16. TEMPERATURE AND ADJUSTMENT

The temperature of the cooled beverage is controlled by an electronic thermostat between 2 °C
and 8 °C.
16.1 Control panel:
1. Main switch
2. Thermostatic scale
3. Temperature adjustment button (each press of the button lowers the temperature of the
beverage)
4. Button to switch the compressor on/off
ATTENTION: If you are using the cooler to cool non-alcoholic beverages, set the thermostat
to no more than level 3. Otherwise, the beverage may freeze in the cooler's tubing and damage
the device.

17. HOW TO WORK WITH SPEED FITTINGS

17.1 Speed Fitting Installation:
Grasp the speed fitting and insert the hose all the way inside the speed fitting body (ca. 20 mm).
19
The end of the hose must be straight so that it plugs fully into the coupling. If the hose will not go
in, moisten the end of the hose.
17.2 Speed Fitting Removal:
Hold the grey ring tight against the body of the speed fitting and pull out the hose.
ATTENTION: If you do not hold the grey ring but pull at the hose, the speed fitting will cut
even deeper into the hose.
ATTENTION: The hoses must not be under pressure during removal.
:
(see Fig. 16.)
Max. temperature of the input beverage
25 °C.
(see Fig. 17.)
:
