9027905 Bench Grinder Pedestal Stand V1.0 SPECIFICATIONS Capacity (lb) Table Size (in.) 12-1/2 x 10 Height (in.) Material Steel table and pipe/cast iron base Colour Black Finish Powder coated HAZARD DEFINITIONS Please familiarize yourself with the hazard notices found in this manual. A notice is an alert that there is a possibility of property damage, injury or death if certain instructions are not followed.
V1.0 Bench Grinder Pedestal Stand 9027905 INTRODUCTION This heavy duty cast-iron stand not only provides a dedicated workspace for 6 to 10 in. bench grinders, but also improves the ease of operation. It securely anchors to floors and features pre-drilled slots and holes for easy mounting, a 29-1/2 in.
9027905 Bench Grinder Pedestal Stand V1.0 Do not operate any tool when tired or under the influence of drugs, alcohol or medications. Do not overreach when operating a tool. Proper footing and balance enables better control in unexpected situations. SPECIFIC SAFETY PRECAUTIONS WARNING! DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to the tool safety rules.
V1.0 Bench Grinder Pedestal Stand 9027905 Place the fixed plate (#1) over the support pole. Secure it in place by tightening its 2 set screws. Attach the plastic hanger (#10) to the fixed plate from underneath using the small screw (#11). Ensure the washer is positioned between the hanger and the plate.
9027905 Bench Grinder Pedestal Stand V1.0 PARTS BREAKDOWN PARTS LIST # DESCRIPTION 7 Lock Washer 1 Fixed Plate 8 Hex Nut 2 Coolant Tray 9 Flat Washer 3 Support Pole 10 Plastic Hanger 4 Base 11 Small Screw 5 Hex Key...
Page 7
V1.0 Bench Grinder Pedestal Stand 9027905 Visit www.princessauto.com for more information...
Page 8
9027905 Bench Grinder Pedestal Stand V1.0 For technical questions call 1-800-665-8685...
Page 9
V1,0 9027905 Vous devez lire et comprendre toutes les instructions avant d'utiliser l'appareil. Conservez ce manuel afin de pouvoir le consulter plus tard.
9027905 Socle de meuleuse d’établi V1,0 SPÉCIFICATIONS Capacité (lb) Dimension de la table (po) 12 1/2 x 10 Hauteur (po) Matériau Base en fonte/table et tuyau en acier Couleur Noir Finition À revêtement en poudre DÉFINITIONS DE DANGER Veuillez-vous familiariser avec les avis de danger qui sont présentés dans ce manuel.
V1,0 Socle de meuleuse d’établi 9027905 INTRODUCTION Ce support en fonte robuste procure un espace de travail dédié aux meuleuses d’établi de 6 à 10 po et améliore aussi la facilité d’utilisation. Peut être fixé solidement sur les planchers et comprend des fentes et orifices prépercés qui facilitent le montage, une hauteur hors tout de 29 1/2 po et un...
9027905 Socle de meuleuse d’établi V1,0 Les chaussures antidérapantes sont recommandées pour maintenir la stabilité et l'équilibre au sein de l'environnement de travail. PRÉCAUTIONS PERSONNELLES Gardez le contrôle de l'outil, de vos mouvements et de l'environnement de travail pour éviter les blessures ou le bris de l'outil.
V1,0 Socle de meuleuse d’établi 9027905 ASSEMBLAGE ET INSTALLATION Les numéros de référence entre parenthèses (n 1) se rapportent à la liste de pièces comprise. ASSEMBLAGE DU SUPPORT Placez la base (n 4) sur une surface plane et de niveau.
9027905 Socle de meuleuse d’établi V1,0 SOIN ET ENTRETIEN Entretenez l'outil avec soin. Un outil en bon état sera efficace, plus facile à contrôler et préviendra les problèmes de fonctionnement. Inspectez les composants de l'outil régulièrement. Réparez ou remplacez les composants endommagés ou usés.
V1,0 Socle de meuleuse d’établi 9027905 RÉPARTITION DES PIÈCES LISTE DES PIÈCES DESCRIPTION QTÉ Rondelle-frein Plaque fixe Écrou hexagonal 2 Bac de refroidissement Rondelle plate Poteau de support 10 Crochet en plastique Base 11 Petite vis Clé hexagonale 12 Petite rondelle 6 Boulon hexagonal Visitez www.princessauto.com pour plus d'informations...
Page 16
9027905 Socle de meuleuse d’établi V1,0 En cas de questions techniques, appelez le 1-800-665-8685...
