FlowLine LI25 Series Quick Start Manual

Loop-powered meter
Hide thumbs Also See for LI25 Series:

Advertisement

Quick Links

Spec Tech Industrial Electric
QS301034 Rev. B
©2010 Flowline, Inc.
All Rights Reserved
Made in USA

Welcome to the LI25 Quick Start

The LI25 Quick Start is meant to show some of the more common setup solutions to getting the LI25 up and running
quickly. If you run into an issue that is not addressed here or wish to install or set up with a non-standard
configuration, please address the LI25 Manual or refer to the Flowline website at www.flowline.com.
Spec Tech Industrial Electric
www.spectechind.com
Model: LI25
Loop-Powered Meter

Quick Start

www.spectechind.com
10500 Humbolt Street, Los Alamitos, CA 90720 USA
Tel: 562.598.3015
Fax: 562.431.8507
888-773-2832
www.flowline.com
1 |
888-773-2832
P a g e
Model: LU8
Ec

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LI25 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for FlowLine LI25 Series

  • Page 1: Quick Start

    If you run into an issue that is not addressed here or wish to install or set up with a non-standard configuration, please address the LI25 Manual or refer to the Flowline website at www.flowline.com. P a g e...
  • Page 2: Ordering Information

    We Do Your Level Best Thank you for purchasing Loop-Powered Meter (LI25). The LI25 Series is a multipurpose, easy to use digital process meter ideal for level, flow rate, temperature, or pressure transmitter applications. It accepts current and voltage signals (e.g. 4-20 mA, 0-10 V) and has three front panel buttons that can be programmed for specific operation.
  • Page 3: Front Panel Operation

    Spec Tech Industrial Electric www.spectechind.com 888-773-2832 Connections Signal connections are made via a removal, four-terminal connector. This section is intended for the LI25-1001 only. LI25-2001 LI25 Rear Panel installation must be performed in accordance with Control Drawing QS301034-1 in order to meet agency approval. Observe all safety regulations.
  • Page 4 Decide on units of measure The LI25 series can show level (ex. inches, centimeters, feet, meters, etc) or Volume (gallons, liters, etc.) or any other engineering units. Please determine the units of operation that you want to appear on the display. This will give you a set point for the environment you are measuring.
  • Page 5 Spec Tech Industrial Electric www.spectechind.com 888-773-2832 To set the decimal point: Press the MENU button to bring up the Setup screen. Press the ACK button to bring up the decPT screen. Press the ACK button and the decimal point display screen will appear as “dd.ddd”.
  • Page 6 Spec Tech Industrial Electric www.spectechind.com 888-773-2832 To set the SCALE function: Press the MENU button to bring up the programming menu. Press the Up Arrow/Max to scroll through the Menu options until you reach ProG. Press the ACK button to enter ProG and SCALE will appear. Press the ACK button and Input I (Inpt1) will appear.
  • Page 7 Spec Tech Industrial Electric www.spectechind.com 888-773-2832 To set the units in the display: Press the MENU button to bring up the Setup screen. Press the ACK button to bring up the dec PT screen. Press the Up Arrow/Max to bring up the units screen. Then, press the ACK button. The following screen allows you to set a three-digit representation of the units in which you’re measuring your environment, as shown above.
  • Page 8 Flowline where: 1) there is evidence of a potentially hazardous material present with the product; or 2) the product has remained unclaimed at Flowline for more than 30 days after Flowline has dutifully requested disposition.
