Summary of Contents for VisionTek VT2900
- Page 1 VT2900 DUAL SYSTEM DOCK USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS........INTRODUCTION............ FEATURES.............. CONTENTS............SYSTEM REQUIREMENTS........DOCKING STATION PORTS........DOCKING STATION SETUP........KVM SWITCHING..........OPTIONAL ACCESSORIES........SUPPORTED RESOLUTIONS........DISPLAY SETUP WINDOWS......... DISPLAY SETUP macOS........NOTICE..............WARRANTY / SUPPORT........ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Always read the safety instructions carefully. Keep the User Manual for future reference. Keep this equipment away from humidity. If any of the following situations arise, have the equipment checked by a service technician immediately: • The equipment has been exposed to moisture. •... -
Page 4: Introduction
INTRODUCTION Your new VT2900 USB-C KVM Docking Station can connect to any host with Type-C connectors that support DisplayPort over USB-C providing a future-proof docking solution. Connect up to two additional monitors as well as 3 USB Type-A and 2 USB Type-C accessories through a single USB-C cable. -
Page 5: System Requirements
SYSTEM REQUIREMENTS Compatible Devices System with USB-C port that supports DisplayPort over USB-C (DP Alt Mode MST) for video or MacBook with USB-C port that supports DisplayPort over USB-C (DP Alt Mode SST) for video For USB-C charging, a system with a USB-C port that supports USB-C Power Delivery 3.0 is required Operating System Windows 11, 10, 8.1, 8, 7 macOS 10.12 or Later... -
Page 6: Docking Station Ports
DOCKING STATION PORTS... - Page 7 DOCKING STATION PORTS (Continued) Port Description 1. Audio Jack Connect headphones, headset or other devices with 3.5mm connector 2. USB-C Port Connect a USB-C device, supports 5Gb/s transfer speeds, BC 1.2 battery charging up to 7.5W, 2.4A charging on supported Apple devices (12W) 3.
-
Page 8: Docking Station Setup
DOCKING STATION SETUP Connecting Power 1. Plug the power adapter into the DC In port on the back of the dock. Connect the other end into a power outlet. 2. Press and hold the power button until the LED turns on. - Page 9 DOCKING STATION SETUP (Continued) Connecting Systems 1. Connect the included USB-C cable to the PC2 out port on the back of the VT2900. Connect the other end to your host laptop, PC or Mac. 2. The VT2900 has high resolution DP and HDMI outputs. Resolutions up to 3840 x 2160 @ 60Hz are supported depending on how many monitors are connected and the host system capabilities.
- Page 10 DOCKING STATION SETUP (Continued) Optional - Additional System 1. Connect the included USB-C cable to the PC1 out port on the back of the VT2900. Connect the other end to your secondary laptop, PC or Mac. 2. Connect a USB-C Power Supply (5V/1A -- 5V/20A) for USB-C Power Pass-through to PC1.
-
Page 11: Kvm Switching
KVM SWITCHING To switch between connected hosts quick press the Power/Switch button located on the top of the dock. All connected Displays and Accessories will switch between host devices. PC2 is the default host device selected on device startup. OPTIONAL ACCESSORIES Optional - Accessories Connect any additional items such as Keyboard, Mouse, Headset, USB Flash Drive, External Storage, etc. -
Page 12: Supported Resolutions
SUPPORTED RESOLUTIONS SINGLE DISPLAY Display Connection DP or HDMI Host System DP 1.2 HBR2 3840 x 2160 @ 30Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz Host System DP 1.4 HBR3 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz macOS (Intel, M1, M2) 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz DUAL DISPLAY... -
Page 13: Display Setup Windows
DISPLAY SETUP - WINDOWS Windows Users 1. Right Click at any open spot on your desktop and select “Display Settings” 2. In “Display”, select either monitor 1 or monitor 2. Click and drag the selected display to your preferred arrangement 3. -
Page 14: Display Setup Macos
DISPLAY SETUP - macOS macOS Users When a new display is connected to your Mac, it will default to being extended to the right of the main display. To configure the settings for each of your displays, select “Displays” from the “System Preferences”... -
Page 15: Notice
FCC. Changes or modification to product not expressly approved by VisionTek Products, LLC could void your right to use or operate your product by the FCC. -
Page 16: Warranty / Support
VisionTek’s liability under this warranty, or in connection with any other claim relating to the product, is limited to the repair or replacement, at VisionTek’s option, of the product or portion of the product which is defective in manufacturing material. Warrantee assumes all risk of loss in transit. The returned products shall be the sole property of VisionTek.
