- Page 1 INITIO WALL HUNG WC FRAME 290820 A_05/2020 BS 1212-4 COMPLIANT www.wirquin.co.uk...
- Page 2 IMPORTANT INFORMATION - PRIOR TO INSTALLATION OF THE WC FRAME Read the instructions carefully. Ensure product contents are complete. Check the product for any signs of damage It is recommended that a technically competent installer undertakes installation. It is the installer’s responsibility to carry out a thorough assessment of the installation environment (i.e.
- Page 3 COMPONENTS Component Description 0.8m Frame 1m Frame Inlet Valve Flush Valve 90 ° WC Pan Connector WC Pan Connector Bracket Straight WC Pan Connector Flushpipe Flushpipe Bungs Push Plate Clips Push Plate Bracket Push Plate Cable Connector Chrome Push Plate Wall Brackets Wall &...
- Page 4 COMPONENTS - 0.8M FRAME...
- Page 5 COMPONENTS - 1M FRAME...
-
Page 6: Height Adjustment
click ! HEIGHT ADJUSTMENT... - Page 7 WC PAN CONNECTOR INSTALLATION click ! 1h30 1h00 30 mn 15 mn 10 mn click ! Secure the pan connector into the bracket...
- Page 8 WALL & FLOOR FIXINGS click ! P Q R M N O 1h30 1h00 30 mn 15 mn 10 mn click !
-
Page 9: Water Feed
WATER FEED The water feed can be positioned either top, back or side A flow restrictor is supplied and should only be fitted when the water supply is mains fed. Ensure all pipework is clear of debris before connecting the water supply. OPTIONAL - FLOW RESTRICTOR... - Page 10 WC PAN FIXINGS Define required wc pan centres (180mm or 230mm) by measuring the distance on the back of the pan. 1h30 1h00 30 mn 15 mn 10 mn 1h30 1h00 30 mn 15 mn click ! +20mm 1h30 1h00 30 mn 15 mn Thickness...
-
Page 11: First Fix
FIRST FIX 1h30 1h00 30 mn 15 mn 10 mn click ! 171 mm 180mm/230mm 120 mm Ø60mm Ø139 mm... - Page 12 FLUSHPIPE / WC PAN CONNECTOR INSTALLATION click ! 0.8m Frame 1m Frame 0.8m Frame 1m Frame 1m Frame 0 mn 1h30 1h00 30 mn 23 mm MIN 0.8m Frame 26 mm MAX 0.8m Frame click ! 1h30 1h00 30 mn 15 mn 10 mn click !
- Page 13 PAN INSTALLATION 1h30 1h00 30 mn 15 mn 0.8m Frame 1m Frame 1h30 1h00 30 mn 15 mn 10 mn DOWN click...
- Page 14 FINAL COMISSIONING click ! ATTENTION Ensure the divertor is positioned to allow the Check that the inlet valve shuts off on the water discharged water a clear unobstructed passage line indicated inside the cistern. If adjustment into the cistern. is needed, move the float up or down the notched stem as required until the inlet shuts off on the water line indicated.
- Page 15 PUSH PLATE INSTALLATION 1h30 1h00 30 mn 15 mn 10 mn click ! 1h30 1h00 1h30 1h00 30 mn 15 mn 10 mn 1h30 1h00 30 mn 15 mn 10 mn 1h30 1h00 30 mn 15 mn 10 mn click ! click ! click ! 1h30...
- Page 16 ! click ! HELPLINE Should you require any technical help in association with your Wirquin products, please call our customer service number 0333 222 44 88 with your query. WARRANTY: 10 Years For more detail on warranty information, please visit our website: www.wirquin.co.uk WIRQUIN Ltd | Warmsworth Halt Ind Est | Warmsworth | Doncaster | DN4 9LS www.wirquin.co.uk...
