Evaluation Board User
Guide
than the ability of the existing device, the software will
indicate this and revert to the max Sample frequency.
5. Exit Button. Use this to exit the software. Alternatively, go
to File->Exit
6. BUSY: This LED indicates when a read is in progress from
the EVAL-SDP-CB1Z board.
7. There are four tabs available displaying the data in different
formats, this are listed here and described in more detail
later.
a. Waveform tab
b. Histogram
c. FFT
d. Summary
8. Select the number of samples to analyze.
9. "Sample" : to perform a single capture.
10. "Continous" : to perform a continuous capture from the
ADC. Press a second time to stop sampling
Within any of the Chart panels, the following tools allow user
control of the different chart displays.
Is used for controlling the cursor if present
Is used for zooming in and out.
Is used for panning.
Rev. PrA | Page 15 of 28
UG-xxx-AD7276
