3.3 Pumped liquids

WARNING
Electric shock
Death or serious personal injury
‐
For indoor use only.
‐
This pump has not been investigated for use in
swimming pool or marine areas.
WARNING
Fire or explosion hazard
Death or serious personal injury
‐
The pump must not be used for the transfer of
flammable liquids such as diesel oil, gasoline and
similar liquids.
The product is suitable for pumping clean, thin, non-aggressive and
non-explosive liquids without solid particles or fibers or mineral oils.
If required, 50 % of the volume solution of glycol and water can be
used. However, a decrease in pump performance may occur due to
an increase in the viscosity of the solution. Contact the
manufacturer for information regarding suitability of the pump for
pumping other liquids.
The pump is designed to circulate water from 36 to 230 °F (2 to 110
°C) up to a maximum pressure of 175 psi (12 bar).
6

3.4 Identification

3.4.1 Nameplate
15 16 17
14
Amp Watt
Min X.XX
XX
Max X.XX XX
13
12 1Ph 115V 60Hz
11
Enclosure type 2
XXX XX: XXXXXXXXXXX
Boitier de type 2
Non-submersible pump
Pompe non immergée
Electronically Protected
10
GFXXX
Max water temp:
9
XXX°F / XXX°C
Max ambient temp:
8 XXX°F / XXX°C
Grundfos Holding A/S
Model: X
7
DK -8850 Bjerringbro
Made in XXXXXXX
Denmark
6
Pos. Description
1 Product number
2 Serial number
3 Factory code and production code (year and week)
4 Data matrix
5 Grundfos address
6 Country of origin
7 Pump model
8 Max. ambient temperature
9 Max. liquid temperature
10 Combined legal product code
11 Enclosure class
12 Number of phases and voltage
13 Max. current consumption
14 Min. current consumption
15 Min. power consumption
16 Max. power consumption
17 Frequency
18 Approvals
19 FCC radio approval ID
Related information
4.1 Inspecting the product
7. Electrical connection
18
19
1
PN:XXXXXXXX
2
SN:XXXXXXXX
PC:XXXXXXX
3
4
5
