Panasonic CF-19 Series Supplementary Instructions Manual

For hspa modem personal computer.
Hide thumbs

Advertisement

Model No.
This manual contains supplementary instructions regarding the use of the
computer. It explains the cases where the operation of the computer differs from
that in the Operating Instructions.
Your computer is equipped with the HSPA modem enabling you to communicate
using radio frequencies.
Contents
Precautions .................................................................. 2
Description of Parts ..................................................... 4
Inserting/Removing a SIM Card .................................. 9
Installing the Software ............................................... 12
Troubleshooting ......................................................... 14
Specifi cations ............................................................. 14
Appendix ..................................................................... 15
Terms and illustrations in this Manual
NOTE:
CAUTION:
[start] - [Run]:
:
:
Some of the illustrations in this manual may differ slightly in shape from the
actual items in order to make the explanation easier to understand.
About the abbreviations in this manual, refer to the table on page 15.
Supplementary Instructions
CF-19/CF-30/CF-52
Useful and helpful information.
Condition that may result in minor or moderate injury.
Click [start], and then click [Run].
You may need to double-click in some cases.
Page in these Supplementary Instructions or in the
Reference Manual for the computer.
Reference to the on-screen manuals.
for HSPA Modem
Personal Computer
Series

Advertisement

Table of Contents

   Related Manuals for Panasonic CF-19 Series

   Summary of Contents for Panasonic CF-19 Series

  • Page 1: Table Of Contents

    Supplementary Instructions for HSPA Modem Personal Computer CF-19/CF-30/CF-52 Series Model No. This manual contains supplementary instructions regarding the use of the computer. It explains the cases where the operation of the computer differs from that in the Operating Instructions. Your computer is equipped with the HSPA modem enabling you to communicate using radio frequencies.
  • Page 2: Precautions

    Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions.
  • Page 3 Personal Computer or Handheld Computer incorporating wireless WAN modem. 27-E-1-1 Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this Personal Computer is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.doc.panasonic.de...
  • Page 4: Description Of Parts

    Description of Parts Except the followings, refer to the Operating Instructions for the computer. <CF-19 Series> Antenna Wireless Switch page 7, Reference Manual for the computer “Disabling/Enabling Wireless Communication”) SIM Card Slot page 9) (Appearance may differ depending on specifi cations.)
  • Page 5 <CF-30 Series> Antenna SIM Card Slot page 9) Wireless Switch page 7, Reference Manual for the computer “Disabling/Enabling Wireless Communication”) (Appearance may differ depending on specifi cations.)
  • Page 6 Description of Parts <CF-52 Series> Antenna Wireless Switch page 7, Reference Manual SIM Card Slot for the computer “Disabling/Enabling page 9) Wireless Communication”) (Appearance may differ depending on specifi cations.) Supplied Accessories Wireless WAN (HSPA) Software CD-ROM ......1...
  • Page 7: Open The Cover

    Using the Wireless Switch <CF-19 Series> <CF-19 Series> Open the cover. A Slide the latch to the right to unlock the cover. B Slide the latch down, and open the cover. <CF-19 Series> Slide the wireless switch (A) to turn on/off the wireless devices.
  • Page 8 Description of Parts <CF-52 Series> NOTE To use wireless communication, set the wireless device setting ([Wireless LAN] / [Bluetooth] / [Wireless WAN]) to [Enabled] (default) in the [Advanced] menu of the Setup Utility. It may take some time to turn off wireless communication after switching the wireless switch to off.
  • Page 9: Inserting/removing A Sim Card

    Before using the HSPA modem, set a SIM card to the SIM card slot. CAUTION Be sure to shut down the computer before inserting or removing the SIM card. <CF-19 Series> Turn off the computer. Contact SIM Card Inserting a SIM card A Open the cover.
  • Page 10 Inserting/Removing a SIM Card <CF-19 Series> Removing a SIM card A Open the cover. Refer to the step A on page 9. <Only for CF-52 Series> After opening the cover, remove the screw and then remove the metallic cover. B Push the card.
  • Page 11 <CF-52 Series>...
  • Page 12: Installing The Software

    If the [Found New Hardware Wizard] screen is displayed, click [Cancel] to close the screen. Install the Wireless WAN software by following procedure. A <Only for CF-19 Series> Connect the CD/DVD drive. <Only for CF-30 Series> Insert the CD/DVD drive in Multimedia Pocket.
  • Page 13 Uninstalling the software <Model with Windows XP> Click [start] - [Control Panel] - [Add or Remove Programs] - [Wireless WAN Software Installer for Gobi(TM)], and then click [Remove] to uninstall the software. <Model with Windows Vista> Click (Start) - [Control Panel] - [Uninstall a program] - [Wireless WAN Software Installer for Gobi(TM)], and then click [Uninstall] to uninstall the software.
  • Page 14: Troubleshooting

    Troubleshooting Cannot • Confi rm that wireless switch is in ON. communicate. • Confi rm that [Wireless WAN] is set to [Enabled] in the [Advanced] menu of the Setup Utility. • Use the Wireless Switch Utility and confi rm that the wireless WAN is on.
  • Page 15: Appendix

    Appendix Abbreviations EDGE Enhanced Data rates for Global Evolution GPRS General Packet Radio Service HSDPA High Speed Downlink Packet Access Subscriber Identity Module Short Message Service UMTS Universal Mobile Telecommunications System HSPA High Speed Packet Access HSUPA High Speed Uplink Packet Access...
  • Page 16 Importer’s name & address pursuant to the EU GPSD (General Product Safety Directive) 2001/95/EC Art.5 Hagenauer Straße 43 65203 Wiesbaden Germany © Panasonic Corporation 2009 HS0409-0 Printed in Japan DFQW5276ZA...
