Power Fist 9105388 Quick Start Manual

V1.0
SPECIFICATIONS
Number of Shelves 3
Load Capacity (lb) 330
Capacity per Shelf (lb) 110
Overall Dimensions (in.) 72L x 13-3/4W x 16H
Material Steel
Colour/Finish Black/blue
Mounting Type Wall
Includes Mounting hardware
SAFETY
WARNING! Read and understand all instructions
before using this tool. The operator must follow basic
precautions to reduce the risk of personal injury
and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating
or inspection and maintenance instructions.
1. Use the correct tool for the job. This tool was designed
for a specific function. Do not modify or alter this tool or
use it for an unintended purpose.
2. Operate in a safe work environment.
3. Do not exceed the rated load capacity.
UNPACKING
Remove the parts and accessories from the packaging and
inspect for damage.
Make sure that all items in the parts list are included.
Please read and understand all instructions before use. Retain this manual for future reference.
PARTS BREAKDOWN
PARTS LIST
# DESCRIPTION
Mounting bar
1
Supporting screw
2
Flat washer φ6
3
Plastic dowels
4
Supporting bar
5
Lock nut M8
6
Flat washer φ8
7
8 Bolt M8
TROUBLESHOOTING
Visit a Princess Auto Ltd. location for a solution if the tool
does not function properly or parts are missing. If unable to
do so, have a qualified technician service the tool.
9105388
QTY
2
4
4
4
6
6
6
6
