Panasonic Toughbook CF-52AJC15AM Operating Instructions Manual

Panasonic toughbook cf-52ajc15am: user guide.
Hide thumbs

Advertisement

For further information about the com-
puter, you can refer to the on-screen
manual.
To access the on-screen manual
page 16 "On-screen Manual"
Please read these instructions carefully before using this product, and save this manual for future use.

OPERATING INSTRUCTIONS

Contents
Getting Started
.................................................2
..............................................3
(Precautions)

Useful Information

Troubleshooting

Appendix
............................................28
Personal Computer
CF-52
Model No.
.....................................10
.....................................12
.......................................16
.............................17
....................................19
................................21
..............26
..................................32
series

Advertisement

   Also See for Panasonic Toughbook CF-52AJC15AM

   Related Manuals for Panasonic Toughbook CF-52AJC15AM

   Summary of Contents for Panasonic Toughbook CF-52AJC15AM

  • Page 1: Table Of Contents

    For further information about the com- puter, you can refer to the on-screen manual. To access the on-screen manual page 16 “On-screen Manual” Please read these instructions carefully before using this product, and save this manual for future use. OPERATING INSTRUCTIONS Contents Getting Started ...2...
  • Page 2: Introduction

    Introduction Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully. Terms and illustrations in these instructions CAUTION NOTE Enter : Fn + F5 : (Start) - [All Programs]: [start] - [Run] :...
  • Page 3: Read Me First

    Connect the equipment into an outlet on a circuit differ- ent from that to which the receiver is connected. Consult the Panasonic Service Center or an experi- enced radio/TV technician for help. Warning To assure continued compliance, use only shielded inter- face cables when connecting to a computer or peripheral.
  • Page 4 Read Me First 9. The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other elec- tronic device to send any message via a telephone fax machine unless such message clearly contains in a mar- gin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entry,...
  • Page 5 If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.doc.panasonic.de Authorised Representative: Panasonic Testing Centre Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Network connection of Wired Modem. The terminal equipment is intended for connection to the following public network;...
  • Page 6 Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions When in a hospital or other health care facility, observe the restrictions on the use of mobiles.
  • Page 7 IMPORTANT! Personal Computer or Handheld Computer incorporating wireless WAN modem operate using radio signals and cellular networks cannot be guaranteed to connect in all conditions. Therefore, you should never rely solely upon any wireless device for essential communications, for example emergency calls. Remember, in order to make or receive calls, Personal Computer or Handheld Computer incorporating wireless WAN modem must be switched on and in a service area with adequate cellular signal strength.
  • Page 8 , LIFE SUPPORT SYS- TEMS OR OTHER EQUIPMENTS/DEVICES/SYSTEMS THAT ARE INVOLVED WITH ENSURING HUMAN LIFE OR SAFETY. PANASONIC WILL NOT BE RESPONSI- BLE FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGO- ING USES.
  • Page 9 This computer is not intended for a use with connection of medical equipment for the purpose of medical diagnosis. Panasonic shall not be liable for loss of data or other incidental or consequential damages resulting from the use of this product.
  • Page 10: Description Of Parts

    Description of Parts <Model without Touchscreen> A : Speaker Reference Manual “Key Combinations” B : Multimedia pocket Reference Manual “Multimedia Pocket” C : SD Memory Card slot Reference Manual “SD Memory Card” D : Battery pack Specified Battery pack: <Except for CF-52GG/HG series> CF-VZSU29ASU <CF-52GG/HG series>...
  • Page 11 Right side Rear side LOCK A : Hard disk drive Reference Manual “Hard Disk Drive” B : Smart Card slot <Only for model with Smart Card slot> Reference Manual “Smart Card” C : ExpressCard slot Reference Manual “PC Card / ExpressCard” D :PC Card slot Reference Manual “PC Card / ExpressCard”...
  • Page 12: First-time Operation

    First-time Operation Preparation A Check and identify the supplied accessories. If you do not find the described accessories, contact Panasonic Technical Support ( • AC Adaptor ..1 Model No: CF-AA5803A <Only for model with touchscreen>...
  • Page 13: Insert The Battery Pack

    CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support ( page 10) is OFF. page 10) for approximately one page 10) lights.
  • Page 14 First-time Operation Setup Windows. A Follow the on-screen instructions. After the computer is turned on, the screen remains black or unchanged for a while, but this is not a malfunction. Wait for a moment until the Windows setup screen appears. Setup of Windows will take approximately 20 minutes.
  • Page 15 NOTE PC Information Viewer This computer periodically records the management information including the hard disk information. The maximum data volume for each record is 1024 bytes. This information is only used for estimating the cause when the hard disk goes down by any possibility. They are never sent to outside via network nor used for any other purpose except for the purpose described the above.
  • Page 16: On-screen Manual

    (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips]. Double-click Alternatively click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips]. NOTE When Adobe Reader update notice is displayed, we recommend you follow the on-screen procedure and update.
  • Page 17: Handling And Maintenance

