SPECIFICATIONS
HDP2 GATE OPERATOR KIT
© G h o s t C o n t r o l s
®
SPECIFICATIONS
■ Compliance: The operator is system certified to be in compliance
with UL325 Standard, 7th Edition
■ System Operating Voltage: 12 VDC
■ System Battery Type: 12V DC Deep Cycle Marine Battery (not
included) or Battery Box Kit (ABBT2) (not included)
A BATTERY IS REQUIRED.
■ System Current: 1-2 Amps is typical when active.
Standby is 20 milliamps
■ Operator Arm:
Maximum Stroke Distance: 26"
Minimum Stroke Distance: 5.5"
■ Operator Opening Speed: 90 degrees in approximately 15 seconds
■ Maximum Operator Opening Range: 110 degrees
■ Linear Actuator Operating Temperature: -5°F to 160°F
