DOCKING STATION PORTS (Continued)
Port
1. USB-C 3.1 Gen 2 Port
2. USB-A 3.1 Gen 2 Port
3. USB-A 3.1 Gen 2 Ports
4. SD/microSD Card Reader
5. Audio Jack
6. Power Switch
7. RJ45 Gigabit Ethernet
8. HDMI 1.4 Port (DP Alt Mode)
9. DP 1.4 Port (DP Alt Mode)
10. DP 1.4 Port (DP Alt Mode)
11. HDMI 2.0 Port (DP Alt Mode)
12. USB-C 3.1 Gen 2 Ports
13. 20V DC Power Supply In
14. Kensington Security Slot
15. USB-C Host Upstream Port
*Note: 4K @ 60Hz max single display resolution, maximum resolution dependent on host system
specifications.
Description
Connect a USB-C device, supports 10Gbps transfer speeds
PD3.0 5V/3A,9V/3A,12V/2A,20V/1.5A; 30W Max
Connect a USB-A device, supports 10Gbps transfer speeds, up to 7.5W charging
Connect a USB-A device, supports 10Gbps transfer speeds, up to 4.5W charging
SD 4.0 card reader 312MB/s, microSD 3.0 card reader 104MB/s
Connect headphones, headset or other devices with 3.5mm connector
Power Switch with LED indicator light
Connect a network router or modem at 10/100/1000 Mbps
Display 3 - Connect a display with a HDMI port to stream video up to 4K@30Hz*
Display 2 - Connect a display with a DP port to stream video up to 4K@60Hz*
Display 1 - Connect a display with a DP port to stream video up to 4K@60Hz*
Display 1 - Connect a display with a HDMI port to stream video up to 4K@60Hz*
Connect a USB-C device, supports 10Gbps transfer speeds, up to 7.5W charging
Connect the included 150W 20V/7.5A Power Supply
Attach a standard or nano Kensington Lock to secure docing station
Connect to a laptop or PC, up to 10 Gbps to host, DP Alt Mode Video and USB-C
Power Delivery charging up to 100W
