VisionTek VT1100 User Manual

Dual display docks
Hide thumbs
Table of Contents

Advertisement

Quick Links

VT1000 / VT1100
DUAL DISPLAY DOCKS
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT1100 and is the answer not in the manual?

Questions and answers

Related Manuals for VisionTek VT1100

Summary of Contents for VisionTek VT1100

  • Page 1 VT1000 / VT1100 DUAL DISPLAY DOCKS USER MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS............INTRODUCTION..............FEATURES................CONTENTS................SYSTEM REQUIREMENTS............ DOCKING STATION PORTS VT1000 / VT1100....SUPPORTED RESOLUTIONS (VT1000)......... SUPPORTED RESOLUTIONS (VT1100)......... DOCKING STATION SETUP..........DRIVER INSTALLATION (Windows)........WINDOWS SETUP............... DRIVER INSTALLATION (macOS) ........DISPLAYLINK MANAGER CONFIGURATION (macOS)..DISPLAY SETTINGS (macOS)..........

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Always read the safety instructions carefully. Keep the User Manual for future reference. Keep this equipment away from humidity. If any of the following situations arise, have the equipment checked by a service technician immediately: • The equipment has been exposed to moisture. •...

  • Page 4: Introduction

    Note: VT1100 - If an HDMI display and a VGA display are connected at the same time, displays will be the cloned. For 2 extended displays connect to DisplayPort + HDMI or DisplayPort + VGA CONTENTS • VT1000 / VT1100 Dual Display Docking Station • AC Power Adapter - 20W • USB 3.0 USB-B to USB-A Cable (1M)

  • Page 5: System Requirements

    SYSTEM REQUIREMENTS Compatible Devices Laptop or Desktop Computer with USB-A 3.0 port DisplayLink USB Graphics Software for Windows Windows 11 (64-bit edition) Windows 10 (32-bit and 64-bit edition) Windows 8.1 Update 2015 (32-bit and 64-bit editions) Windows 8 (32-bit and 64-bit editions) Windows 7 (32-bit and 64-bit editions) DisplayLink USB Graphics Software for macOS macOS 10.12 or later...

  • Page 6: Docking Station Ports Vt1000 / Vt1100

    DOCKING STATION PORTS VT1000 / VT1100...
  • Page 7 DOCKING STATION PORTS (VT1000 / VT1100 Continued) Port Description 1. USB-A Ports Connect a USB-A device, supports 5Gbps transfer speeds 2. Audio Jack Connect headphones, headset or other audio devices with 3.5mm connector 3. Power LED LED Status Light 4. VGA Port (DisplayLink 1) Display 1 - Connect a display with a VGA port to stream video up to 1080p@60Hz 5.

  • Page 8: Supported Resolutions (Vt1000)

    SUPPORTED RESOLUTIONS (VT1000) SINGLE DISPLAY Display Connection Maximum Resolution DisplayPort 1.2 2560 x 1440 @ 60Hz HDMI 1.4 2560 x 1440 @ 60Hz 1920 x 1080 @ 60Hz DUAL DISPLAY Display Connection Maximum Resolution DisplayPort 1.2 2048 x 1152 @ 60Hz HDMI 1.4...

  • Page 9: Supported Resolutions (Vt1100)

    SUPPORTED RESOLUTIONS (VT1100) SINGLE DISPLAY Display Connection Maximum Resolution DisplayPort 1.2 2560 x 1440 @ 60Hz (DisplayLink 2) HDMI 1.4 2560 x 1440 @ 60Hz (DisplayLink 1) 1920 x 1080 @ 60Hz (DisplayLink 1) DUAL DISPLAY Display Connection Maximum Resolution DisplayPort 1.2 2560 x 1440 @ 60Hz (DisplayLink 2)

  • Page 10: Docking Station Setup

    DOCKING STATION SETUP Connecting Power 1. Plug the power adapter into the DC In port on the back of the dock. Connect the other end into a power outlet.
  • Page 11 1. Connect the included USB-B to USB-A cable to the USB-B Host port on the back of the dock. Connect the other end to your host laptop, PC. 2. The VT1000 / VT1100 adds DP, HDMI and VGA outputs to your system. Resolutions up to 1440p @ 60Hz are supported depending on monitors connected.
  • Page 12 DOCKING STATION SETUP (Continued) Single Display Setup 1. Connect your monitor to the Display 1 - HDMI/VGA or Display 2 - DisplayPort.
  • Page 13 DOCKING STATION SETUP (Continued) Dual Display Setup 1. Connect Display 1 to the Display 1 HDMI or VGA 2. Connect Display 2 to the Display 2 DisplayPort. Note: For the VT1100 DisplayLink stream 1, HDMI and VGA are cloned. For 2 independent displays connect Display 1 to HDMI or VGA and Display 2 to DisplayPort.

