Yardistry YM12721 Installation And Operating Instructions Manual

4.27 m (14 ft) octagon gazebo
Hide thumbs

Advertisement

Quick Links

Download this manual
4.27 m (14 ft) OCTAGON GAZEBO
Installation and Operating Instructions – YM12721
YM11924 - Meridian Octagon
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
12' 0"
Revised 12-1-2022
3.658 m
4.267m
(14')
Yardistry – North America
Toll Free Customer Support:
1.888.509.4382
4.267m
info@yardistrystructures.com
12' 0"
(14')
3.658 m
www.yardistrystructures.com
Regular Hours: Mon - Fri, 8:30 am - 5:00
pm EST (excl. holidays)
(For extended hours see our website)
English and French Spoken
Height: 10' 5-5/8" (3.192 m)
Y40000-2721
