Open Drive - Mod. 03A ÷ 460A
3.3- DENOMINAZIONE DEI
COMPONENTI E DIMENSIONI
Nelle FIG. 3A - 3B - 3C - 3D - 3E - 3F - 3G - 3H - 3I -
3L sono rappresentati e denominati i componenti
principali che costituiscono l'Azionamento Open
Drive e le dimensioni d'ingombro nei rispettivi
modelli.
Istruzioni per l'installazione / Installation instructions
Rev. 3.1 - 29.04.09 - IT (originali) / EN (Translations from original instructions)
DESCRIZIONE TECNICA / TECHNICAL DESCRIPTION
3.3- COMPONENT NAMES AND
SIZES
FIG. 3A - 3B - 3C - 3D - 3E - 3F - 3G - 3H - 3I - 3L
show the main components that make up an Open
Drive with the relevant names and overall sizes, for
each model.
3
13
S.p.A.
