Digital output – DO1, DO2, DO3, DO4, DO5, DO6
3.5
24 VDC digital outputs.
DO
+ -
+ -
3.5.1 Terminals
DO1 27 (+)
28 (-)
DO2 30 (+)
31 (-)
DO3 33: (+)
34: (-)
DO4 36: (+)
37: (-)
DO5 47: (+)
48: (-)
DO6 49: (+)
50: (-)
All DOs (-) are common with PS2 (-)
3.5.2 Electrical specifications
DO – Digital outputs
Max load per digital output
Max load total
Val Controls A/S • Sallingsundvej 5 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DHW-UM-004
Revision: 4
up to 48W at 24VDC
up to 192W at 24VDC
