3.7m x 4.3m (12.1' x 14.1') WOOD GAZEBO
Installation and Operating Instructions – YM12941Z
Yardistry – North America
Toll Free Customer Support:
1.888.509.4382
info@yardistrystructures.com
www.yardistrystructures.com
Regular Hours: Mon - Fri, 8:30 am - 5:00
pm EST (excl. holidays)
(For extended hours see our website)
English and French Spoken
Y40000-941Z
with ALUMINUM ROOF
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Revised 08-21-2020
HEIGHT:
3.175m / 10'5"
4.29 m
14' 1"
3.69 m
12' 1"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YM12941Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yardistry YM12941Z

Summary of Contents for Yardistry YM12941Z

  • Page 1 3.7m x 4.3m (12.1’ x 14.1’) WOOD GAZEBO with ALUMINUM ROOF Installation and Operating Instructions – YM12941Z HEIGHT: 3.175m / 10’5” IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Revised 08-21-2020 4.29 m 14’ 1” Yardistry – North America Toll Free Customer Support: 1.888.509.4382...
  • Page 2 Wood is NOT flame retardant and will burn. Grills, fire pits and chimineas are a fire hazard if placed too close to a Yardistry structure. Consult user’s manual of the grill, fire pit or chiminea for safe distances from combustible materials.
  • Page 3 Limited Warranty Yardistry warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. In addition, for any product with lumber, all lumber is warranted for five (5) years against rot and decay. This warranty applies to the original owner and registrant and is non-transferable.
  • Page 4 Instructions for Proper Maintenance Your Yardistry structure is designed and constructed of quality materials. As with all outdoor products it will weather and wear. To maximize the enjoyment, safety and life of your structure it is important that you, the owner, properly maintain it.
  • Page 5 Assembly Tips Following are some helpful tips to make the assembly process smooth and efficient. PRE-ASSEMBLIES: (i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc) • Work on a raised, solid and flat surface such as, a table or saw horse. •...
  • Page 6 Permanent Installation Examples Note: It is critically important you start with square, solid and level footings, concrete pad or deck to attach your Pergola Room. We supply Post Mounts with this structure which gives you the flexibility to permanently install your structure to a pre-existing or new wood or concrete surface.
  • Page 7 Permanent Installation Examples cont. Concrete Patio [min. 3.63 m x 4.24 m (11’11” x 13’11”)] with 15.24 cm (6”) clearance on all sides Anchoring Hardware not included Wood Deck [min. 3.63 m x 4.24 m (11’11” x 13’11”)] with 15.24 cm (6”)clearance on all sides Anchoring Hardware not included Post Mount...
  • Page 8 support@yardistrystructures.com...
  • Page 9 support@yardistrystructures.com...
  • Page 10 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 152.4 x 228.6 x 2387.6mm (6 x 9 x 94") 4pc. (851) - 6x9 Post FSC Y70229-851 23.8 x 133.4 x 276.2mm (1-1/2 x 7-1/2 x 39-1/2")
  • Page 11 Part Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 31.8 x 82.6 x 574.7mm (1-1/4 x 3-1/4 x 22-5/8") 31.8 x 82.6 x 1561.3mm (1-1/4 x 3-1/4 x 61-15/32") 2pc.
  • Page 12 Hardware Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 4pc. 4pc. - Long Panel Right 4pc. - Short Panel Left Ridge Cap Short 25.2 (Y01030-129) (Y01030-126) (Y01030-132)
  • Page 13 Hardware Identification ( Dimensions are approximate and are shown to assist in the identification of parts for assembly. Actual dimensions may be smaller or larger. 5/16 x 1-1/2" 24pc. Hex Bolt - (Y07718-312) 12pc. 1/4 x 2-3/4 Hex Bolt - (Y07718-223) 5/16 x 1-1/4"...
  • Page 14 • Please retain this information for future reference. You will need this information if you contact the Consumer Relations Department. PRODUCT NUMBER: YM12941Z CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1) CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2) CARTON I.D.

