORE EVERY USE.
onto piston.
onto piston
C
See page 3.
A
C
B
D
SET ASIDE
FOR STEP 3
A
B
