Excel 11734 Original Operating Instructions page 8

•
Attachments weight: 1.5kg
CROSS CUT 90° AND TURNTABLE 0°
For cutting widths up to approx. 100 mm it is possible
to fix the saw's drag function with the locking screw
(22) for drag guide in rear position. If the cutting width
exceeds 100 mm you must ensure that the locking
screw (22) for drag guide is slackened and that the
machine head (19) can be moved.
·Move the machine head
· Use the handle (1)
(19) and fix it in this position if required (dependent
on the cutting width).
· Place the piece of wood to be cut against the
workpiece stop (15) and on the turntable (25).
·Caution! Lock the material with the clamping device
(13) on the fixed saw table to prevent the material
from moving during the cutting operation.
· Clamp flat material in lying position using the vertical
clamping device.
·Alternatively, clamp flat material which you want to
cut in upright position using the horizontal clamping
device.
· To turn the saw on: push the switch
meanwhile depress and hold the on/off trigger switch
· With the drag guide fixed in place: Use the handle
to move the machine head
pressure downwards until the saw blade
completely cut through the workpiece.
· With the drag guide not fixed in place: Pull the
machine head (19) all the way to the front and then
use the handle (1) to move it downwards steadily and
with light pressure. Now push the machine head
slowly and steadily to the very back until the saw
blade (18) has completely cut through the workpiece.
·When the cutting operation is completed, move the
machine head (19) back to its upper (home) position
and release the On/Off button
Important! The
integral resetting springs
automatically lift the machine head. Do not simply let
go of the handle (1)
machine head (19) to rise slowly, applying slight
counter pressure as it does so.
CROSS CUT 90° AND TURNTABLE 0° - 45°
The crosscut saw can be used to make crosscuts of 0°-
45° to the left and 0° - 45° to the right in relation to
the stop rail.
· Release the turntable
(19) to its upper position.
to push back the machine head
lock(24)
(19) steadily and with light
(2) to turn the saw off.
after cutting, but allow the
(25) by undoing the locking
screw (7)
· Turn the turntable
desired angular setting on the dial
place with the locking screw
positions at angles of - 45°, -30°, -22.5°, -15°, 0°, 15°,
22.5°, 30° and 45°, at which the turntable
clicks into position.
· Re-tighten the locking screw
turntable
·Cut as described
MITER CUT 0°- 45° AND TURNTABLE 0°
The crosscut saw can be used to make miter cuts to
the left of 0°-45° and to the right of 0°-45° in relation
to the work surface.
· If required, dismantle the clamping device
mount on the opposite side of the fixed saw table.
·Move the machine head
·Fasten the turntable
·Cut as described before.
MITER CUT 0°- 45° AND TURNTABLE 0°- 45°
The crosscut saw can be used to make miter cuts to
the left of 0°-45° and to the right of 0°-45° in relation
to the work surface, with simultaneous setting of the
to left
. turntable from 0°-45° to the left or 0°-45° to the right
(2)
in relation to the stop rail (double miter cut).
(1)
· If required, dismantle the clamping device
(18) has mount on the opposite side of the fixed saw table.
·Move the machine head
· Release the turntable
screw (7)
·Use the handle
(19)
angle required.
· Re-tighten the locking
turntable in place.
·Cut as described before.
LIMITING THE CUTTING DEPTH
will
· The cutting depth can be infinitely adjusted using the
& Locker lever (8).
(25) and scale pointer to the
(7).
(25) in place.
before.
(19) to its upper position.
(25) in 0° position.
(19) to its upper position
(25) by undoing the locking
& Locker lever (8).
(1) to adjust the turntable
screw(7)
(26) and lock into
The saw has locking
(25) audibly
(7) to secure the
(13) or
(13) or
(25) to the
to secure the
