- Page 1 VT2600 MULTI DISPLAY MST DOCK USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS............INTRODUCTION..............FEATURES................CONTENTS................SYSTEM REQUIREMENTS............ DOCKING STATION PORTS..........DOCKING STATION SETUP..........SUPPORTED RESOLUTIONS..........DRIVER INSTALLATION (Windows)........WINDOWS SETUP............... DRIVER INSTALLATION (macOS) ........DISPLAYLINK MANAGER CONFIGURATION (macOS)..DISPLAY SETTINGS (macOS)..........NOTICE................WARRANTY / SUPPORT............. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Always read the safety instructions carefully. Keep the User Manual for future reference. Keep this equipment away from humidity. If any of the following situations arise, have the equipment checked by a service technician immediately: • The equipment has been exposed to moisture. •... -
Page 4: Introduction
• USB 3.2 Gen 2 10Gbps USB-A / USB-C ports • SD/microSD Card Reader • Gigabit Ethernet • Standard and Nano Kensington Lock Support CONTENTS • VT2600 Multi Display MST Dock • 150W Power Adapter • USB-C to USB-C Cable • User Manual... -
Page 5: System Requirements
SYSTEM REQUIREMENTS Compatible Devices System with USB-C port that supports DisplayPort over USB-C (DP Alt Mode MST) for video or MacBook with USB-C port that supports DisplayPort over USB-C (DP Alt Mode SST) for video For USB-C charging, a system with a USB-C port that supports USB-C Power Delivery 3.0 is required Operating System Windows 11, 10, 8.1, 8, 7 macOS 10.12 or Later... -
Page 6: Docking Station Ports
DOCKING STATION PORTS... - Page 7 DOCKING STATION PORTS (Continued) Port Description 1. USB-C 3.1 Gen 2 Port Connect a USB-C device, supports 10Gbps transfer speeds PD3.0 5V/3A,9V/3A,12V/2A,20V/1.5A; 30W Max 2. USB-A 3.1 Gen 2 Port Connect a USB-A device, supports 10Gbps transfer speeds, up to 7.5W charging 3.
-
Page 8: Docking Station Setup
DOCKING STATION SETUP Connecting Power 1. Plug the power adapter into the 20V DC Power In port on the back of the dock. Connect the other end into a power outlet. Note: Power supply is required for dock operation. - Page 9 DOCKING STATION SETUP (Continued) Connecting Systems 1. Connect the included USB-C cable to the USB-C Host port on the side of the VT2600. Connect the other end to your host laptop, PC or Mac. 2. The VT2600 has high resolution DP and HDMI outputs. Resolutions up to 3840 x 2160 @ 60Hz are supported depending on monitors connected and the host system capabilities.
- Page 10 DOCKING STATION SETUP (Continued) Single Display Setup 1. Connect your monitor to the Display 1 - DisplayPort or HDMI, Display 2 - DisplayPort or Display 3 - HDMI. Note: Display 1, 2 and 3 output video via USB-C DP Alt Mode and will only output video when connected to a host system with this feature.
- Page 11 DOCKING STATION SETUP (Continued) Dual Display Setup 1. Connect display 1 to the Display 1 - DisplayPort or HDMI. 2. Connect display 2 to Display 2 - DisplayPort or Display 3 - HDMI. Note: For best performance connect to Display 1 and Display 2 inputs.
- Page 12 DOCKING STATION SETUP (Continued) Triple Display Setup 1. Connect display 1 to Display 1 DisplayPort or HDMI. 2. Connect display 2 to Display 2 DisplayPort. 3. Connect display 3 to Display 3 HDMI.
-
Page 13: Supported Resolutions
SUPPORTED RESOLUTIONS SINGLE DISPLAY Display Connection DP or HDMI Host System DP 1.2 3840 x 2160 @ 30Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz Host System DP 1.4 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz Host System DP 1.4 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz MST + DSC... - Page 14 SUPPORTED RESOLUTIONS TRIPLE DISPLAY Display Connection DP + DP + HDMI Host System DP 1.2 Host System DP 1.4 Host System DP 1.4 (2) 3840 x 2160 @ 30Hz, (1) 1920 x 1080 @ 60Hz MST + DSC macOS (Intel) 3840 x 2160 @ 30Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz (1 Extended + 2 Cloned) macOS (M1, M2)
-
Page 15: Windows Setup
DISPLAY SETTINGS (Windows) Windows 10 - Display Setup 1. Right Click on any open spot on your desktop and select “Display Settings” Arranging Displays 2. In “Display”, select the desired display that you want to adjust. Click and drag the selected display to your preferred arrangement Extending or Duplicating Displays 3. - Page 16 AUIDO SETUP (Windows) Windows 10 - Audio Setup 1. Right Click on the speaker icon in the lower right corner and select “Open Sound settings” 2. Under the Output menu select 3. Under the Input menu select “Speakers (USB Advanced Audio Device)” “Microphone (USB Advanced Audio Device)”...
-
Page 17: Display Settings (Macos)
DISPLAY SETTINGS (macOS) When a new display is connected to your Mac, it will default to being extended to the right of the main display. To configure the settings for each of your displays, select “Displays” from the “System Preferences” menu. This will open the “Display Preferences”... - Page 18 DISPLAY SETTINGS (macOS Continued) 1. To arrange displays and configure mirrored or extended displays click on the arrangement tab. 2. To move a display, click and drag the display in the arrangements window. 3. To change primary display, click on the small bar on top of the main monitor and drag in onto the monitor you want to be the primary.
- Page 19 Step 2: Disconnect laptop display Why doesn’t my third monitor display when I set the triple display mode? 1. Select the laptop display (“1” is the default display for laptops) and scroll down to A1. Step 1: Selecting the main display “Multiple displays”.
- Page 20 3. Make sure that the resolution values for each Why are my 2K and 4K monitors displaying monitor on “Desktop resolution” and “Active abnormally when I enable dual or triple display signal resolution” match. mode? The resolution of some monitors may not ad- just automatically and the “Active signal resolution”...
- Page 21 What is High Dynamic Range (HDR)? Why does it show “slow charging” on my laptop. High Dynamic Range (HDR) creates much more lifelike experiences by allowing bright Some users may notice that charging status objects such as lights and highlights glinting off shows “slow charging”, this might happen for the shiny objects to be displayed much brighter than following reasons.
-
Page 22: Notice
FCC. Changes or modification to product not expressly approved by VisionTek Products, LLC could void your right to use or operate your product by the FCC. - Page 23 VisionTek’s liability under this warranty, or in connection with any other claim relating to the product, is limited to the repair or replacement, at VisionTek’s option, of the product or portion of the product which is defective in manufacturing material. Warrantee assumes all risk of loss in transit. The returned products shall be the sole property of VisionTek.
- Page 24 UPGRADE YOUR DIGITAL LIFESTYLE FOR MORE INFORMATION, PLEASE VISIT: VISIONTEK.COM Part # 901531 REV03162023...
