BLACKPOINT S44 Steven - Rechargeable Speaker Manual

FEATURES

Wireless BT connection
TWS-True wireless stereo
Led lights effects
Wired microphone
FM radio
USB/TF card
Rechargeable battery
Wired Microphone 30W power output

SPECIFICATIONS

Tweeter Unit: 1"
Subwoofer Unit: 12" AUX in
Lithium battery: 2000mAH

CONTROL PANEL FUNCTIONS

1. POWER JACK: iram adaptor plug in
2. MIC. INPUT: microphone plug in
3. VOLUME POWER: it is power on/off and control the sound volume.
4. AUX IN: it is a Aux input
5. MODE (LED SW): it can change the mode in BT/AUX/FM press and hold to control the light on/off
6. CH+ press it to go previous songgo to next song press and hold to decrease the volume
7. SCAN/TWS press it to play and pause the music in FM mode, press it to autosearching the radio station.
8. CH+ press it to go to next song press and hold to increase the volume
9. DISPLAY: it display the mode

11. USB: it is a USB slot
12. MIC VOL: it is control microphone volume
13. ECHO: it is control volume of microphone echo.

TWS/ TRUE WIRELESS STEREO

Use mobile to connect any one of speaker S44 Steven by BT wireless connection (it is Main Unit), then find another S44Steven speaker and start BT wireless function and then press this button " SCAN/TWS" from Main unit that it has a B sound. The main unit will be autosearching to another speaker (second unit), then both speaker can be connected by TWS function.

Disconnection
Take the second unit, then press this button " SCAN/ TWS" again, the TWS can be disconnected.
Next time when you turn on the main unit and second unit again, the TWS function will be automatically connected.

Note:
It is recommended to regulate the listening volume from the linked BT device (cellphone, etc), kepping the volume of each speaker to the maxiumun.