  • Page 15: Fig. 2.2

    Step 2: Post Assemblies A: At the bottom of one (851) 6 x 9 Post insert two 5/16” T-Nuts on the outside of each long side. (fig. 2.2) B: At the bottom of the same (851) 6 x 9 Post place two Post Mounts tight to the bottom and inside faces on the long sides as shown in fig.
  • Page 16 Step 3: Short Beam Assembly Part 1 A: Connect one (451) Beam Short Left and one (452) Beam Short Right using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in fig. 3.1 and 3.2. B: Connect one (449) Beam Short End to each end of one (450) Beam Short Centre using two 5/16 x 1-1/2”...
  • Page 17 Step 3: Short Beam Assembly Part 2 D: Place one Short Beam L-R Assembly tight to one Short Beam End Assembly so the ends are flush. Match the bolt holes in each (449) Beam Short End with the bolt holes in (451) Beam Short Left and (452) Beam Short Right.
  • Page 18 Step 4: Long Beam Assembly Part 1 A: Connect one (447) Beam Long Left and one (448) Beam Long Right using two 5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in fig. 4.1 and 4.2. B: Connect one (445) Beam Long End to each end of one (446) Beam Long Centre using one 5/16 x 1-1/2”...
  • Page 19 Step 4: Long Beam Assembly Part 2 D: Place one Long Beam Insert in between one Long Beam L-R Assembly and one Long Beam End Assembly then fit tight together so the beam assembly ends are flush. Match the bolt holes and wood screw pilot holes in both beam assemblies and Long Beam Insert.
  • Page 20 Step 5: Frame Assembly and Anchoring Part 1 A: Move your Post Assemblies to the final location. Make sure the ground is flat and level before continuing assembly. Short Beam Fig. 5.1 Assembly B: With one person at each Post stand two complete Post Assemblies.
  • Page 21 Step 5: Frame Assembly and Anchoring Part 2 D: Make sure each corner is square and level then attach Beam Assemblies to Post Assemblies with two 5/16 x 4-3/4” Lag Screws (with 1/4-5/16” large washer) per corner. (fig. 5.4) E: Depending on what you are placing the Gazebo on will determine how you anchor it to that surface. Please refer to pages 6 and 7 for installation examples.
  • Page 22 Step 6: Attach Gussets and Roof Brackets Note: The bevelled ends on each gusset should always face away from the wood it is attaching to. A: Make sure the assembly is still square and level then facing one Long or Short Beam Assembly place one (330) Gusset Right on the right hand side so the top fits tight to the Beam Assembly and the bottom fits tight to the Post Assembly.
  • Page 23 Step 7: Fascia Beam Assemblies A: Tightly connect one (443) Fascia Left and one (444) Fascia Right using one 5/16 x 1-1/2” Hex Bolt (with 5/16” lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in fig. 7.1 and 7.2. Repeat to make a second Fas- cia Beam Assembly.
  • Page 24 Step 8: Small Roof Rafter Assembly Part 1 A: On each side of one (440) Rafter place one (438) Rafter Corner Left and one (439) Rafter Corner Right so the tops and edges are flush then attach with two #8 x 2-1/4” Wood Screws per side. (Fig. 8.1 and 8.2) B: Place Fascia Beam Assembly from Step 7A on the bottom of (438) Rafter Corner Left, (439) Rafter Corner Right and (440) Rafter so the sides are flush then attach with two #8 x 2-1/4”...
  • Page 25 Step 8: Small Roof Rafter Assembly Part 2 D: Place one (337) Strap Short in the notches of (438) Rafter Corner Left, (439) Rafter Corner Right and (440) Rafter so the ends do not overhang the outside edges of the outside boards then attach with six #8 x 1-1/2” Wood Screws.
  • Page 26 Step 9: Attach Roof to Beam Brackets - Small Roof Rafter Assembly A: On the Back of one Small Roof Rafter Assembly, centred and flush to the bottom of (442) Rafter Short Right, (441) Rafter Short Left and (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1” Pan Screw in the bottom hole and one #12 x 1-1/2”...
  • Page 27 Step 10: Large Roof Rafter Assembly Part 1 A: On each side of one (434) Top place one (440) Rafter so the tops and edges are flush then attach with two #8 x 2-1/2” Wood Screws per side. (Fig. 10.1 and 10.2) B: Place Large Fascia Beam Assembly from Step 7B on the bottom of (440) Rafters so the sides are flush and holes are centred on the (440) Rafters then attach with two #8 x 2-1/4”...
  • Page 28 Step 10: Large Roof Rafter Assembly Part 2 D: Beside each (440) Rafter place one (438) Rafter Corner Left and one (439) Rafter Corner Right so the tops and edges are flush and the bottom edges are flush to Large Fascia Beam Assembly then attach with two #8 x 2-1/4”...
  • Page 29 Step 10: Large Roof Rafter Assembly Part 3 F: Place one (430) Strap Short - Large Roof in the notches of (438) Rafter Corner Left, (439) Rafter Corner Right and both (440) Rafters so the ends do not overhang the outside edges of the outside boards then attach with eight #8 x 1-1/2”...
  • Page 30 Step 10: Large Roof Rafter Assembly Part 4 J: Turn Large Roof Rafter Assembly over then attach one (433) Strap Brace to (431) Strap Left - Large Roof and (432) Strap Right - Large Roof with eight #8 x 2-1/4” Wood Screws. Edges are flush. (fig. 10.8 and 10.9) K: Complete Steps F - J for both Large Roof Rafter Assemblies.
  • Page 31 Step 11: Attach Roof to Beam Brackets - Large Roof Rafter Assemblies A: On the Back of both Large Roof Rafter Assemblies, centred and flush to the bottom of (442) Rafter Short Right, (441) Rafter Short Left and both (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1” Pan Screw in the bottom hole and one #12 x 1-1/2”...
  • Page 32 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! HANDLE WITH CARE! Place roofing material on a non-abrasive surface before assembly as it can bend, dent and scratch easily. WARNING – DO NOT OVER TIGHTEN ROOFING SCREWS! Over tightening screws will cause roofing material to crush.
  • Page 33 STOP STOP STOP STOP INSTALLING ROOFING MATERIAL CAUTION! Roofing material may have sharp edges! Wear gloves! BE SURE TO REMOVE ALL PLASTIC COVERING, ON BOTH SIDES OF THE ALUMINUM PANELS AND TRIM, DIRECTLY BEFORE INSTALLING EACH PIECE. (One side is clear and the other is blue, both must be removed.) Example #1 Example #2 Overtightened and Crushed...
  • Page 34 Step 12: Attach Roof Panels - Small Roof Part 1 A: Place one Long Panel Left on the front of one Small Roof Rafter Assembly so it is flush to the side of (438) Rafter Corner Left and a slight overhang at the bottom of the Fascia Beam Assembly. Holes should line up with (440) Rafter.
  • Page 35 Step 12: Attach Roof Panels - Small Roof Part 2 E: Place one Short Panel Left on Small Roof Rafter Assembly so it overlaps the Long Panel Left and it is flush to the sides of (438) Rafter Corner Left and a slight overhang at the bottom of the Fascia Beam Assembly. There should be no overhanging at the corners.

