Evaluation Board User
Guide
Table 2 Link Options -Setup condition
Link No. Position
LK1 A
LK2 A
LK3 A
LK4 A
LK5 INSERTED
LK6 INSERTED
LK7 A
LK8 INSERTED
LK9 A
LK10 A
LK11 INSERTED
LK12 A
Function
Amplifier negative voltage supplied from on board supply
Amplifier Positive voltage supplied from on board supply
Selected voltage level is VDD to U4-A
VDD sourced from U5
U5 output voltage is 3.0V
VIN Unbiased input impedance is 51Ω
Connected to EVAL-SDP-CB1Z
Biased up signal is available to the input buffer U7-A
Connected to EVAL-SDP-CB1Z
Input signal applied to Buffer U7-A
VIN Unbiased input impedance is 51Ω
Connected to EVAL-SDP-CB1Z
