SAFETY
Step Two
About this Manual:
PLEASE READ THE ENTIRE MANU-
AL PRIOR TO INSTALLING OR USING THIS PRODUCT. This
manual includes information on the LI42-1001 Multi-channel level
indicator from FLOWLINE. Please refer to the part number locat-
ed on the indicator label to verify the exact model configuration
which you have purchased.
User's Responsibility for Safety:
tures a broad range of level sensing technologies. While each of
these sensors is designed to operate in a wide variety of applica-
tions, it is the user's responsibility to select a sensor model that is
appropriate for the application, install it properly, perform tests of
the installed system, and maintain all components. The failure to
do so could result in property damage or serious injury.
Proper Installation and Handling:
staff should install and/or repair this product. Always check for
leaks prior to system start-up.
Wiring and Electrical:
used to power the LI42-1001 indicator. The sensor circuit should
never exceed a maximum of 24 volts DC. Electrical wiring of the
sensor should be performed in accordance with all applicable
national, state, and local codes.
Material Compatibility:
a flame retardant Polycarbonate (PC/ABS FR). Make sure that the
model which you have selected is chemically compatible with the
application media.
Enclosure:
While the indicator housing is liquid-resistant the
LI42-1001 is not designed to be immersed. Make sure that the indi-
cator is mounted in an appropriate location such that under normal
operating conditions, it cannot come into contact with the applica-
tion media.
Make a Fail-Safe System:
accommodates the possibility of indicator and/or power failure.
FLOWLINE recommends the use of redundant backup systems
and alarms in addition to the primary system.
Flammable, Explosive or Hazardous Applications:
The LI42-1001 should not be used within classified hazardous
environments.
Electrical wiring should be performed in accordance with
applicable national, state, and local codes. Only properly trained
personnel should install or repair this product.
Spec Tech Industrial Electric
FLOWLINE manufac-
Only properly trained
A supply voltage of 12-24 VDC is
The LI42-1001 indicator is made of
Design a fail-safe system that
Warning
www.spectechind.com
OVERVIEW
Step Three
A. Application:
cator reads 0-100% of span with TWO level transmitter input
channels. A single push button allows users to scroll through
active channels. The compact NEMA 4X enclosure supports
panel and wall mount installations.
B. Part Number:
the back of the indicator. To access the label, remove the lock-
ing nut and separate the mounting bracket from the indicator.
Check the part number on the product label and confirm which
of the below model configurations you have purchased:
Part Number
LI42-1001
LI44-1001
Mounting
Plate
Locking
Nut
C. MicroCal Calibration Kit:
MicroCal PC calibration kit (purchased separately), users can
greatly expand the indicators functionality to customize engi-
neering units, configure FET alarm set points from level trans-
mitter, level switch or leak detection switch inputs, and/or lin-
earize the volumetric measurement of odd shaped tanks. Each
kit includes (1) PC Windows® based MicroCal software CD and
(1) USB to RS485 adapter with 1m cable.
Sensor Calibration Appliation
Application
File Name
Device
LI44
Channel Calibration
Inches
0.0
1.8
3.6
7.1
8.9
10.7
14.3
17.9
19.6
21.4
25.0
26.8
28.6
32.1
33.9
35.7