  • Page 36: Table Of Contents

    Step 13: Attach Ridge Clips and Roof Edges - Small Roof A: Place one Roof Edge Left 72.2 and one Roof Edge Right 72.2 on the bottom of each Small Roof Rafter Assembly so the ends are flush with the outside ends of the Fascia Beam Assembly and meet tight in the centre. Attach both Roof Edges with 17 #8 x 1”...

  • Page 37: Flush

    Step 14: Attach Roof Panels - Large Roof Part 1 A: Place one Middle Panel on the front of one Large Roof Rafter Assembly so it slightly overhangs the top of (434) Top and an overhang at the bottom of the Large Fascia Beam Assembly. Holes should line up with (440) Rafter and (430), (431) and (432) Straps (fig.

  • Page 38: Left

    Step 14: Attach Roof Panels - Large Roof Part 2 C: Place one Short Panel Left so it overlaps the Long Panel Left and it is flush to the sides of (438) Rafter Corner Left and one Short Panel Right so it overlaps the Long Panel Right and it is flush to the side of (439) Rafter Corner Right.

  • Page 39: Fig. 14.6

    Step 14: Attach Roof Panels - Large Roof Part 3 F: On one Large Roof Rafter Assembly place one (463) Spacer Top flush to the outside edges and centred on (434) Top then attach with three #8 x 2-1/4” Wood Screws. (fig. 14.5 and 14.6) (463) Fig.

