Excel 11734 Original Operating Instructions page 9

screw (A). To do so, undo the knurled nut on the screw
(A). Turn the screw (A)
cutting depth and then re-tighten the knurled nut on
the screw (A).
·Check the setting by completing a test cut.
SAW DUST BAG
The saw is equipped with a saw dust bag for saw dust
and chips. Slip the sawdust bag onto the connector
along side the transport handle (11).The saw dust bag
can be emptied by means of a zipper at the bottom.
The sawdust bag can be removed in order to connect
the suction hose of a dust extractor (wet and dry
vacuum cleaner or extraction system). The extraction
system is then plugged onto the same position
(suction hose/extraction system is not included in the
scope of this delivery).
CHANGING THE SAW BLADE
·Warning! Before changing the saw blade: Pull out
the power plug!
·Caution! Wear work gloves to prevent injury when
changing the saw blade.
in or out to set the required
·Swing the machine head up wards.
· Loosen the cover plate screw
a Phillips screwdriver. Do not remove this screw
from the tool.
·Lift and hold up the lower blade guard
the threaded blade bolt.
· Press the saw shaft lock
positioning the Allen key on the flange bolt with the
other hand. The saw shaft lock
more than one rotation.
· Now, using a little more force, slacken the flange
screw in the clockwise direction.
· Turn the flange screw right out and remove the
external flange .
·Take the blade (18)
down wards.
· Carefully clean the flange screw, outer flange and
inner flange.
· Fit and fasten the new saw blade
order.
·Important! The cutting angle of the teeth, in other
words the direction of rotation of the saw blade
must coincide with the direction of the arrow on the
housing.
· Check to make sure that all safety devices are
properly mounted and in good working condition
before you begin working with the saw again.
· Important! Every time that you change the saw blade,
check to see that it spins freely in the table insert
both perpendicular and 45° angle settings.
· Important! The work to change and align the saw
blade (18) must be carried out correctly.
TRANSPORT
· Re-tighten the locking screw to secure the turntable
in place.
·Activate the release button (28), press the machine
head downwards and secure with the safety pin (21).
The saw is now locked in its bottom position.
(A) about 2 turns with
(4) to expose
(20) with one hand while
(20) engages after no
of the inner flange and pull out
(18) in reverse
(18)
(6) in
