Ghost Controls HDP2 Installation And Owner's Manual page 11

11
. Swing gate systems must not open into public access
areas or into the road which could cause collision with
a moving vehicle.
12
. Test the gate operator monthly. The gate MUST
reverse on contact with a rigid object or stop when
an object activates the non-contact sensors. After
adjusting the force or the limit of travel, retest the gate
operator. Failure to adjust and retest the gate operator
properly can increase the risk of injury or death.
13
. SEPARATE PEDESTRIAN GATE IS REQUIRED!
14
. Single or dual gate operation based on the size of your
opening, gate specifications, and operator system
capacities.
A. Dual gate operations require trenching across
the driveway so that the power cable for the sec-
ondary gate operator can be buried. (shown in
diagram below)
B. The power cable should always be enclosed
in PVC conduit for protection, including
when buried across the driveway in dual
gate applications.
S Y S T E M O V E R V I E W
15
. Swing direction of gate(s). The image (shown in dia-
gram below) indicates the more common "Pull-to-
Open" installation and the less common "Push-to-
Open" installation.
16.
Wired and Wireless Vehicle Sensors should NOT
be used on properties that contain livestock or
animals. Instead, we recommend using the
Wireless Keypad (AXWK).
17.
SAVE THESE INSTRUCTIONS.
18.
ELECTRIC FENCES: If an electric fence is
installed at or near the automatic gate opener
it can cause the unit to not function correctly.
Pedestrian Gate
