VisionTek VT2000 User Manual

Multi display mst dock
Hide thumbs
Table of Contents

Advertisement

Quick Links

VT2000 | VT2500 | VT2510
MULTI DISPLAY MST DOCK
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT2000 and is the answer not in the manual?

Questions and answers

Related Manuals for VisionTek VT2000

Summary of Contents for VisionTek VT2000

  • Page 1 VT2000 | VT2500 | VT2510 MULTI DISPLAY MST DOCK USER MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS............INTRODUCTION..............FEATURES................CONTENTS................SYSTEM REQUIREMENTS............ DOCKING STATION PORTS..........DOCKING STATION SETUP..........SUPPORTED RESOLUTIONS..........DISPLAY SETTINGS (Windows).......... AUDIO SETTINGS (Windows)..........DISPLAY SETTINGS (macOS)..........FAQ..................NOTICE................WARRANTY / SUPPORT............

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Always read the safety instructions carefully. Keep the User Manual for future reference. Keep this equipment away from humidity. If any of the following situations arise, have the equipment checked by a service technician immediately: • The equipment has been exposed to moisture. •...

  • Page 4: Introduction

    The VT2000 / VT2500 / VT2510 is built to be slim and light. It allows you to connect additional USB devices and monitors through one convenient USB-C Cable. You can run up to 3 displays at 1920 x 1080 @ 60Hz with the VT2000 / VT250 (depending on the host device).

  • Page 5: Contents

    CONTENTS VT2000 - 901284 VT2500 - 901381 VT2510 - 901551 • VT2000 Multi Display MST Dock • VT2500 Multi Display MST Dock • VT2510 Multi Display MST Dock • USB-C to USB-C Cable • 100W Power Adapter • 100W Power Adapter •...

  • Page 6: Docking Station Ports

    DOCKING STATION PORTS USB 3.0 Micro SD USB-C POWER IN DISPLAYPORT DISPLAYPORT HDMI USB 2.0 USB 2 .0 USB 3.0...
  • Page 7 12. USB-C Host Upstream Port Connect to a laptop or PC, up to 20 Gbps to host, Power Delivery charging up to 85W (VT2000 / VT2500), 100W (VT2510) 13. Kensington Lock Slot Attach a Kensington Lock to secure docing station...

  • Page 8: Docking Station Setup

    Note: Power supply is not required for dock operation. USB-C Power Supply for charging host system via USB-C PD. VT2000 does not include a USB-C Power Adapter, Sold Separately. VT2500 / VT2510 include 100W USB-C Power Adapter. USB-C POWER IN USB 2.0...
  • Page 9 DOCKING STATION SETUP (Continued) Connecting Systems 1. Connect the included USB-C cable to the USB-C Host port on the side of the VT2000 / VT2500 / VT2510. Connect the other end to your host laptop, PC or Mac. 2. The VT2000 / VT2500 / VT2510 has high resolution DP and HDMI outputs. Resolutions up to 3840 x 2160 @ 60Hz are supported depending on monitors connected and the host system capabilities.
  • Page 10 DOCKING STATION SETUP (Continued) Single Display Setup 1. Connect your monitor to the Display A - DisplayPort, Display B - DisplayPort or Display C - HDMI. USB-C POWER IN USB 2.0 USB 2 .0 USB 3.0 DISPLAYPORT DISPLAYPORT HDMI Note: Display A, B and C output video via USB-C DP Alt Mode and will only output video when connected to a host system with this feature.
  • Page 11 DOCKING STATION SETUP (Continued) Dual Display Setup 1. Connect monitor 1 to the Display A DisplayPort. 2. Connect monitor 2 to Display B - DisplayPort or Display C - HDMI USB-C POWER IN DISPLAYPORT DISPLAYPORT HDMI USB 2.0 USB 2 .0 USB 3.0...
  • Page 12 DOCKING STATION SETUP (Continued) Triple Display Setup 1. Connect monitor 1 to Display A DisplayPort. 2. Connect monitor 2 to Display B DisplayPort. 3. Connect monitor 3 to Display C HDMI. USB-C POWER IN USB 2.0 USB 2 .0 USB 3.0 DISPLAYPORT DISPLAYPORT HDMI...