    Handling and Maintenance Operation Environment Place the computer on a flat stable surface. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become inoperable. Temperature: Operation : 5 °C to 35 °C {41 °F to 95 °F} Storage : -20 °C to 60 °C {- 4 °F to 140 °F} Humidity:...
  • Page 18 Handling and Maintenance Maintenance To clean the LCD panel <Only for model without touchscreen> Do not use water to clean the panel. Ingredients included in water may leave scratches and reduce readability of the screen. To remove dust or dirt, do not use a cloth to rub it off since it may leave scratch on the screen. Use a fine brush to sweep dust or dirt, then wipe with a dry soft glass-cleaning cloth.
  • Page 19: Reinstalling Software

    Reference Manual “Multimedia Pocket”). When reinstalling Windows XP from Windows 7: A Turn on the computer, and press F2 or Del while [Panasonic] boot screen is displayed. B Set the Product Recovery DVD-ROM for Windows 7 into the CD/DVD drive.
  • Page 20 Reinstalling Software When reinstalling Windows 7 from Windows XP: Click [Next]. At the confirmation message, click [YES]. Reinstallation starts according to the instructions on the screen. (It will take approximately 30 - 75 minutes.) Do not interrupt reinstallation, for example by turning off the computer. Otherwise reinstallation may become unavailable as Windows may not start up or the data may be corrupted.
  • Page 21: Troubleshooting (basic)

    You have forgotten the Supervisor Password or User Password: Contact Panasonic Technical Support password. Administrator password: • If you have a password reset disk, you can reset the administrator password. Set •...
  • Page 22 [ExpressCard Slot] to [Disabled] in the [Advanced] menu of the Setup Utility. <Only for model with ExpressCard slot> If the problem persists after removing the disk, it may be a hard disk failure. Contact Panasonic Technical Support ( page 33). Press F9 in the Setup Utility ( Setup Utility settings (excluding the passwords) to the default values.
  • Page 23 B Click [Tools] - [Check Now]. C Select the option in [Check disk options] and click [Start]. Start the computer in Safe Mode and check the error details. When the [Panasonic] boot screen disappears Options Menu is displayed. Select the Safe Mode and press Enter.
  • Page 24 Turn off the external display. Try playback by using Windows Media Player. Refer to the following URL, then try to update WinDVD. http://pc-dl.panasonic.co.jp/itn/support/faqs_en.html When using the external mouse, connect it correctly. Restart the computer using the keyboard.
  • Page 25 CD/DVD Drive The tray does not come out A pin of 1.3 mm in diameter is recommended to although inserting a pointed remove a disc using the emergency hole (A). When object to the emergency the diameter of the pin is smaller than this, insert the hole.
  • Page 26: Limited Use License Agreement

    DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended results, and for the installation, use and results obtained therefrom.
  • Page 27 En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et conditions des présentes. Panasonic Corporation a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.
  • Page 28: Specifications

    Specifications This page provides the specifications for the basic model. The model number is different according to the unit configu- ration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility ( [Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Hard disk drive size...
  • Page 29 Main Specifications Model No. CF-52EKNBDPM / CF-52FKNBZPM / CF-52EKNHDPM 65,536 / 16,777,216 colors (800 External Display dots / 1920 ® Wireless LAN Intel page 30 Bluetooth IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE 802.3ab 1000BASE-T Data: 56 kbps (V.92) FAX: 14.4 kbps Modem Sound WAVE and MIDI playback, Intel...
  • Page 30 MB/GB. Data transfer speeds indicate values measured by Panasonic Corporation. The data transfer rate of DVD per 1X speed is 1,350 KB/s. The data transfer rate of CD per 1X speed is 150 KB/s.
  • Page 31 Dummy card is not inserted into the PC card slot and the ExpressCard slot. This slot is compatible with High-Speed Mode. Operation has been tested and confirmed using Panasonic SD/SDHC Memory Cards with a capacity of up to 8 GB. Operation on other SD equipment is not guaranteed.
  • Page 32: Limited Warranty

    Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair the products listed below with new or rebuilt parts, free of charge in the U.S.A. or other Panasonic approved location for the period specified below from the date of original purchase in the event of a defect in materials or workmanship.
  • Page 33 This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For technical support or to arrange for service on your Panasonic computer product, call our toll-free hotline at 1-800-LAPTOP5.
  • Page 34 No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product, or in environmental conditions other than those specified by PCI or the manufacturer, or if subjected to misuse, neglect, mishandling, modification or attempted modification of the program, or if damaged by accident or act of God.
  • Page 35 GARANTIE LIMITÉE – SUPPORTS DES LOGICIELS Couverture – Panasonic Canada Inc. (« PCI ») garantit à l’acheteur original que la ou les disquettes ou tout autre support sur lequel le ou les programmes sont fournis sont exempts de défauts de pièces et de fabrication dans des conditions normales d’utilisation au Canada, et ce, pour une période de soixante (60) jours suivant la date de réception indiquée sur la preuve d’achat.
  • Page 36 As an NERGY ® NERGY settings, Panasonic computers enter a low-power sleep mode after a period of inactivity, saving the user energy. To learn more about power management, please visit the web site: www.energystar.gov/index.cfm?c=power_mgt.pr_power_management Outline of the International The international NERGY saving through the use of computers and other office equipment.