  • Page 14: Driver Installation (Windows)

    DRIVER INSTALLATION (Windows) Windows Users - Downloading Drivers 1. Download and install the latest DisplayLink software. Select the driver according to your operating system. displaylink.com/downloads Please visit and download the latest drivers. DisplayLink provided drivers are always compatible with the USB Docking Station. 2.
  • Page 15 DRIVER INSTALLATION (Windows Continued) 3. Once the installer begins a window will pop up and verify that your system is compatible with DisplayLink USB graphics. 4. Click “Install” 5. Once the “Finish” button appears the install is complete and your system will may need to reboot.

  • Page 16: Windows Setup

    WINDOWS SETUP Windows 10 - Audio Setup 1. Click the DisplayLink “Icon” in the system tray located in the lower right corner. To set up audio, click “Audio Setup” 2. Under the Playback tab select 3. Under the Recording tab select “Speakers”...
  • Page 17 WINDOWS SETUP (Continued) Windows 10 - Display Setup 1.Click the DisplayLink “Icon” in the system tray located in the lower right corner. To set up Video, click “Video Setup” 2. In “Display”, select the desired display that you want to adjust 3.

  • Page 18: Driver Installation (Macos)

    DRIVER INSTALLATION (macOS) macOS Users - Downloading Drivers 1. Download and install the latest DisplayLink software. Select the driver according to your operating system. displaylink.com/downloads Please visit and download the latest drivers. DisplayLink-provided drivers are always compatible with the USB Docking Station. 2.
  • Page 19 DRIVER INSTALLATION (macOS Continued) 3. Click “Continue” to start the installation process. 4. You may be prompted to input your account pass- word, click “Install Software”. 5. After installation is complete restart your system. Your dock should now be working. If not, make sure the DisplayLink Manager application is running by entering “DisplayLink”...
  • Page 20 DRIVER INSTALLATION (macOS Continued) 6. Navigate to Applications, then open DisplayLink Manager. 7. Click the DisplayLink Manager application icon in the notification area to open the application window. This confirms that the DisplayLink software is installed and running properly.

  • Page 21: Displaylink Manager Configuration (Macos)

    DISPLAYLINK MANAGER CONFIGURATION (macOS) Enable Automatic Launch 1. Select “Launch automatically after login” for the DisplayLink Manager software to start automatically every time you login. Enable Screen Recording 2. For display output using DisplayLink technology, Screen Recording may need to be enabled. Navigate to System Preferences and select Security &...
  • Page 22 DISPLAYLINK MANAGER CONFIGURATION (Continued) 3. Enable “Screen Recording” to allow DisplayLink Manager to capture video data and transmit it over USB to your displays. 3.1. Select the “Privacy” tab. 3.2. Navigate to “Screen Recording” in the list on the left. 3.3.
  • Page 23 DISPLAYLINK MANAGER CONFIGURATION (Continued) 5. This notification will also appear in the DisplayLink Manager window. 6. The permissions will take effect the net time you launch the DisplayLink Manager app. Select “Quit & Reopen” to restart the app. Note: In Catalina 10.15.x select “Sign Out Now” 7.

  • Page 24: Display Settings (Macos)

    DISPLAY SETTINGS (macOS) When a new display is connected to your Mac, it will default to being extended to the right of the main display. To configure the settings for each of your displays, select “Displays” from the “System Preferences” menu. This will open the “Display Preferences”...
  • Page 25 DISPLAY SETTINGS (macOS Continued) 1. To arrange displays and configure mirrored or extended displays click on the arrangement tab. 2. To move a display, click and drag the display in the arrangements window. 3. To change primary display, click on the small bar on top of the main monitor and drag in onto the monitor you want to be the primary.

  • Page 26: Notice

    FCC. Changes or modification to product not expressly approved by VisionTek Products, LLC could void your right to use or operate your product by the FCC.

  • Page 27: Warranty / Support

    VisionTek’s liability under this warranty, or in connection with any other claim relating to the product, is limited to the repair or replacement, at VisionTek’s option, of the product or portion of the product which is defective in manufacturing material. Warrantee assumes all risk of loss in transit. The returned products shall be the sole property of VisionTek.
  • Page 28 UPGRADE YOUR DIGITAL LIFESTYLE FOR MORE INFORMATION, PLEASE VISIT: VISIONTEK.COM VT1000 - 901147, VT1100 - 901693 REV10062023...