  • Page 13: Supported Resolutions

    SUPPORTED RESOLUTIONS SINGLE DISPLAY Display Connection DP or HDMI Host System DP 1.2 3840 x 2160 @ 30Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz Host System DP 1.4 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz Host System DP 1.4 MST 3840 x 2160 @ 60Hz / 2560 x 1440 @ 60Hz / 1920 x 1080 @ 60Hz macOS (Intel, M1, M2)
  • Page 14 Host System DP 1.2 Host System DP 1.4 Host System DP 1.4 MST VT2000 / VT2500 - (3) 1920 x 1080 @ 60Hz VT2510 - (2) 3840 x 2160 @ 30Hz, (1) 1920 x 1080 @ 60Hz macOS (Intel, M1, M2) Note: In order to extend output to 3 displays and have video output from the host system, host system must have dedicated graphics with support for USB-C DP Alt Mode W/ MST.

  • Page 15: Display Settings (Windows)

    DISPLAY SETTINGS (Windows) Windows 10 - Display Setup 1. Right Click on any open spot on your desktop and select “Display Settings” Arranging Displays 2. In “Display”, select the desired display that you want to adjust. Click and drag the selected display to your preferred arrangement Extending or Duplicating Displays 3.

  • Page 16: Audio Settings (Windows)

    AUDIO SETTINGS (Windows) Windows 10 - Audio Setup 1. Right Click on the speaker icon in the lower right corner and select “Open Sound settings” 2. Under the Output menu select 3. Under the Input menu select “Speakers (USB Advanced Audio Device)” “Microphone (USB Advanced Audio Device)”...

  • Page 17: Display Settings (Macos)

    DISPLAY SETTINGS (macOS) When a new display is connected to your Mac, it will default to being extended to the right of the main display. To configure the settings for each of your displays, select “Displays” from the “System Preferences” menu. This will open the “Display Preferences”...
  • Page 18 DISPLAY SETTINGS (macOS Continued) 1. To arrange displays and configure mirrored or extended displays click on the arrangement tab. 2. To move a display, click and drag the display in the arrangements window. 3. To change primary display, click on the small bar on top of the main monitor and drag in onto the monitor you want to be the primary.

  • Page 19: Faq

    Q1. Why doesn’t my third monitor display when I set the Step 2: Disconnect laptop display triple display mode? 1. Select the laptop display (“1” is the default display for A1. Step 1: Selecting the main display laptops) and scroll down to “Multiple displays”. 2.
  • Page 20 Q2. Why are my 2K and 4K monitors displaying abnormally 3. Make sure that the resolution values for each when I enable dual or triple display mode? monitor on “Desktop resolution” and “Active signal resolution” match. A2. The resolution of some monitors may not adjust automatically and the “Active signal resolution”...
  • Page 21 Q3. What is High Dynamic Range (HDR)? Q4. Why does it show “slow charging” on my laptop. A3. High Dynamic Range (HDR) creates much more lifelike A4. Some users may notice that charging status shows experiences by allowing bright objects such as lights and “slow charging”, this might happen for the following highlights glinting off shiny objects to be displayed much reasons.

  • Page 22: Notice

    FCC. Changes or modification to product not expressly approved by VisionTek Products, LLC could void your right to use or operate your product by the FCC.

  • Page 23: Warranty / Support

    30 days will ONLY receive a 1 year limited warranty. VisionTek’s liability under this warranty, or in connection with any other claim relating to the product, is limited to the repair or replacement, at VisionTek’s option, of the product or portion of the product which is defective in manufacturing material.
  • Page 24 UPGRADE YOUR DIGITAL LIFESTYLE FOR MORE INFORMATION, PLEASE VISIT: VISIONTEK.COM VT2000 - 901284, VT2500 - 901381, VT2510 - 901551 REV12152022...
