- Page 1 VT5400 THUNDERBOLT™ 4 DOCK USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS lntroduction ................Features ................... Contents .................. Minimum System Requirements ........Docking Station Configuration ........... Windows Setup ..............macOS Setup ................Warranty .................. -
Page 3: Lntroduction
INTRODUCTION Your new Thunderbolt™ 4 Docking Station can connect to any host with Thunderbolt™ 3 or Thunderbolt™ 4 connector. Allowing you to connect up to two additional monitors through a single Thunderbolt™ 4 cable. The VT5400 is compatible with Intel based Mac Systems with Thunderbolt™ 3 and M1 equiped Mac Systems with Thunderbolt™... -
Page 4: Features
FEATURES • Compatible with Thunderbolt™ 4 Laptops and Desktop Computers • Supports 2 displays at resolutions up to 4K (3840 x 2160 @ 60Hz) • Supports Extend and Mirror Display Mode • Supports 5.1 Channel Surround Sound • Combo microphone input and audio output •... -
Page 5: Minimum System Requirements
MINIMUM SYSTEM REQUIREMENTS Computer Port PC With Thunderbolt™ 3 Windows 10 Mac with Thunderbolt™ 3 MacOS 11 Supported Performance System Max Resolution Supported Windows 10, 11 1 x 8K @ 30Hz (Extended) 2 x 4K @ 60Hz (Clonded or Extended) Mac (Intel) 1 x 4K @ 60Hz (Cloned or Extended) 2 x 4K @ 60Hz (Cloned or Extended) -
Page 6: Docking Station Configuration
DOCKING STATION CONFIGURATION Step 1 Connect the power adapter to the VT5400 Docking Station. Connect the Thunderbolt™ 4 cable to the Thunderbolt™ 4 port on the side of the docking station. Plug the other end of the Thunderbolt™ 4 cable into your Laptop/Desktop Computer. Turn on the switch of the VT5400 supply. - Page 7 DOCKING STATION CONFIGURATION (Continued) Step 2 Turn on the laptop, when the system shows the dialogue below please press “OK”. Step 3 When the system shows the below dialogue, please select “Always Connect” and press “OK” to finish the dock setup. VISIONTEK, VT5400...
- Page 8 DOCKING STATION CONFIGURATION (Continued) Step 4 Connect displays and any additional peripherals to the VT5400 Thunderbolt™ 4 Docking Station. Display 1 Display 2 DisplayPort HDMI DisplayPort Cable HDMI Cable (Not Included) (Not Included) Connect to DisplayPort Monitor Connect to HDMI Monitor...
-
Page 9: Windows Setup
WINDOWS SETUP (Audio) Audio setting for Windows 10 Step 1 Click the DisplayLink “Icon” at the lower right corner to set up audio and video, click “Audio setup” Step 2 Step 3 Choose Speaker Choose Microphone... - Page 10 WINDOWS SETUP (Video) Video Setting: Windows 10 Display mode • Click video setup • Select Display and choose Orientation then select Extend desktop to this display.
-
Page 11: Macos Setup
macOS SETUP (MANAGING MULTIPILE DISPLAYS) When a new display is connected to your Mac, it will default to being extended to the right of the main display. To configure the settings for each of your displays, select “Displays” from the “System Preferences” menu. - Page 12 macOS SETUP (MANAGING MULTIPILE DISPLAYS) To arrange displays and configure mirrored or extended displays click on the arrangement tab. To move a display, click and drag the display in the arrangements window. To change primary display, click on the small bar on top of the main monitor and drag in onto the monitor you want to be the primary.
- Page 13 macOS SETUP (CONFIGURING DISPLAYS FROM THE MENU BAR) If you have checked the “Show Displays” ON menu bar in “Display Preferences” then you can configure the displays by clicking the display icon in the menu bar. This menu allows you to perform the following actions: Detect all displays connected to the Mac Turn display mirroring on/off Set the resolution of both the primary display, and the additional display(s)
-
Page 14: Warranty
VisionTek’s liability under this warranty, or in connection with any other claim relating to the Product, is limited to the repair or replacement, at VisionTek’s option, of the product or portion of the product which is defective in manufacturing material. Warrantee assumes all risk of loss in transit. The returned products shall be the sole property of VisionTek.