  • Page 40: 4 X Ridge Clip 102.5

    Step 15: Attach Ridge Clips and Roof Edges - Large Roof A: Place one Roof Edge Left 72.2 and one Roof Edge Right 96.2 on the bottom of each Large Roof Rafter Assembly so the ends are flush with the outside ends of the Large Fascia Beam Assembly and meet tight in the centre.
  • Page 41 Step 16: Attach Roof Panels to Frame Part 1 A: From inside the Post Assemblies measure 4’ 11” to mark the centre of each Short Beam Assembly. (fig. 16.1) B: With all four assemblers place one Large Roof Panel Assembly with Roof to Beam Brackets just in front of the Post Assemblies then raise it up so it is centred on the Long Beam Assembly.
  • Page 42 Step 16: Attach Roof Panels to Frame Part 2 C: Lift a Small Roof Panel Assembly with Roof to Beam Brackets over Short Beam Assembly taking care not to drag the panel on the beams. Make sure the middle Roof to Beam Bracket lines up to the centre mark and the Rafter Corners are flush with each other.
  • Page 43 Step 16: Attach Roof Panels to Frame Part 3 E: Lift second Large Roof Panel Assembly with Roof to Beam Brackets over Large Beam Assembly taking care not to drag the panel on the beams then set in place beside the Small Roof Panel Assembly. (fig. 16.6) F: Starting at the bottom and working up connect Large Roof Panel Assembly to Small Roof Panel Assembly through the Rafter Corners with three 1/4 x 2-3/4”...
  • Page 44 Step 17: Roof Peak Assembly A: Insert two Carriage Bolts with Contoured Washers through the top of Peak Cap Long, into Peak Post then Spring Clip. The Spring Clip holds the assembly together. (fig. 17.1) B: Insert one 1/4” Nut into each Peak Loop. Be careful nut is loose and will fall out until attached to Peak Cap Assembly.
  • Page 45 Step 18: Attach Roof Peak to Roof Panels A: Insert Roof Peak Assembly in gap between Large and Small Roof Panels. Peak Cap Long to be lined up with Rafter Corners. (fig. 18.1 and 18.2) B: Insert two Roof Peak Brackets through each Carriage Bolt and attach Peak Loop to Carriage Bolts then twist to tighten loosely.
  • Page 46 Step 19: Attach Final Roof Panel Part 1 A: Lift last Small Roof Panel Assembly (without Roof to Beam Brackets) over Short Beam Assembly taking care not to drag the panel on the beams. Panel fits under the Peak Cap Long, push up on Peak Loop to lift Peak Cap Long.
  • Page 47 Step 19: Attach Final Roof Panel Part 2 Remember to push up centre to assist with alignment. B: Starting at the bottom and working up loosely connect Roof Panel Assemblies through the Rafter Corners with three 1/4 x 2-3/4” Hex Bolts (with two 1/4-5/16” large washers and one 1/4” lock nut) per side. To align bolt holes helper on the centre ladder may have to push up in the centre of the panels and others make sure corners are aligned.
  • Page 48 Step 19: Attach Final Roof Panel Part 3 C: On the Small Roof Rafter Assembly just installed, centred and flush to the bottom of (442) Rafter Short Right, (441) Rafter Short Left and (440) Rafter attach one Roof to Beam Bracket per board with one #8 x 1” Pan Screw in the bottom hole and one #12 x 1-1/2”...

  • Page 49: Wood Screws

    Step 20: Secure Roof Corners A: Make sure middle Roof to Beam Brackets are flush and tight to the Beam Assemblies. Lift in centre if needed. B: From outside the assembly attach Roof Panel Assemblies together at the Fascia Beam Assembly Ends with two #8 x 2-1/2”...
  • Page 50 Step 21: Attach Corner and Beam Caps A: At each corner place one Corner Cap tight to Fascia Assemblies, push up so the bottom is tight to the bottom of the assemblies then attach with four #8 x 3/4” Sheet Metal Screws per Corner Cap. (fig. 21.1 and 21.2) Fig.
  • Page 51 Step 22: Secure Roof to Beam Brackets A: From inside the assembly attach Roof to Beam Brackets to Beam Assemblies with two #12 x 1-1/2” Pan Screw per bracket. (fig. 22.1 and 22.2) Fig. 22.1 Inside View Beam Assembly Fig. 22.2 Roof to Beam Bracket...
  • Page 52 Step 23: Secure Roof Peak Brackets A: Tighten the six screws in Roof Peak Brackets then attach to Corner Rafters in the remaining holes with ten #10 x 1-1/4” Pan Screws. (fig. 23.1) Fig. 23.1 Roof Peak Bracket Rafter Rafter Corner Corner Rafter...
  • Page 53 Step 24: Attach Ridge Caps to Roof Panels A: Slide one Ridge Cap Long 81.5 over the Ridge Clips, with cut end leading, on each corner of the assembly from the bottom up. Slide Ridge Cap Short 25.2 over the Ridge Clips leading with the insert end to push the Ridge Cap Long 81.5 to the top, lifting Peak Cap Long by pushing up the Peak Loop so Ridge Cap Long 81.5s fit under Peak Cap Long.
  • Page 54 Step 25: Attach Tie Wrap Brackets and Ties A: Attach one Tie Wrap Bracket to each end of Fig. 25.1 Large Roof Panel Large Roof one (461) Tie with one #10 x 1-1/4” Pan Screw Panel per bracket using the inside holes. (461) Tie is tight to end of bracket.
  • Page 55 Step 26: Metal Hooks and Plaque Part 1 A: Two 50 mm Hooks are included with this unit for attaching wiring. They can be placed anywhere along the Rafter Corners as needed. Pre-drill with a 1/8” drill bit before installing. (fig.
  • Page 56 Step 26: Metal Hooks and Plaque Part 2 C: Attach Gazebo ID Plaque to a prominent location on your gazebo with two #8 x 1” Pan Screws. This provides warnings concerning safety and important contact information. A tracking number is provided to allow you to get critical information or order replacement parts for this specific model.
  • Page 58 NOTES support@yardistrystructures.com...
  • Page 59 NOTES support@yardistrystructures.com...
  • Page 60 Anglais et français parlés / Inglés y francés hablado À l’attention de: Service à la clientèle Yardistry would like to say “Thank you” for your time and feedback. Yardistry quiere “Agradecerle” por su tiempo y su opinión. Yardistry aimerait vous remercier d’avoir pris le temps de répondre au sondage.
